About Your Creative WebCam
Focus ring
Power LED
Front View
Power LED Lights up when your Creative WebCam is connected to your computer's USB port.
Adjusts the view focus. Point the lens toward your subject and then rotate this ring in
Focus ring
a clockwise or counterclockwise motion until the image is in focus.
Snapshot
Press it to launch WebCam Center and capture images.
button
USB cable Connect it to your computer's USB port.
Hinged lever Use this to mount your Creative WebCam on an LCD display panel.
Snapshot
button
Hinged
USB cable
lever
Side View
Figure 1
