Summary of Contents for Samsung DV328
-
Page 1: User Manual
Gas and Electric Dryer imagine Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/global/register DV337AEW-02453A-04_EN.indd 1 user manual the possibilities DV337 DV328 2007-07-23 ¿ÀÈÄ 1:47:14... -
Page 2: Energy Saving
44 minutes! Giving you time for more important things in life. 5. Energy Saving Samsung dryers are super energy efficient, using only 3.01 kWh per pound of laundry. Also, both the large capacity and Fuzzy Logic Control save energy by automatically drying your clothes the most efficient way. -
Page 3: Safety Instructions
Congratulations on your new Samsung Dryer. This manual contains valuable information on the installation, use, and care of your appliance. Please take the time to read this manual to take full advantage of your dryer’s many benefits and features. - Page 4 Do not sit on top of the dryer. Because of continuing product improvements, Samsung reserves the right to change specifications without notice. For complete details, see the Installation Instructions packed with your product before selecting cabinetry, making cutouts, or beginning installation.
- Page 5 Gas leaks may occur in your system, resulting in a dangerous situation. WARNING Gas leaks may not be detected by smell alone. Gas suppliers recommend you purchase and install a UL-approved gas detector. Install and use in accordance with the manufacturer’s instructions. Do not place items in your dryer that have been spotted or soaked with vegetable oil or cooking oil.
-
Page 6: Table Of Contents
contents INSTALLING YOUR DRYER OPERATING INSTRUCTIONS, TIPS CARE AND CLEANING SPECIAL LAUNDRY TIPS TROUBLESHOOTING 6_ Contents DV337AEW-02453A-04_EN.indd 6 Tools needed for installation See Exhaust Requirements Ducting requirements Important to installer location considerations Alcove or closet installation Mobile home installation Exhausting Gas requirements Electrical requirements Grounding... -
Page 7: Installing Your Dryer
installing your dryer TOOLS NEEDED FOR INSTALLATION Hire a professional to install this dryer properly. If there is a service call performed as a result of poor setup, adjustment, and connection, it is considered the responsibility of the installer. If you install the dryer you are responsible. -
Page 8: Ducting Requirements
installing your dryer DUCTING REQUIREMENTS • Use a 4-inch (10.2 cm) diameter rigid aluminum or rigid galvanized steel duct. • Do not use a smaller duct. • Ducts larger than 4 inches (10.2 cm) in diameter can result in increased lint accumulation. Lint accumulation should be cleaned regularly. -
Page 9: Important To Installer
If the new dryer is installed into an existing exhaust system you must make sure: • The exhaust system meets all local, state, and national codes. • That a flexible plastic duct is not used. • To Inspect and clean all lint buildup from inside the existing duct. •... -
Page 10: Mobile Home Installation
A minimum of 72 in² (183 cm²) of unobstructed space is required. Call 1-800-SAMSUNG for information on purchasing the Floor Anchoring Kit as an accessory. All mobile home installations must be exhausted to the outside with the exhaust duct termination securely fastened to the mobile home structure, using materials that will not support combustion. -
Page 11: Gas Requirements
GAS REQUIREMENTS Use only natural or LP (liquid propane) gases. THE INSTALLATION MUST CONFORM WITH LOCAL CODES, OR IN THE ABSENCE OF LOCAL CODES, WITH THE NATIONAL FUEL GAS CODE ANSI/Z223.1, LATEST REVISION (FOR THE UNITED STATES), OR WITH THE CAN/CGA-B149 INSTALLATION CODES (FOR CANADA). Gas dryers are equipped with a burner vent for use with natural gas. -
Page 12: Electrical Requirements
installing your dryer ELECTRICAL REQUIREMENTS Wiring diagram is located on plate below the control panel. • Improper connection of the equipment grounding conductor can result in a risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether your dryer is WARNING properly grounded. -
Page 13: Electrical Connections
It is not permissible to convert a dryer in Canada to 208 volts. REPLACEMENT PARTS AND ACCESSORIES If your dryer requires replacement parts or accessories, contact the dealer from whom you purchased your dryer or the SAMSUNG customer care center at 1-800-SAMSUNG (726-7864). DV337AEW-02453A-04_EN.indd 13 Installing your dryer _13... -
Page 14: Installation
installing your dryer INSTALLATION For proper installation, it is highly recommended to hire a professional. To install: 1. Move your dryer to an appropriate location for installation. Consider installing the dryer and washer side- by-side, to allow access to gas, electrical, and exhaust connections. Lay two of the carton cushion-tops on the floor. -
Page 15: Final Installation Checklist
3-WIRE system connections 1. Loosen or remove the center terminal block screw. 2. Connect the neutral wire (white or center wire) of the power cord to the center, silver-colored terminal screw of the terminal block. Tighten screw. 3. Connect the other wires to outer terminal block screws. Tighten screws. 4. -
Page 16: Dryer Exhaust Tips
installing your dryer DRYER EXHAUST TIPS Plastic or non-metal flexible duct presents a potential fire hazard. WARNING 1. Let your dryer exhaust the air easily. 2. Use 4” diameter rigid metal duct. Tape all joints, including at the dryer. Never use lint-trapping screws. 3. -
Page 17: Door Reversal
DOOR REVERSAL 1. Unplug the power cord. 2. Remove two door hinge screws. 3. Lift the door and remove from the dryer. 4. Remove a screw on the Frame Front 5. Remove two screws on the opposite side of the door hinge. -
Page 18: Operating Instructions, Tips
operating Instructions, tips OVERVIEW OF THE CONTROL PANEL The display window shows the estimated time remaining in the cycle after the Start/Pause button is pressed. The estimated time remaining may fluctuate as the cycle progresses. The Drying light will illuminate and remain lit until the cycle is complete. When your dryer is in the cool-down phase, the Cooling light will illuminate. - Page 19 When using Manual Dry cycles, time can be adjusted by pressing the time selection button. Time Selection Button During the Sensory Dry cycle, the time light indicator is off because exact drying times are determined by fluctuating humidity levels. When the cycle is complete, a chime will sound. When the Wrinkle Prevent option is selected, the chime will sound intermittently.
-
Page 20: Child Lock
operating Instructions, tips CHILD LOCK A function to prevent children from playing with your dryer. Setting/Releasing If you want to set or release the Child Lock, press both the Time and Signal buttons simultaneously for 3 seconds. How to Set: 1. -
Page 21: Rack Dry
RACK DRY Installing the drying rack 1. Open the dryer door. 2. Position the drying rack in the tumbler, placing the rear legs in the two recessed areas of the dryer’s back wall. 3. Place the front lip of the drying rack on top of the lint filter. 4. -
Page 22: Clean The Lint Filter
operating Instructions, tips CLEAN THE LINT FILTER • After each load. • To shorten drying time. • To operate more energy efficiently. Do not operate your dryer without the lint filter in place. LOAD THE DRYER PROPERLY • Place only one washload in your dryer at a time. •... -
Page 23: Care And Cleaning
care and cleaning CONTROL PANEL Clean with a soft, damp cloth. Do not use abrasive substances. Do not spray cleaners directly on the panel. The control panel finish may be damaged by some laundry pre-treatment soil and stain remover products. Apply such products away from your dryer and wipe up any spills or overspray immediately. -
Page 24: Special Laundry Tips
special laundry tips Please follow the care label or manufacturer’s instructions for drying special items. If care label instructions are not available, use the following information as a guide. Bedspreads & Comforters Blankets Curtains & Draperies Cloth Diapers Down–filled Items (jackets, sleeping bags, comforters, etc.) Foam Rubber (rug backs,... -
Page 25: Troubleshooting
troubleshooting CHECK THESE POINTS IF YOUR DRYER… PROBLEM doesn’t run. doesn’t heat. doesn’t dry. is noisy. DV337AEW-02453A-04_EN.indd 25 SOLUTION • Be sure the door is latched shut. • Be sure the power cord is plugged into a live electrical outlet. •... -
Page 26: Information Codes
Door open sensing problem. Door open error When the door is open, the dryer will not operate. For any codes not listed above, call 1–800–726–7864 (1–800–SAMSUNG) 26_ Troubleshooting DV337AEW-02453A-04_EN.indd 26 • Seams, pockets, and other similarly heavy areas may not be completely dry when the rest of the load has reached the selected dryness level. -
Page 27: Appendix
appendix FABRIC CARE CHART The following symbols provide garment care direction. The Clothing care labels include symbols for washing, bleaching, drying and ironing, or dry cleaning when necessary. The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow care label directions to maximize garment life and reduce laundering problems. -
Page 28: Protecting The Environment
appendix PROTECTING THE ENVIRONMENT This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected to a power source. Remove the door so that animals and small children cannot get trapped inside the appliance. -
Page 29: Cycle Chart
CYCLE CHART Cycle Normal Heavy Duty Sensor Dry Towels Perm Press Delicates Freshen Up Time Dry Manual Dry Wrinkle Release Air Fluff DV337AEW-02453A-04_EN.indd 29 Default Temp Sensor dry Time control level High Normal dry 44 min (Medium) High (No Normal dry 60 min change) High... - Page 30 Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will provide in-home service during the warranty period at no charge, subject to availability within the contiguous United States.
- Page 31 SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
- Page 32 QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT U.S.A 1-800-SAMSUNG (7267864) www.samsung.com Code No. DC68-02453A-04_EN DV337AEW-02453A-04_EN.indd 32 2007-07-23 ¿ÀÈÄ 1:48:05...
