- Page 1 3 Seater Sofa Thank you for purchasing ! Weight Limit: 600 Lb / 272 Kg DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge.
-
Page 2: Limited 1-Year Warranty
Limited 1 year Warranty Read Before Beginning Assembly We warrants this product to be free from defects in material and workmanship ●Work in a spacious area and near where the unit will be used, preferably on a and agrees to remedy any such defect. This warranty covers one year from the carpet, or use a piece of the cardboard packaging to protect your floor and product. - Page 3 PARTS...
-
Page 4: Parts List
PARTS LIST Seat Armrest Armrest 1 PC 1 PC 1 PC Back 1 PC 4 PCS Arm B and Arm C are packed insideSeat A. Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above! -
Page 5: Hardware List
HARDWARE LIST Hardware Pack (Gray Velvet) (Green Velvet) Plastic Washer M10... - Page 6 Step 1 Carefully unpack parts/hardware from the storage of the seat body and place on a clean flat surface.
- Page 7 Step 2 Place both arms (B), (C) as shown below, secure the two legs (E) and plastic washers (1) into the pre-drilled holes at the bottom of the arms. Please do not overtighten them.
- Page 8 Step 3 Carefully lift and turn upright the assembled arms (B) & (C) on their legs. Attach the seat (A) to its arms (B) & (C) by inserting the metal brackets on seat (A) into the metal glides on the arms (B) & (C) as shown below.
- Page 9 Step 4 Insert the backrest placing its ear piece metal plates on both arms’s (B) & (C) brackets as shown below. Make sure everything is placed correctly.
- Page 10 Step 5 Stretch and pull down the rear fabric cover evenly before securing it with the Velcro strip to the seat base. Repeat if necessary to achieve a better fit.
-
Page 11: Helpful Hints
Helpful Hints CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. • Move your new furniture carefully, with two people lifting and carrying the unit to its new location. - Page 12 Lea antes de comenzar a ensamblar Información sobre la garantí a • Llame a nuestro número gratuito si necesita asistencia. garantiza que este producto está libre de defectos de material y mano de obra y • Trabaje en un área espaciosa y cerca de donde su producto será utilizado, se compromete a remediar cualquier defecto de este tipo.
- Page 13 Partes Nota: Por favor no apriete completamente los pernos hastaque el ensamblaje sea completado, a menos de que se indique especí ficamente en cada paso de las IMPORTANTE: La lista de números de piezas que aparece a instrucciones. continuación es exclusiva de su producto. Por favor, manténgalo a mano cuando solicite piezas de repuesto.
-
Page 14: Consejos Útiles
Instrucciones Lí mites de peso: 600 Lb / 272 Kg Paso 1 Consejos ú tiles Desembale cuidadosamente las piezas / hardware del almacenamiento del cuerpo del asiento y colóquelas en una • Mueva sus muebles nuevos con cuidado, se requiere de dos superficie limpia y plana. -
Page 15: Informations Sur La Garantie
Merci d'avoir acheté un produit ! Informations sur la garantie Avant de commencer l'assemblage • garantit que ce produit est exempt de tout vice de matériaux et de fabrication et Si vous avez besoin d'aide, appelez notre service à la clientèlesans frais. s'engage à... - Page 16 Pièces IMPORTANT: La liste des références ci-dessous est propre à votre produit. Veuillez l'avoir sous la main lorsque vous appelez pour des pièces de rechange. Remarque: Sauf indication contraire dans les instructions, ne pas resserrer complètement les vis et les boulons, jusqu'à ce que l'assemblage soit terminé.
-
Page 17: Conseils Utiles
Instructions Limite de Poids: 600 Lb / 272 Kg Conseils utiles É tape 1 Déballez soigneusement les pièces / quincaillerie du rangement à • l’intérieur du siège et placez-les sur une surface plane et propre. Déplacez votre nouveau mobilier avec soin, nous recommandons deux personnes pour soulever et transporter le mobilier vers son nouvel emplacement.
