aquaBUBBLER AB12 Install Manual

Pre-installation
I M P O R T A N T > > >
Location: Outdoor Indoor
S P O R T S F I E L D
Install onto :
Ground Concrete
2
Work Pad
3 Determine Plumbing Connection
Above Ground Below Ground
Installation must be in accordance with AS/NZS 3500.1 and AS/NZS 3500.2
Classic/Universal aquaBUBBLER
Unit must be installed by a Certified Plumber
Identify Water & Drainage points
4
Timber
Floor
Is an Anti-Freeze
7
Valve Required?
Where installed in
frost-prone areas,
unit must be fitted
with an Anti-Freeze
Valve. Warranty will
otherwise be void
ATTENTION PLUMBER: See next page for INSTALLATION GUIDE
Product Code: AB12/ABUA13/AB2UA14
5 Determine Orientation
Locate Keyhole OUTSIDE
Black Zone for accessibility
W a l l
C O R N E R
6
Decide Location of Inlet / Outlet
Locate Drain Outlet and
Mains Water Inlet at
back of unit (out of
view), or at either side
if necessary
Plumbing Tools Required
8
Timber boxing foundation
1
Screws and washers
2
Bag of cement
3
Socket Extension Bar
4
10 mm threaded rod and nuts
5
Flexible head ratchet wrench
6
43 mm hole saw
7
15 mm hole saw
8
10 mm socket
9
- failure to do so will void all warranties.
W A L K W A Y
Keyhole
W A L L
Do not place
Drain Outlet under
the Side Pod:
this will obstruct
wheelchair access
Front
Pod
1
2 5
4
3 6
7 8 9
1
