Light intensity:
MISCELLANEOUS
Total weight
Dimensions
Max. load allowed on dental chair
Length of foot control cable
Min. space recommended for
equipment installation area
IMPORTANT
The apparatus is designed and constructed in compliance with directive 93/42/EEC and amendments, "Medical
Equipment" and with international safety standards IEC EN 60601-1 (Medical electrical equipment – General
requirements for Safety) and IEC EN 60601-1-2 (Medical electrical equipment – Collateral standard:
Electromagnetic compatibility), ISO 7494-1 (Dental units - General requirements and test methods) and ISO
6875 (Dental patient chair).
O.M.S. declines any and all responsibility for equipment safety and reliability in the following cases: if installation,
additions, re-calibration, modifications or changes are not performed by O.M.S. authorised technicians following
the instructions and using the components supplied by O.M.S. exclusively; if the electric system installed in the
workplace does not comply with IEC standards; and/or if the equipment is not used according to the operating
instructions.

2.1 ID PLATE DATA

The dental chair support features an ID plate located under the seat that shows the general data of the
equipment (see Figure 4).
B. Manufacturer
C. Rated voltage and current type (alternating )
D. Rated frequency
E. Rated current
F. Rated power
G. Equipment model
H. Cooling fluid temperature
I. Applied part, type B
J. Medical equipment directive 93/42/EEC and amendments
K. Warning: consult the annexed documentation (operating instructions).
L. Equipment serial number

3 TECHNICAL INSTRUCTIONS FOR INSTALLATION

3.1 PACKAGING

The equipment is shipped in a crate which also contains a box of accessories, instruction manual S.T. 01/3, wiring
diagrams, lamp*, lamp arm*, suction unit*, fixing screws.
(*) Supplied only if specifically requested in the purchase order.
Outside each crate a tag shows the purchase order number, the order acknowledgement number and the
equipment model.
N.B.: if an O.M.S. stool is included in the supply, this is packed separately.
8
15000-30000 Lux.
approx. 165 Kg
(see figure 19)
135 kg
2.5 m
approx. 3.20x3.00x3.00 m (LxHxD)
DUKE S.T.01/3AR rev.0 4/2011
