PUIG 7004 Mounting Instructions

MOTOPLASTIC, S.A.
Molí de la sal, 1 - 08403 Granollers (Barcelona) SPAIN
Tel. 34 93 849 06 33 - Fax 34 93 849 09 88
info@puig.tv - info@puigusa.com
www.puig.tv - www.puigusa.com
INSTRUCCIONES DE MONTAJE - MOUNTING INSTRUCTIONS - MONTAGEANLEITUNG
CÚPULA ADAPTABLE A - SCREEN FOR - WINDSCHUTZSCHEIBE FÜR
SIN CÚPULA ORIGINAL / WITHOUT ORIGINAL SCREEN
ID. PIEZA / PART
1
2
3
4
5
6
Pg. 1/3
KTM RC 125/200/390
DESCRIPCIÓN
Cúpula
Tornillo especial M6x13 con hexagonal 18mm
y rosca int. M5x11
Tornillo especial M6x13 con hexagonal 14mm
y rosca int. M5x11
Arandela de goma Ø ext. 15 Ø int. 5x4
Tornillo Allen M5x16 ISO 7380 (negro)
Arandela nylon M5x0,5
CON CÚPULA ORIGINAL / WITH ORIGINAL SCREEN
DESCRIPTION
Screen
Special Screw M6x13 with hexagonal 18mm
and interior thread M5x11
Special Screw M6x13 with hexagonal 14mm
and interior thread M5x11
Ø outer 15 x Ø inner 5x4 rubber washer
M5x16 ISO 7380 (black) Allen screw
M5x0,5 nylon washer
Ref.: 7004
QTY.
1
2
2
4
4
4
