Operating instructions
Assembly
The product is delivered folded and
ready for transport. To place it in driving
mode, proceed as follows
Unfolding (Fig. A)
1. Loosen the lower quick-release
fastener (1).
2. Pull the lever (2) upwards and fold
the steering column (3) forwards until it
engages
3. Secure the folding mechanism by
tightening the lower quick release.
Assembling the handles (Fig. B)
1. Release the handles (4) from the
holders (5).
2. Push down the locking knobs (6) on
the handles and slide the handles on
both sides into the T-tube (7) of the
steering column. The locking knobs
must engage audibly in the provided
holes (8).
Adjusting the steering column height
(Fig. C)
The steering column can be adjusted to
four different heights. The product may
only be used if the locking button is
engaged in one of the four holes
provided and the steering column is
then secured with the quick release!
1. Release the quick-release fastener
(9) on the steering column.
2. Pull the steering column (10)
upwards until the locking button (11)
engages in one of the four holes (12).
3. Secure the steering column by
tightening the quick release.
Steering head bearing (Fig. D)
The steering head bearing is preset
when the product is delivered. If the
handlebars are too loose or become too
stiff after some time, take the product to
a specialist dealer or a bicycle shop to
have the steering head bearing
adjusted.
E
Preparing the product for transport
1. Release the quick release (Fig. C-9)
on the steering column, press the
locking button (Fig. C-11), push the
steering column all the way down, then
lock the quick release.
2. Press the locking buttons (Fig. B-
6) of the handles (Fig. B-4), pull the
handles out of the T-tube (Fig. B-7)
and secure them to the brackets (Fig.
B-5).
3. Release the lower quick release
(Fig. E-1) and pull the lever (Fig. F-2)
upwards, push the steering column
towards the deck until it engages
(Fig. F). Lock the lower quick-
release fastener (Fig. G-2).
Use
Driving, braking, parking (Fig. H)
• Place one leg on the deck (13) and
provide momentum with the other leg
by pushing off regularly.
• To brake, step on the brake plate
(14).
• Extend the support (15) for parking.
The product may only be placed on
level ground.
Maintenance
Replacing the roles
Important!
Observe the chapter "Technical data".
Rollers with a different diameter are
liable of altering the riding
characteristics and possibly cause a
hazard for the user. Do not use rollers
that cannot be properly installed.
Never install rollers which are larger
than the product´s original rollers.
Rollers are subject to wear. This wear
depends on many factors, such as the
floor, the size and weight of the user,
the weather conditions, the material of
the rollers and their hardness.
