MPS Variable Multi Split SYSTEM
Free Joint, 50Hz, R410A
LM50 2004-E1
Get user manuals:
See SafeManuals.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LM50 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG LM50

Summary of Contents for LG LM50

  • Page 1 MPS Variable Multi Split SYSTEM Free Joint, 50Hz, R410A LM50 2004-E1 Get user manuals: See SafeManuals.com...
  • Page 2 A high-grade, high-quality, advanced individual air-conditioning system that is able to respond to expanding, more sophisticated housing environment needs. LG Electronics Inc., which has been a top air conditioner maker for the three consecutive years, has developed "MPS(Multi Power System) Variable Multi Split" system that can efficiently control air-conditioning in a better way.
  • Page 3 MPS Variable Multi Split System(50Hz, R410A) Get user manuals: See SafeManuals.com...
  • Page 4 LG Airconditioners Product Data TABLE OF CONTENTS Table of contents Page Part 1 Features....................7 Part 2 MPS Variable Multi-Split system (R410A)........11 2004 Product Data Get user manuals: See SafeManuals.com...
  • Page 5 MPS Variable Multi Split System(50Hz, R410A) Get user manuals: See SafeManuals.com...
  • Page 6 Part 1 Features 2004 Product Data Get user manuals: See SafeManuals.com...
  • Page 7 Features & Benefit MPS(Multi Power System) Variable Control : (Except A2UC146FA0,A2UH146FA0) Big Energy Saving with MPS Variable Control • Basic Principle of MPS Variable Control MPS control provides comfortable and convenient environment as there are two compressors with 60&40% load sharing with on compressor of small capacity always working to maintain the set temperature conditions & meanwhile other compressor is at rest if the load is low whereas in conventional system the only compressor is working with ON/OFF cycles.
  • Page 8 Features & Benefit Air Purifying System (ppm) - It not only removes microscopic contaminants & dust, but it Normal Filter also removes house mites, pollen, and pet fur to help pre- vent allergic diseases like asthma.It provides odor free, dust free and allergy free air.
  • Page 9 Features & Benefit Ultra-Slim design(Depth 129mm) 129 mm Thinnest Turbo Fan 3-Dimensional Cooling System New Cube 3-Dimension cooling system of ART COOL has Indirect Cooling mode for sleep operation. Being in sleep operation, cool air is discharged only right/left side! Indirect cooling ensures you nice sleep.
  • Page 10 Cooling, Heating & Fan Operation: - LG multi air conditioners can provide cooling, heating & fan operation. In the cooling mode, it cools the air with an operation range of 18~30°C. In the heating mode, it heats the air with an operation range of 16~30°C. In the fan operation mode, only indoor fan will run at the selected speed, outdoor fan and compressor will be off.
  • Page 11 MPS Variable Multi Split System(50Hz, R410A) Get user manuals: See SafeManuals.com...

  • Page 12: Table Of Contents

    Part 2 MPS Variable Multi-Split System R410A, Cooling Only/Heat Pump AMNC076LQL0 AMNC096AP*1 A2UC146FA0 AMNC096LQL0 AMNC126AP*1 A2UC186FA0 AMNC126LRL0 A3UC216FA0 AMNC186LTL0 A4UC306FA0 AMNC246LTL0 AMNH076LQL0 AMNH096AP*1 A2UH146FA0 AMNH096LQL0 AMNH126AP*1 A2UH186FA0 AMNH126LRL0 A3UH216FA0 AMNH186LTL0 A4UH306FA0 AMNH246LTL0 1. Power Supply .........................12 2. Model Number Nomenclature ..................13 3.

  • Page 13: Power Supply

    1. Power Supply Type Outdoor Unit Power Supply A2UC146FA0 A2UC186FA0 Cooling Only A3UC216FA0 A4UC306FA0 1Ø, 220~240V, 50Hz A2UH146FA0 Heat Pump A2UH186FA0 A3UH216FA0 A4UH306FA0 Note : Power Supply Intake ; Outdoor Unit Only External wiring procedure - The power supply is needed only to the outdoor unit. The power supply to the indoor unit Is conducted through the transmission wiring.

  • Page 14: Model Number Nomenclature

    2. Model Number Nomenclature 2.1 Indoor Units Serial Number Combination of Functions L : Nano Plasma ART COOL Type Front Panel Color B : Blue, D : Wood, M : Metal Chassis Name Indoor Unit Type L : Wall Mounted A : ART COOL Electrical Ratings 6: 1ø, 220~240V, 50Hz...

  • Page 15: Outline Of System

    3. Outline of System The system has number of indoor units attached to an outdoor unit which saves energy while in operation. This system can be installed in small space and cooling can be controlled in each room individually. 3.1 Example of System [A4UH306FA0] 3.2 Combination of Indoor and Outdoor Unit Indoor Units...
  • Page 16 3. Outline of System 3.3 External Appearance of Indoor Units Wall Mounted ART COOL AMNC076LQL0 AMNH076LQL0 AMNC096AP*1 AMNH096AP*1 AMNC096LQL0 AMNH096LQL0 AMNC126AP*1 AMNH126AP*1 AMNC126LRL0 AMNH126LRL0 AMNC186LTL0 AMNH186LTL0 AMNC246LTL0 AMNH246LTL0 '* : Front Panel Color B : Blue D : Wood M : Metal 2004 Product Data Get user manuals: See SafeManuals.com...

  • Page 17: List Of Functions

    4. List of Functions Model AMNC-LQ/LR/LT AMNC-AP AMNH-LQ/LR/LT AMNH-AP Features Airflow Direction Control(Left & Right) Manual Manual Manual Manual Airflow Direction Control(Up & Down) Automatic Automatic Automatic Automatic Airflow Outlet Airflow Steps(Fan / Cool / Heat) 3/4/3 3/4/3 3/4/3 3/4/3 Auto Changeover(Operation) Auto Cleaning Auto Restart Operation...

  • Page 18: Specifications

    5. Specifications 5.1 Indoor Units Cooling Only Indoor Unit Type Wall Mounted Model AMNC076LQL0 AMNC096LQL0 AMNC126LRL0 AMNC186LTL0 AMNC246LTL0 Nominal Cooling Capacity # kcal/hr(W) 1764(2051) 2267(2638) 3024(3515 4536(5275) 5795(6740 Btu/hr 7000 9000 12000 18000 23000 Nominal Heating Capacity # kcal/hr(W) Btu/hr Air Circulation H/M/L CMM(CFM)
  • Page 19 5. Specifications Heat Pump Indoor Unit Type Wall Mounted Model AMNH076LQL0 AMNH096LQL0 AMNH126LRL0 AMNH186LTL0 AMNH246LTL0 Nominal Cooling Capacity # kcal/hr(W) 1764(2051) 2267(2638) 3024(3515) 4536(5275) 5796(6740) Btu/hr 7000 9000 12000 18000 23000 Nominal Heating Capacity # kcal/hr(W) 2016(2343) 2520(2929) 3326(3867) 4990(5803) 6426(7472) Btu/hr 8000...
  • Page 20 Rotary Rotary Rotary Quantity Model GJ176PAA 5KS140DAD21 5KS150EAB21 5KS225DKSM681 Maker LG. Electric Matsushita Electric Matsushita Electric Matsushita Electric Capacity kcal/hr(Btu/hr) 3654(14500) at 50Hz & 240V 2932(11635) at 50Hz & 240V 3130(12420) at 50Hz & 240V 4901(19450) at 50Hz & 240V...
  • Page 21 Rotary Quantity Model GJ176PAA 5KS140DAD21 5KS150EAB21 5KS225DKSM681 Maker LG. Electric Matsushita Electric Matsushita Electric Matsushita Electric Capacity kcal/hr(Btu/hr) 3654(14500) at 50Hz & 240V 2932(11635) at 50Hz & 240V 3130(12420) at 50Hz & 240V 4901(19450) at 50Hz & 240V Motor Type...

  • Page 22: Combination Table

    6. Combination Table 6.1 Cooling Only 6.1.1 A2UC146FA0 Cooling Cooling Combination(k Btu) Capacity (Btu/h) Input Current Operation (Btu/h.W) Unit-A Unit-B Unit-C Unit-D Total Total 1 UNIT 9000 7000 1300 2 UNIT 7500 7500 15000 1400 10.7 6.1.2 A2UC186FA0 Cooling Cooling Combination(k Btu) Capacity (Btu/h) Input...
  • Page 23 6. Combination Table 6.1.4 A4UC306FA0 Cooling Cooling Combination(k Btu) Capacity (Btu/h) Operation Input Current (Btu/h.W) Unit-A Unit-B Unit-C Unit-D Total Total 9000 9000 1200 10000 10000 1200 1 UNIT 12000 12000 1200 10.0 18000 18000 1950 24000 24000 3250 15.0 8000 8000 16000...
  • Page 24 6. Combination Table 6.2 Heat Pump 6.2.1 A2UH146FA0 Cooling Cooling Combination(k Btu) Operation Capacity (Btu/h) Input Current Unit-A Unit-B Unit-C Unit-D Total (Btu/h.W) Total 1 UNIT 9400 9400 1350 2 UNIT 7200 7200 14400 1450 Heating Heating Combination(k Btu) Operation Capacity (Btu/h) Input Current...
  • Page 25 6. Combination Table 6.2.3 A3UH216FA0 Cooling Cooling Combination(k Btu) Capacity (Btu/h) Operation Input Current Unit-A Unit-B Unit-C Unit-D Total (Btu/h.W) Total 8000 8000 9500 9500 10.6 1 UNIT 12(Art) 11000 11000 1150 12000 12000 1150 10.4 8400 8400 16800 2100 8000 10000 18000...
  • Page 26 6. Combination Table 6.2.4 A4UH306FA0 Cooling Cooling Combination(k Btu) Operation Capacity (Btu/h) Input Current Unit-A Unit-B Unit-C Unit-D Total Total (Btu/h.W) 9000 9000 1200 10000 10000 1200 1 UNIT 12000 12000 1200 10.0 18000 18000 1950 24000 24000 3250 15.0 8000 8000 16000...
  • Page 27 6. Combination Table Heating Heating Combination(k Btu) Capacity (Btu/h) Operation Input Current Unit-A Unit-B Unit-C Unit-D Total (Btu/h.W) Total 10000 10000 1310 11000 11000 1310 1 UNIT 12000 12000 1310 18000 18000 2050 26400 26400 3360 15.5 8800 8800 17600 2050 8200 10400...

  • Page 28: Dimensional Drawings

    7. Dimensional Drawings 7.1 Indoor Units AMNC-LQ/LR/LT, AMNH-LQ/LR/LT More than More than 5cm More than More than 2.3m Installation plate Note: 1. Pipe Specification(mm) Model Liquid Ø 6.35 Ø 9.52 7, 9, 12k Ø 6.35 Ø 12.7 18, 24k Distance(mm) CHASSIS (Grade) Installation plate...
  • Page 29 7. Dimensional Drawings AMNC-AP, AMNH-AP Hanger Hole Fix Hole Pipe Hole (Unit: mm) Note: 1. Pipe Specification(mm) More than 10cm Model Liquid 9, 12k Ø 6.35 Ø 9.52 More than 50cm More than 50cm More than 2m (unit : mm) Model AMNC/H096AP*1 AMNC/H126AP*1...
  • Page 30 7. Dimensional Drawings 7.2 Outdoor Units A2UC146FA0, A2UH146FA0 Gas side 3-way valve Liquid side 2-way valve Model A2UC146FA0, A2UH146FA0 Dimensions 543.6 11.4 72.5 74.5 2004 Product Data Get user manuals: See SafeManuals.com...
  • Page 31 7. Dimensional Drawings A2UC186FA0, A2UH186FA0 Gas side 3-Way valve Liquid side 2-Way valve Model A2UC186FA0, A2UH186FA0 Dimensions 76.5 MPS Variable Multi Split System(50Hz, R410A) Get user manuals: See SafeManuals.com...
  • Page 32 7. Dimensional Drawings A3UC216FA0, A3UH216FA0 Gas side 3-way valve Liquid side 2-way valve Model A3UC216FA0, A3UH216FA0 Dimensions 76.5 2004 Product Data Get user manuals: See SafeManuals.com...
  • Page 33 7. Dimensional Drawings A4UC306FA0, A4UH306FA0 4-holes for anchor bolts Number Name Descripition Liquid side service valve(mm) Ø6.35 Gas side service valve(mm) Ø9.52 Air discharge grill Control Cover MPS Variable Multi Split System(50Hz, R410A) Get user manuals: See SafeManuals.com...

  • Page 34: Wiring Diagrams

    8. Wiring Diagrams 8.1 Indoor Unit Wall Mounted AC PCB ASM DC PCB ASM THERMISTOR(OUT-PIPE) THERMISTOR(IN-PIPE) THERMISTOR(ROOM) FUSE 250V 2A 3854A20135W CONNECTOR NUMBER Location CN-POWER AC POWER SUPPLY CN-MOTOR AC FAN MOTOR OUTPUT CN-ACDC AC/DC CONNECTION CN-COMM COMMUNICATION CN-DISP DISPLAY CN-DISP2 DISPLAY CN-UD...
  • Page 35 8. Wiring Diagrams ART COOL Type AC PWB ASM DC PWB ASM THERMISTOR(OUT-PIPE) THERMISTOR(IN-PIPE) MOTOR THERMISTOR(ROOM) STEP MOTOR STEP MOTOR STEP MOTOR FUSE 250V 3.15A H.V. PLASMA AIR CLEAN CN-D1(WH) CN-D2(WH) 1(L) 2(N) DISPLAY CONNECT SAFETY S/W TO OUTDOOR UNIT PCB ASM SAFETY S/W STEP...
  • Page 36 8. Wiring Diagrams 8.2 Outdoor Unit A2UC146FA0 OUTDOOR WIRING DIAGRAM 1(L) MAIN POWER 2(N) MAIN PCB ASSY 1(L) T/B1 2(N) A-UNIT 3(A) 3(B) FUSE 250V T3.15A B-UNIT T/B2 P/NO : 3854A20375B Notes: BLUE BLACK BROWN ORANGE WHITE YELLOW GN/YL GREEN/YELLOW CONNECTOR 2004 Product Data Get user manuals:...
  • Page 37 8. Wiring Diagrams A2UC186FA0 OUTDOOR WIRING DIAGRAM (WH) 1(L) CN-LEV2 CN-LEV1 (BL) (WH) COMP-A 2(N) INDOOR UNIT-A CN-COMP COMP-B GN/YL (RD) MAIN PWB ASSY 2(N) INDOOR UNIT-B CN-COM 1(L) (WH) CN-FAN1 (WH) FUSE GN/YL T3.15A 1(L) MAIN POWER CN-TH1 CN-POWER (WH) 2(N) (RD)
  • Page 38 8. Wiring Diagrams A3UC216FA0 OUTDOOR WIRING DIAGRAM GN/YL GN/YL (WH) 1(L) CN-LEV3 CN-LEV2 CN-LEV1 INDOOR (YL) (BL) (WH) COMP-A 2(N) UNIT-A COMP-B CN-COMP (RD) INDOOR UNIT-B 2(N) MAIN PWB ASSY 1(L) CN-COM (WH) INDOOR CN-FAN1 (WH) UNIT-C FUSE GN/YL T3.15A GN/YL 1(L) CN-TH1...
  • Page 39 8. Wiring Diagrams A4UC306FA0 GN/YL OUTDOOR WIRING DIAGRAM GN/YL FMo1 INDOOR (WH) UNIT-A CN-LEV4 CN-LEV3 CN-LEV2 CN-LEV1 (WH) (YL) (BL) (WH) COMP-A 2(N) INDOOR UNIT-B 1(L) COMP-B CN-COMP (RD) MAIN PWB ASSY INDOOR UNIT-C FMo2 CN-FAN1 2(N) (WH) (WH) CN-COM 1(L) (WH) CN-FAN2...
  • Page 40 8. Wiring Diagrams A2UH146FA0 OUTDOOR WIRING DIAGRAM 1(L) MAIN POWER 2(N) MAIN PCB ASSY 1(L) T/B1 2(N) A-UNIT 3(A) 3(B) FUSE 250V T3.15A B-UNIT CN-TH1 (RD) PIPE SENSOR T/B2 P/NO : 3854A20375A Notes: BLUE BLACK BROWN ORANGE WHITE YELLOW GN/YL GREEN/YELLOW CONNECTOR 2004 Product Data...
  • Page 41 8. Wiring Diagrams A2UH186FA0 OUTDOOR WIRING DIAGRAM (WH) 1(L) CN-LEV2 CN-LEV1 (BL) (WH) COMP-A 2(N) INDOOR UNIT-A COMP-B CN-COMP GN/YL (RD) MAIN PWB ASSY 2(N) INDOOR UNIT-B CN-COM (WH) 1(L) CN-FAN1 (WH) FUSE GN/YL T3.15A 1(L) MAIN POWER CN-TH1 CN-POWER (RD) CN-H,L,S,4 (WH)
  • Page 42 8. Wiring Diagrams A3UH216FA0 OUTDOOR WIRING DIAGRAM GN/YL GN/YL (WH) 1(L) CN-LEV3 CN-LEV2 CN-LEV1 INDOOR (YL) (BL) (WH) COMP-A 2(N) UNIT-A COMP-B CN-COMP (RD) INDOOR UNIT-B 2(N) MAIN PWB ASSY 1(L) CN-COM (WH) INDOOR CN-FAN1 (WH) UNIT-C FUSE GN/YL T3.15A GN/YL 1(L) CN-TH1...
  • Page 43 8. Wiring Diagrams A4UH306FA0 GN/YL OUTDOOR WIRING DIAGRAM GN/YL FMo1 INDOOR (WH) UNIT-A CN-LEV4 CN-LEV3 CN-LEV2 CN-LEV1 (WH) (YL) (BL) (WH) COMP-A 2(N) INDOOR UNIT-B 1(L) COMP-B CN-COMP (RD) MAIN PWB ASSY INDOOR UNIT-C FMo2 CN-FAN1 2(N) (WH) (WH) CN-COM 1(L) (WH) CN-FAN2...

  • Page 44: Piping Diagrams

    9. Piping Diagrams 9.1 Indoor Unit 9.1.1 Cooling Only Wall Mounted :Cooling Heat Exchanger Refrigerant pipe connection port diameter C.F.F [unit:mm(inch)] Model Liquid lndoor unit AMNC076LQL0 AMNC096LQL0 Ø9.52(3/8) AMNC126LRL0 Ø6.35(1/4) AMNC186LTL0 Ø12.7(1/2) AMNC246LTL0 : Thermistor ART COOL :Cooling Heat Exchanger Turbo Fan Refrigerant pipe connection port diameter [unit:mm(inch)]...
  • Page 45 9. Piping Diagrams 9.1.2 Heat Pump Wall Mounted :Cooling Heat Exchanger :Heating Refrigerant pipe connection port diameter C.F.F [unit:mm(inch)] Model Liquid lndoor unit AMNH076LQL0 AMNH096LQL0 Ø9.52(3/8) AMNH126LRL0 Ø6.35(1/4) AMNH186LTL0 Ø12.7(1/2) AMNH246LTL0 : Thermistor ART COOL :Cooling Heat Exchanger :Heating Turbo Fan Refrigerant pipe connection port diameter [unit:mm(inch)] lndoor unit...
  • Page 46 9. Piping Diagrams 9.2 Outdoor Unit 9.2.1 Cooling Only A2UC146FA0 OUTDOOR UNIT Room B Field Piping Room A Header Accumulator Heat Exchanger Compressor Solenoid Valve Room B Field Piping Liquid Room A Refrigerant Flow Capillary Tube Cooling A2UC186FA0 OUTDOOR UNIT Room B Field Piping Room A...
  • Page 47 9. Piping Diagrams A3UC216FA0 OUTDOOR UNIT Room C Field Piping Room B Room A Header Check Check Valve(2) Valve(1) Accumulator Compressor A Compressor B LEV-C Room C LEV-B Field Piping Room B Liquid LEV-A Room A Refrigerant Flow Cooling A4UC306FA0 OUTDOOR UNIT Room D Room C...
  • Page 48 9. Piping Diagrams 9.2.2 Heat Pump A2UH146FA0 OUTDOOR UNIT Reversing Room B Valve Field Piping Room A Header Accumulator Heat Exchanger Compressor Solenoid Valve Room B Field Piping Liquid Room A Refrigerant Flow Capillary Tube Cooling Heating A2UH186FA0 OUTDOOR UNIT Reversing Room B Valve...
  • Page 49 9. Piping Diagrams A3UH216FA0 OUTDOOR UNIT Reversing Room C Valve Field Piping Room B Room A Header Check Check Valve(1) Valve(2) Accumulator Compressor A Compressor B LEV-C Room C LEV-B Field Piping Room B Liquid Pressure LEV-A Room A Refrigerant Flow Cooling Heating A4UH306FA0...

  • Page 50: Capacity Tables

    10. Capacity Table Cooling Only 10.1 A2UC146FA0 [Cooling Capacity] Indoor Air Temp.: °CWB Combination Outdoor Capacity Index Air Temp.: (kBtu/h) °CDB 2.52 0.89 2.69 0.90 2.81 0.92 2.91 0.93 3.05 0.95 3.12 0.96 2.48 0.98 2.66 0.99 2.77 1.01 2.87 1.03 3.00 1.04...
  • Page 51 10. Capacity Table Cooling Only 10.3 A3UC216FA0 [Cooling Capacity] Indoor Air Temp.: °CWB Combination Outdoor Capacity Index Air Temp.: (kBtu/h) °CDB 2.24 0.60 2.40 0.61 2.50 0.62 2.58 0.63 2.71 0.64 2.77 0.65 2.20 0.66 2.36 0.67 2.46 0.68 2.55 0.69 2.67 0.70...
  • Page 52 10. Capacity Table Cooling Only 10.4 A4UC306FA0 [Cooling Capacity] Indoor Air Temp.: °CWB Combination Outdoor Capacity Index Air Temp.: (kBtu/h) °CDB 2.52 0.82 2.69 0.84 2.81 0.85 2.91 0.86 3.05 0.87 3.12 0.88 2.48 0.90 2.66 0.92 2.77 0.93 2.87 0.95 3.00 0.96...
  • Page 53 10. Capacity Table Cooling Only Indoor Air Temp.: °CWB Combination Outdoor Capacity Index Air Temp.: (kBtu/h) °CDB 7.83 2.22 8.38 2.26 8.74 2.29 9.04 2.33 9.48 2.37 9.70 2.40 7.72 2.44 8.26 2.48 8.61 2.52 8.91 2.56 9.34 2.60 9.56 2.63 9+18 7.44...
  • Page 54 10. Capacity Table Cooling Only Indoor Air Temp.: °CWB Combination Outdoor Capacity Index Air Temp.: (kBtu/h) °CDB 8.39 2.22 8.98 2.26 9.36 2.29 9.69 2.33 10.16 2.37 10.39 2.40 8.27 2.44 8.85 2.48 9.23 2.52 9.55 2.56 10.01 2.60 10.24 2.63 9+9+12 7.97...
  • Page 55 10. Capacity Table Heat Pump 10.5 A2UH146FA0 [Cooling Capacity] Indoor Air Temp.: °CWB Combination Outdoor Capacity Index Air Temp.: (kBtu/h) °CDB 2.63 0.92 2.81 0.94 2.93 0.95 3.04 0.97 3.18 0.98 3.26 1.00 2.59 1.01 2.77 1.03 2.89 1.04 2.99 1.06 3.14 1.08...
  • Page 56 10. Capacity Table Heat Pump 10.6 A2UH186FA0 [Cooling Capacity] Indoor Air Temp.: °CWB Combination Outdoor Capacity Index Air Temp.: (kBtu/h) °CDB 1.96 0.53 2.10 0.54 2.18 0.55 2.26 0.56 2.37 0.57 2.42 0.58 1.93 0.59 2.07 0.60 2.15 0.60 2.23 0.62 2.34 0.62...
  • Page 57 10. Capacity Table Heat Pump [Heating Capacity] Outdoor Air Temp.: °CWB Combination Indoor Capacity Index Air Temp.: (kBtu/h) °CDB 1.78 0.95 2.10 1.04 2.43 1.13 2.82 1.22 3.06 1.28 3.37 1.37 1.72 0.98 2.03 1.07 2.35 1.17 2.73 1.26 2.96 1.33 3.27 1.42...
  • Page 58 Heat Pump 10. Capacity Table 10.7 A3UH216FA0 [Cooling Capacity] Indoor Air Temp.: °CWB Combination Outdoor Capacity Index Air Temp.: (kBtu/h) °CDB 2.24 0.60 2.40 0.61 2.50 0.62 2.58 0.63 2.71 0.64 2.77 0.65 2.20 0.66 2.36 0.67 2.46 0.68 2.55 0.69 2.67 0.70...
  • Page 59 10. Capacity Table Heat Pump [Heating Capacity] Outdoor Air Temp.: °CWB Combination Indoor Capacity Index Air Temp.: (kBtu/h) °CDB 1.78 0.98 2.10 1.08 2.43 1.17 2.82 1.27 3.06 1.33 3.37 1.43 1.72 1.02 2.03 1.11 2.35 1.21 2.73 1.31 2.96 1.38 3.27 1.48...
  • Page 60 Heat Pump 10. Capacity Table 10.8 A4UH306FA0 [Cooling Capacity] Indoor Air Temp.: °CWB Combination Outdoor Capacity Index Air Temp.: (kBtu/h) °CDB 2.52 0.82 2.69 0.84 2.81 0.85 2.91 0.86 3.05 0.87 3.12 0.88 2.48 0.90 2.66 0.92 2.77 0.93 2.87 0.95 3.00 0.96...
  • Page 61 10. Capacity Table Heat Pump Indoor Air Temp.: °CWB Combination Outdoor Capacity Index Air Temp.: (kBtu/h) °CDB 7.83 2.22 8.38 2.26 8.74 2.29 9.04 2.33 9.48 2.37 9.70 2.40 7.72 2.44 8.26 2.48 8.61 2.52 8.91 2.56 9.34 2.60 9.56 2.63 9+18 7.44...
  • Page 62 10. Capacity Table Heat Pump Indoor Air Temp.: °CWB Combination Outdoor Capacity Index Air Temp.: (kBtu/h) °CDB 8.39 2.22 8.98 2.26 9.36 2.29 9.69 2.33 10.16 2.37 10.39 2.40 8.27 2.44 8.85 2.48 9.23 2.52 9.55 2.56 10.01 2.60 10.24 2.63 9+9+12 7.97...
  • Page 63 10. Capacity Table Heat Pump Outdoor Air Temp.: °CWB Combination Indoor Capacity Index Air Temp.: (kBtu/h) °CDB "16 "3.68 "1.49 "4.34 "1.63 "5.02 "1.78 "5.83 "1.92 "6.31 "2.02 "6.97 "2.17 3.56 1.55 4.20 1.69 4.86 1.84 5.65 1.99 6.11 2.09 6.75 2.24 3.46...
  • Page 64 10. Capacity Table Heat Pump Outdoor Air Temp.: °CWB Combination Indoor Capacity Index Air Temp.: (kBtu/h) °CDB 6.29 2.45 7.41 2.68 8.58 2.92 9.97 3.15 10.80 3.32 11.92 3.55 6.09 2.53 7.18 2.77 8.30 3.02 9.66 3.26 10.45 3.43 11.54 3.67 7+9+12 5.91...

  • Page 65: Operation Limit

    11. Operation Limits Item Range Inlet air temperature (Cooling) 43(118.4) Standard operation 21(69.8) 15(59) 24(75.2) Indoor air temperature °C W.B.(°F) Inlet air temperature (Heating) 18(64.4) Standard operation -7(14) 10(50) 24(75.2) Indoor air temperature °C D.B.(°F) Power source voltage Rating ±10% Min.

  • Page 66: Air Velocity And Temperature Distributions(Reference Data)

    12. Air Velocity and Temperature Distributions(Reference Data) 12.1 Wall Mounted Type 7k Btu/h Model Cooling Heating Discharge angle:45° Discharge angle:50° Air velocity [m/s] Air velocity [m/s] 2.7m 2.7m Temperature [˚C] Temperature [˚C] 2.7m 2.7m 12.2 ART COOL Type 12k Btu/h Model Cooling Heating Discharge angle:45°...

  • Page 67: Sound Levels

    13. Sound Levels 13.1 Indoor Unit Wall Mounted Overall Notes: - Sound measured at 1m away from the center of the unit. - Data is valid at free field condition. - Data is valid at nominal operation condition. - Reference accoustic pressure 0dB=20µPa. - Sound level will vary depending on a range of factors such as 0.8m the construction(acoustic absorption coefficient) of particular...
  • Page 68 13. Sound Levels ART COOL Overall Notes: - Sound measured at 1m away from the center of the unit. - Data is valid at free field condition - Data is valid at nominal operation condition - Reference accoustic pressure OdB = 20µPa - Sound level will vary depending on a range of factors such as 0.8m the construction(acoustic absorption coefficient) of particular...
  • Page 69 13. Sound Levels 13.2 Outdoor Unit Overall Notes: - Sound measured at 1m away from the center of the unit. - Data is valid at free field condition. - Data is valid at nominal operation condition. - Reference accoustic pressure 0dB=20µPa. Microphone - Sound level will vary depending on a range of factors such as the construction(acoustic absorption coefficient) of particular...

  • Page 70: Installation

    14. Installation 14.1 Piping Length & Refrigerant Charge The maximun allowable level and piping length [Outdoor Unit] It does not matter which unit is higher. Indoor Unit 7.5m 7.5m Model Standard Length Max piping length each indoor unit Max total [Outdoor Unit] piping length A, B, C, D...
  • Page 71 14. Installation 14.2 Select the best location 14.2.1 Indoor Unit Install the air conditioner in the location that satisfies the following conditions. Wall Mounted Type • There should not be any heat source or steam near the unit. • There should not be any obstacles to prevent the air Lower than 2.3m circulation.
  • Page 72 14. Installation 14.2.2 Outdoor Unit • If an awning or canopy is built over the unit to prevent direct sunlight or rain exposure, make sure that heat radiation from the condenser is not restricted. • Ensure that the space around the back is more than 20~30cm and sides is more than 20~30cm. The front of the unit should have more than 70cm of space.
  • Page 73 14. Installation 14.4 Connecting Pipings and the cable to Outdoor unit 14.4.1 Connecting the pipings to the Outdoor unit 1. While installing pipes, you must use the connector. 2. Align the center of the pipings and tighten the flare nut by hand Indoor Units Liquid 18k, 24k...
  • Page 74 14. Installation CAUTION: Provide a circuit breaker Main power source between power source and the unit as shown below. Circuit Breaker Conditioner Use a circuit breaker or time delay fuse. CAUTION: The power cord connected to the outdoor unit should be complied with the fol- lowing specifications (Cable type approved by HAR or SAA).
  • Page 75 14. Installation CAUTION After the confirmation of the above conditions, prepare the wiring as follows. 1. Never fail to have an individual power circuit specifically for the air conditioner. For wiring, methed take guidance from the circuit diagram posted on the inside of control cover. 2.
  • Page 76 14. Installation 14.5 Drain Pipe Work ❑ Drain pipe gradient and support 1) - The drain pipe must be fitted at a gradient of at least 1/100. - The drain pipe should be as short as possible and free from airlocks. Indoor unit Gradient of at least 1 / 100 (1cm/ 1m)

  • Page 77: Function Of Remote Controller

    15. Function of Remote Controller 15.1 Wireless LCD Remote Controller START/STOP BUTTON Operation starts when this button is pressed and Signal transmitter stops when the button is pressed again. OPERATION MODE SELECTION BUTTON Used to select the operation mode. ROOM TEMPERATURE SETTING BUTTONS Used to select the room temperature.
