Samsung DV316LEW/XAA Service Manual

Samsung DV316LEW/XAA Service Manual

Clothes dryer
Hide thumbs Also See for DV316LEW/XAA:
Table of Contents

Advertisement

Quick Links

SERVICE
PRODUCT IMAGE
Refer to the service manual in the GSPN (see the rear cover) for the more information.
Get free repair and and buy Samsung appliance parts at www.Appliantology.org
CLOTHES DRYER
BASIC MODEL : DV316LEW/XAA
MODEL NAME : DV337AEW
MODEL CODE : DV337AEW/X**
THE FEATURE OF PRODUCT
1.
SUPER SIZE CAPA CITY
2.
ENERGY SAVING
3.
T IME SAVING
DV337AGW
DV337AEG
DV337AGG
DV337AEL
DV337AGL
DV337AER
DV337AGR
(FRONTIER2-PJT)
DV328AEW
DV328AGW
DV328AER
DV328AGR
(FRONTIER3-PJT)
DV337AGW/X**
DV328AEW/X**
DV328AEG/X**
DV328AER/X**
Manual

Advertisement

Table of Contents
loading

Related Manuals for Samsung DV316LEW/XAA

Summary of Contents for Samsung DV316LEW/XAA

  • Page 1 THE FEATURE OF PRODUCT PRODUCT IMAGE SUPER SIZE CAPA CITY ENERGY SAVING T IME SAVING Refer to the service manual in the GSPN (see the rear cover) for the more information. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 2: Table Of Contents

    7-1. ASSY-CONTROL ..........................7-2 7-2. ASSY-DRUM .............................7-6 7-3. ASSY-FRONT ..........................7-10 7-4. ASSY-PANEL CONTROL .......................7-14 7-5. ASSY-MOTOR / ASSY-DUCT HEATER ..................7-18 7-6. PARTS LIST (SA others) ........................7-22 7-7. PARTS LIST (SCREW TYPE) ......................7-25 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 3 12-5. COMMUNICATION PART ......................12-5 13. REFERENCE INFORMATION 13-1. MODEL NAME ..........................13-1 13-2. TERMINOLOGY ..........................13-2 13-3. CHECK THESE POINTS IF YOUR DRYER .................13-3 13-4. INFORMATION CODES .......................13-4 13-5. FABRIC CARE CHART .........................13-5 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 4: Precautions

    If water has penetrated into the dryer, this may cause electric shocks or fire. 14. Do not install the dryer where it will be exposed to bad weather. It may cause electric shocks and fire and shorten the product life. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 5: Important Safety Information

    14. Always disconnect dryer from electrical supply before attempting any service. Disconnect power cord by grasping the plug, not the cord. 15. Do not use heat to dry articles containing foam rubber or similarly textured rubberlike materials. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 6 Remove the dryer from use and call the service person. 28. Remove laundry immediately after the dryer stops. 29. ALWAYS follow the fabric care instructions supplied by the garment manufacturer. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 7 DO NOT exhaust dryer air into a window well, gas vent, chimney or enclosed, unventilated area, such as an attic, wall, ceiling, crawl space under a building or concealed space of a building. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 8 Mispolarized-The outlet is miswired so that the larger slot is hot (live) and the smaller slot is neutral. Grounded -This means the round hole con- nection is connected to ground through a Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 9: Precautions Upon Installation

    3. GAS LINES (if a gas dryer) must meet national and local codes. 4. EXHAUST SYSTEM – must be rigid metal or flexible stiff-walled metal exhaust ducting. See Exhaust Requirements. Control panel Door Adjustable leg Pipe wrench Pliers Cutting knife Nut drivers (gas only) Phillips Level Duct tape Crescent Screwdriver spanner Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 10 17.4 m (57 ft.) 10.1 m (33 ft.) 15.5 m(51 ft.) 7.6 m (25 ft.) 14.3m (47 ft.) 9.0 m (29 ft.) 12.5 m(41 ft.) 6.5 m (21 ft.) * Do not use non-metallic flexible duct. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 11 • No other fuel-burning appliance should be installed in the same closet as the dryer. • WARNING: To reduce the risk of fire, this dryer MUST BE EXHAUSTED TO THE OUTDOORS. See EXHAUST INFORMATION section. • Minimum clearances between the dryer and adjacent walls or other surfaces are: 2” in front, 17” on top, 1” on either side, and 2.375” in the back. • Closet front must have two unobstructed air openings for a combined minimum total area of 72 in² with 3” minimum clearance on the top and bottom. A louvered door with equivalent space clearance is acceptable. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 12 Outside the U.S. and Canada: • Refer to local codes. WARNING –The dryer must be exhausted to the outside to reduce the risk of fire when installed n an alcove or closet. NEVER USE PLASTIC OR NON-METAL FLEXIBLE DUCT. If your existing ductwork is plastic, non-metal, or combustible, replace it with metal. Use only metal exhaust duct that is non-flammable to ensure containment of exhaust air, heat, and lint. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 13 WARNING – Gas leaks may occur in your system, creating a dangerous situation. Gas leaks may not be detected by smell alone. Gas suppliers recommend you purchase and install a UL-approved gas detector. Install and use in accordance with manufacturer’s instructions. 1-10 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 14 The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. If a power cord is not used and the electric dryer is to be permanently wired, the dryer must be connected to a permanent grounded metal wiring system, or an equipment grounding conductor must be run with the circuit conductors and connected to the equipment grounding terminal. 1-11 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 15 NOTE: It is not permissible to convert a dryer in Canada to 208 volts. REPLACEMENT PARTS AND ACCESSORIES If your dryer requires replacement parts or accessories, contact the dealer from whom you purchased your dryer or a SAMSUNG customer care center at 1-800-SAMSUNG (726-7864). 1-12 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 16 Turn on the gas supply. Check all gas connections for leaks using a soap solution. If bubbles appear, tighten the connections and recheck. DO NOT use an open flame to check for gas leaks. 1-13 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 17 FINAL INSTALLATION CHECKLIST □ Dryer is plugged into electrical outlet and properly grounded. □ Exhaust ductwork is hooked up and joints taped. □ Plastic flexible duct is NOT used. □ Use rigid or stiff-walled flexible metal vent material. □ Dryer is level with all legs firmly on the floor. □ Gas models – gas is turned on with no gas leaks. □ Start your dryer to confirm that it runs, heats, and shuts off. 1-14 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 18 3. Keep ducts as straight as possible. 4. Clean all old ducts before installing your new dryer. Be sure vent flap opens and closes freely. Inspect and clean the exhaust system annually. Don’t let a poor exhaust system slow drying by: 1. Restricting your dryer with a poor exhaust system. 2. Using a plastic, thin foil, or non-metal flexible duct. 3. Using unnecessarily long duct runs with many elbows. 4. Allowing crushed or clogged ducts and vent. 1-15 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 19 5. Remove two screws on 9. Reassemble the holder holder lever. lever. 6. Remove one black screw 10.Reassemble the screws in from the door hinge. the remaing holes. 1-16 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 20: Product Specifications

    6. Slanted Control Panel You can see what your laundry is doing from any direction you’d like with our easy-to-read slanted control panel. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 21 Want to freshen up a garment that doesn’t need washing, but could deserve a little help after last night’s party. Our Freshen Up Cycle removes odors, adding that extra freshness to give more mileage to your clothes. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 22: Specifications Of Product

    C. Depth with A. Height 38”(96.5) 49”(124.5) door open 90° DIMENSION B. Width 27”(68.6) D. Depth 30.25” (77.0) WEIGHT 56.8kg HEATER RATING 5300W NO HEAT 268W POWER CONSUMPTION HEATING 5445W Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 23: Overview Of The Dryer

    2-3. OVERVIEW OF THE DRYER Control panel Door Adjustable leg Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 24: The Comparative Specifications Of Product

    STS Steel STS Steel Stainless/Paint coated Stainless/Paint coated Door Type Glass Transparent Glass Transparent Glass Transparent Glass Transparent Vent Exhaust 3 way 3 way 3 way 3 way Reversible Door Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 25: Option Specifications

    2-4. OPTION SPECIFICATIONS Item Item Name CODE.NO Remark MANUAL-BOOK DC68-02453A DIE-RACK DRY DC61-01522A Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 26: Overview Of The Control Panel

    Medium Low – For lower heat than Medium to dry synthetic or washable knit fabrics. Low – For heat sensitive items labeled Tumble Dry Low or Tumble Dry Warm. Extra Low – Provides the lowest heated dry temperature possible. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 27 Press once to turn your dryer on, press again to turn it off. If your dryer is left on for more than 10 minutes without any buttons being touched, the power automatically turns off. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 28: Cycle Chart

    High 40 min 35 min 5 min Manual Wrinkle Medium 25 min 20 min 5 min Release - (No Air Fluff 20 min 20 min change) Quick Dry High 30 min 25 min 5 min Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 29: Main Functions

    Then you can start My Cycle by pushing the Start/Pause button in My Cycle mode. The cycle and options you select will be displayed next time you choose My Cycle. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 30 Air Fluff Sneakers Fluff or Heat WARNING – Drying foam rubber, plastic, or rubber on a heat setting may cause damage to the item and lead to a fire hazard. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 31: Designation Of Main Components

    3-4. DESIGNATION OF MAIN COMPONENTS 3-4-1. Heater Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 32 3-4-2. Motor − − Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 33 54.83 10.031 12.687 8.277 18.62 174.24 24.69 40.16 54.88 9.995 12.688 8.222 19.03 174.69 24.51 40.17 54.82 10.049 12.688 8.233 18.57 174.34 24.06 40.08 54.93 10.057 12.687 8.225 18.89 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 34: Alignment And Adjustments

    - Sensor bar Open Over Dry excess Dry time - using Adjust time Up excessively Check for Invalid state of Eeprom EEprom Fail - PCB on EEprom communication circuit Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 35: Test Mode

    How to Enter: - To enter Special Test Mode press Signal and Temp Keys for 3 seconds for 3 seconds or until the control beep. (same for all Frontier models.) Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 36 How to Enter: - To enter Special Test Mode press While in Service Mode pressing the Signal key for 3 seconds or until the control beep. (same for all Frontier models.) Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 37 - “ t2 “ will display. - System Check Mode Progress t2 mode Function Performed Start/Pause Motor(CW) Relay On → Heater Relay On → Heater Relay Off → Motor(CW) Relay Off (Circulation) Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 38: Tools For Disassembly And Reassembly

    Tool to protect the idle and abrasion of the bolt for the Vice pliers box driver. Other(Driver, Nipper, Long nose) General tools for the after service. JIG for the Tub 1 (Disassemble and Assemble) Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 39: Disassembly

    2. Remove Top Cover 3. Remove 3 screws Fame+Plate(u) 4. Remove Wire holder Main PCB Removal 5. Remove Housings 6. Remove 1 Screw Holder PCB ► Shaking the heater terminal side ways to pull out is prohibited. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 40 ► �e care�ul o� e�ternal scratch on the console. Be careful of external scratch on the console. 1. Door Opening 2. Remove 2 Screw Frame Panel 3. Separate the temporary fi�ation part o� the assembly door. Door Removal 4. Remove 13 Screw Holder Glass Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 41 1. Be careful of the external scratch on the door cover. 2. Be careful of the damage to the door glass. 3. Check the door seal condition after the assembly. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 42 3. Remove 2 Screw Frame Front 4. Remove 4 Screw Plate(u) Frame Panel Removal 5. Remove Door Switch Housing 6. Lift the Front Panel off the three tabs across the bottom and remove ► Always wear the protective gloves. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 43 Plate(u) 3. Separate Wire in Wire Holder(2EA) 4. Disconnect Interior Light wiring Harness Front Bulkhead 5. Remove four Bulkhead retaining 5 screws. Removal 6. Disconnect Moisture Sensor wiring Harness Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 44 7. Lift Bulkhead from Cabinet and Remove 8. Removal 2 Screw Duct Outlet 9. Removal Duct Outlet Front Bulkhead Removal 10. Removal 1 Screw Touch Sensor 11. Removal Touch Sensor 12. Removal Roller Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 45 15. Removal Case Filter(B/F) ► Make sure the �elt does not get �olded to the roller. 1. Disconnect Power Supply to Unit 2. Remove Top Cover, Console, Front Panel, Plate(u),Front Bulkhead 3. Remove Belt Drum Removal 4. Remove Drum Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 46 1. Disconnect Power Supply to Unit 2. Remove Top Cover, Console, Front Panel 3. Removal 6 Housing Heater-Terminals Heater 4. Removal 1 Screw Heater Die Removal 5. Separate Heater in Drum back Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 47 3. Remove 2 screw Duct Connector 4. Separate Duct Connector Assy Motor 5. Removal 1 Housing Motor Removal 6. Removal 2 Housing Belt Cut Off Switch 7. Remove 2 Screw Motor-Bracket 5-10 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 48 9. Separate Assy Motor in Bottom Plate 10. Removal 1 Nut Fan Assy Motor Removal 11. Removal Fan 12. Removal 3 Screw Cover-Duct Fan 13. Removal 2 Spring Plate 5-11 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 49 2. Remove Top Cover, Console, Front Panel, Plate(u),Front Bulkhead,Drum 3. Remove 7 Screw Drum-Back Drum Back 4. Separate Wire in Wire Holder Removal 5. Separate Assy-Drum Back in Frame 5-12 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 50 1. Disconnect Power Supply to Unit 2. Remove 4 screw Back-Cover Duct Exhaust Removal 3. Remove 1 screw Duct-Exhaust - Reassembly procedures are in the reverse order of dissasembly procedures. 5-13 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 51: Troubleshooting

    3) As the P.C.B assembly is designed for no trouble, do not replace the P.C.B assembly by the wrong diagnosis and follow the procedure of the trouble diagnosis when the micom is not op erated normally. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 52 •� Popping or s�uealing sound. Check for a sticky or frayed belt. Popping or s�uealing sound. Check for a sticky or frayed belt. Popping or s�uealing sound. Check for a sticky or frayed belt. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 53 (Check 12P and 13P of flat wire) condition? Replace the sub PCB. Is the sub PCB normal? (Check DCpower, signal and key) The problem is in the main PCB assembly. Please replace it. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 54 1. Check whether the motor protector is operating. Is the motor normal? (Check for overload, drum constraint, centrifugal S/W etc.) The problem is in the PCB assembly. Please replace it. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 55 (Remove the power and check Is the heater normal? whether the heater coil has a resistance of about 10Ω) The problem is in the PCB assembly. Please replace it. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 56 Replace the lamp. (Check for disconnection of lamp, Is the lamp normal? socket and missed assembly) Check if the input voltage is properly coming in. 120V Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 57 (Change the contacting part and check the screw fixation) 2. Vibration of heater heat wire. (Check the fixation part of the heat wire) It is normal. Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 58: Component Testing Procedures

    2) Door switch push: On Pin# 3 and 4 Terminal : “COM” - “NC” (1-3) : ∞ Ω Terminal : “COM” - “NO” (1-2) < 1Ω 3.5Ω between Pin# 4 and 5 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 59 If resistance is infinity, replace Valve Igniter(101D) Resistance value 40~400 Ω If resistance is infinite, replace Igniter Thermostat (60T21 Hi-Limit)230F-50F Resistance value < 1 Ω If resistance is infinity, replace Thermostat Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 60 Cycling Thermostat - Disconnect harness and test Blue wire Pin 2 to Red wire Pin 6. Approx 10 K�� at 25 �C��� �� �� at 25 �C��� �� at 25 �C��� �� 6-10 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 61: Assy-Control

    7-1. ASSY-CONTROL P0001 Y0171 P0170 A0368 A0367 F0089 F0065 F0125 C0002 F0028 F0229 A0282 B0075 B0070 B0074 F0064 H0032 D0001 U0376 W0037 A0370 W0004 A0364 N0006 U0363 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 62 U0363 6502-000127 CABLE CLAMP DAWH-18NB,ID15,-,NYLON66,NTR U0376 DC97-08891A ASSY-DUCT HEATER MDE9700AYW,HEATER/5300W W0004 DC96-00764C ASSY-M.WIRE HARNESS MDE9700,LAMP/THERMAL W0037 DC96-00763A ASSY-FLAT WIRE HARNESS GR-PJT,FLAT WIRE Y0171 MFS-DV327L-00 ASSY-PCB PARTS(M) FRONTIER2 DRYER MAIN Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 63: Assy-Drum

    7-2. ASSY-DRUM Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 64 R0172 DC97-10355B ASSY-DRUM WRAPPER DV316LGW/XAA,FRONTIER U0372 DC97-07526B ASSY-DUCT OUTLET DV337AEW,DRYER/BRACKET- U0374 DC97-07521A ASSY-DUCT AIR MDE7800AYW,DRYER/ELECTRIC W0001 DC96-00766A ASSY-WIRE HARNESS GR-PJT,SUB/TOUCH SENSO Z0004 DC60-50145A NUT-HEX -,MSWR10,-,-,-,-,-,-,M10 Z0004 DC60-50145A NUT-HEX -,MSWR10,-,-,-,-,-,-,M10 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 65: Assy-Front

    7-3. ASSY-FRONT Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 66 HINGE-DOOR WF326LAW,ZNDC,T3.8,-,-,-,-,FR D0109 DC63-00789A COVER-DOOR(I) WF337AAW,ABS,-,-,-,-,-,FT2 D0113 DC97-07510B ASSY-HOLDER LEVER MDE7800AYW,DRYER/DOOR F0042 DC64-00828A DOOR-S/W GD-PJT,PA,T13.6,H38.5,W44.3,-, F0064 DC97-10353A ASSY-FRAME FRONT DV736E4/XAA,FRONTIER-DR F0103 DC61-01524A FRAME-FRONT DV736E4/XAA,SECC(EGI),-,-,WH 5-3-1 DC63-00773C COVER-DOOR(O) DV328AEW,ABS,-,-,-,-,-,WHT 7-13 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 67: Assy-Panel Control

    7-4. ASSY-PANEL CONTROL 7-14 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 68 SA/SNA Remark C0002 DC97-12627J ASSY-S.PANEL CONTROL DV328AEW/XAA,FRONTI C0002 DC97-14387A ASSY-PANEL CONTROL DV328AEW/XAA,DRYER/WH C0009 DC64-01491A WINDOW-ENCODER(O) DV337AEW/XAA,ABS,-,-,- C0029 DC97-12954C ASSY-KNOB ENCODER WF337AAW/XAA,NEW Y0172 MFS-DV318A-S0 ASSY-PCB PARTS(S) FRONTIER3 DRYER SUB 7-17 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 69: Assy-Motor / Assy-Duct Heater

    H0002 C0103 Z0051 Z0033 R0165 Z0050 H0084 H0081 H0008 H0082 H0004 A0359 H0010 U0371 Z0053 H0048 F0005 W0013 U0095 U0375 Z0039 A0369 F0005 U0376 F0005 U0369 U0163 U0370 F0228 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 70 BRACKET-THERMISTOR 27-DRYER,FN44N,-,-,-, W0035 DC32-00007A THERMISTOR N3S1-K41-S1,10K,10KOHM 25,-40 Z0033 6009-001342 SCREW-SPECIAL TH,+,-,M5,L11,ZPC(WHT),SWR Z0039 6002-000470 SCREW-TAPPING TH,+,-,1,M4,L10,ZPC(WHT),S Z0050 6002-000231 SCREW-TAPPING TH,+,-,2S,M4,L12,ZPC(WHT), Z0051 6002-000488 SCREW-TAPPING PH,+,-,2S,M3,L16,ZPC(WHT), Z0053 6021-001201 NUT-INCH LEFT TURN,3/8”-24,ZPC(YEL),MSW 7-21 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 71: Block Diagram

    8. BLOCK DIAGRAM 8-1. BLOCK DIAGRAM Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 72: Wiring Diagram

    9. WIRING DIAGRAM 9-1. ELECTRIC DRYER WIRING DIAGRAM Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 73: Gas Dryer Wiring Diagram

    9-2. GAS DRYER WIRING DIAGRAM Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 74: Reference Information

    SILVER NANO DRY CONDENSOR DRY MOTOR THERMOSTAT DOOR LOCK DOOR OPEN DOOR S/W HOT VALVE MAIN VALVE PRE VALVE DRY VALVE DRAIN MOTOR WATER HEATER STEAM HEATER DRY HEATER SPLICE Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 75: Pcb Diagram

     Make the Zerocross  Door Lock Check Micom Control the Washing Machine It Work to Change the AC to the DC Drop the Voltage Regulation for the 5V 10-1 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 76 10-2 Connector & Relay Terminal Description (Sub PBA) ①~⑫ Connects to Main PBA ①~⑬ Connects to Main PBA for the Communication. for the Communication. 10-2 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 77  Supply the Current to the Acting Current  Rotary Switch (For the Selecting a Course)  Input the Detail Course LED & Key  Display the Resent Course 10-3 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 78: Schematic Diagram

    11. SCHEMATIC DIAGRAMS * This Document can not be used without Samsung’s authorization. 11-1 MAIN PCB 11-1 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
  • Page 79 * This Document can not be used without Samsung’s authorization. 11-2 SUB PCB 11-2 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 80: Circuit Descriptions

    12. CIRCUIT DESCRIPTIONS 12-1. OVERALL SYSTEM DIAGRAM COMMUNICATION PART SENSING PART POWER SUPPLY PART DRIVING PART 12-1 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 81: Power Supply Part

    12-2. POWER SUPPLY PART ► FUNCTION - 15V DC is generated by 16V AC reduced from LVT1 through Bridge Diode. - The 5V DC is supplied to Micom through IC5. ► DESCRIPTION - DC Voltage is generated by AC input through Bridge Diode. - The AC input is Checked by TR2. - A constant 5V is output at the IC5 output terminal. - The door and motor are Checked by PC1, PC2 12-2 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 82: Driving Part

    12-3. DRIVING PART ► FUNCTION - Control the electrical harness parts of the set. ► DESCRIPTION - MICOM sends a high signal to the port of the target harness to operate. - If a high signal enters as IC1 input, the output terminal decreases. - At this time, a relay operates to supply power to the target harness. - EEPROM offers the fuction that IC4 memorizes the course Where the machine was working after electricity failure. 12-3 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 83: Sensing Part

    12-4. SENSING PART ► FUNCTION - Check the heat by the output of Thermistor - Check the drying grade using a humidity sensor. ► DESCRIPTION - IC7 checks the drying grade comparing the value of humidity sensor with its default value. - It controls the temperature of the heater by the output of thermistor. 12-4 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 84: Communication Part

    12-5. COMMUNICATION PART ► FUNCTION - Communications circuit for controlling the display of the SUB PCB. - Control circuit for the encoder and switch of the SUB PCB. ► DESCRIPTION - Input/Output ports of the MICOM for controlling the LED, display, and switch of the SUB PBA. 12-5 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 85: Reference Information

    13. REFERENCE INFORMATION 13-1. MODEL NAME 13-1 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 86: Terminology

    (installed on the drying duct) is automatically activated to disconnect the power for your or product’s safety CHILD LOCK → Prevents children from playing with the washing machine. 13-2 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 87: Check These Points If Your Dryer

    • Dryer load is too small. Add more items or a few towels and restart the cycle. load is dry • Dryer load is too large. Remove some items and restart the dryer. 13-3 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 88: Information Codes

    If problem When the door is open, the dryer continues, call for service. See will not operate. below. - For any codes not listed above, call 1-800-726-7864 (1-800-SAMSUNG). 13-4 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...

  • Page 89: Fabric Care Chart

    Hot is 105° –125° F/ 41° – 52° C, for Warm 85° – 105° F/29° – 41° C and for Cold 60° – 85° F/16° – 29° C. (Wash water temperature must be a minimum of 60° F/16° C for detergent activation and effective cleaning.) 13-5 Get free repair and and buy Samsung appliance parts at www.Appliantology.org...
