Quick Reference

Understanding the Operator Panel
The printer operator panel has two buttons and six lights (Continue
Lights indicate the status of the printer. Buttons are used to continue or cancel the current print job.
When the printer is turned on, all lights cycle as a self test is performed. Also, when the printer is
reset, or when a printer setting is changed in the menus, all lights cycle.
Toner Low/Replace PC Kit
Paper Jam
•
Press and release Continue
•
Press and release Continue
•
Press and release Cancel
•
Press and hold Cancel

Understanding the operator panel lights

The operator panel lights mean different things, depending on their sequence. Lights that are off, on,
and/or blinking indicate printer conditions such as printer status, intervention, or service.
Use the light sequence table to find the message being indicated, then click the message for more
information.
Cancel
to resume printing.
twice quickly to display the secondary light sequence.
to cancel the current job.
until all of the lights come on to reset the printer.
Quick Reference
1
is both a light and a button).
Continue
Ready / Data
Load / Remove Paper
Error

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E120N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lexmark E120N

Summary of Contents for Lexmark E120N

  • Page 1: Quick Reference

    Lights indicate the status of the printer. Buttons are used to continue or cancel the current print job. When the printer is turned on, all lights cycle as a self test is performed. Also, when the printer is reset, or when a printer setting is changed in the menus, all lights cycle.
  • Page 2 Other panel lights on = Other panel lights blinking = Message Ready/Power Saver Busy Resolution reduced Waiting Cancel job/Reset printer Flushing buffer Invalid engine code Not ready Printing font list or menus settings page Programming engine code or system code...

  • Page 3: Understanding The Operator Panel

    Memory full Network interface errors Host interface disabled Jam at the input sensor Jam between the input and exit sensors Jam at printer exit sensor Jam in Tray 1 / priority feeder Resource save off Short paper Toner low Long-life photoconductor kit life...

  • Page 4: Using The Printer Resident Web Page

    Using the printer resident Web page The Lexmark™ E120n has a resident Web page, which can be accessed from the browser. To access the resident Web page, type the printer’s IP address in the URL address field of the browser (for example, http://192.168.236.24).

  • Page 5: Loading Paper Or Other Print Media

    Loading paper or other print media Source Sizes Tray 1 A4, A5, JIS-B5, letter, legal, executive, folio, statement, universal 3 x 5 inch, other 7¾, 9, 10, DL, C5, B5, other Priority feeder A4, A5, JIS-B5, letter, legal, executive, folio, statement, universal 3 x 5 inch, other 7¾, 9, 10, DL, C5, B5, other...

  • Page 6: Loading Tray 1

    Loading Tray 1 Open the paper cover by lifting up until the cover clicks into a fully open position. Adjust the slide and attached backstop to the length of the selected print media. Note: To decrease width, push in on the left guide. To increase width, squeeze the tab attached to the right guide, and slide it to the right.
  • Page 7 Note: Load letterhead paper with the design side facing up and the top edge of the sheet feeding into the printer first. Load envelopes with the flap side down and the return address first. The stamp area will feed through last.

  • Page 8: Canceling A Print Job

    A print job can be canceled from the operator panel or from the computer. The Cancel job light sequence appears on the operator panel when a job is canceled (see “Cancel Job/Reset printer” on page 30 of your User’s Guide).

  • Page 9: From A Windows Computer

    A list of print jobs appears. Right-click the current document, and then click Cancel. From a Macintosh computer When a job is sent to print, the printer icon appears on the desktop. Click Applications. Click Utilities. Double-click Printer Setup Utility.

  • Page 10: Clearing Jams

    Clearing jams When a jam occurs, the printer stops, and the Error light on the operator panel blinks. To determine the location of the jam, view the secondary light sequences. Prepare the printer for jam removal by opening the paper support and removing all printed pages from the output bin. Then, follow these steps to clear the entire paper path.
  • Page 11 Open the top door, and remove any lodged print media from the paper path. CAUTION: The fuser may be hot. To avoid personal injury, use caution when opening the top door to remove a jam from the fuser area. Open the front door by sliding the release button to the left. Clearing jams...

  • Page 12: If You Need More Information

    If you need more information • Refer to the Software and Documentation CD that came with your printer for helpful information about using and maintaining your printer. • Contact your administrator or Help desk if you have questions about network printing.
