Electric Dryer

Owner's Manual
Register your product at
www.samsung.com/global/register
Code No.: DC68-02347B-05_EN

Advertisement

   Related Manuals for Samsung DC68-02347B-05

   Summary of Contents for Samsung DC68-02347B-05

  • Page 1: Electric Dryer

    Electric Dryer Owner’s Manual Register your product at www.samsung.com/global/register Code No.: DC68-02347B-05_EN...

  • Page 2: Energy Saving

    44 minutes! Giving you time for more important things in life. Energy Saving Samsung dryers are super energy efficient, using only 3.01 kWh per pound of laundry. And both the large capacity and Fuzzy Logic Control save energy by automatically drying your clothes the most efficient way.

  • Page 3: Safety Precautions

    Congratulations on your new Samsung Dryer. This manual contains valuable information on the installation, use, and care of your appliance. Please take the time to read this manual to take full advantage of your dryer’s many benefits and features. What you need to know about Safety Instructions Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur.

  • Page 4

    9. Do not use fabric softeners or products to eliminate static unless recommended for dryer use by the manufacturer of the fabric softener or product. 4 SAMSUNG Dryer Owner’s Instructions SAVE THESE INSTRUCTIONS...

  • Page 5

    14. Do not sit on top of the dryer. NOTE: Because of continuing product improvements, Samsung reserves the right to change specifications without notice. For complete details, see the Installation Instructions packed with your product before selecting cabinetry, making cutouts, or beginning installation.

  • Page 6: Table Of Contents

    Table of Contents Installation Instructions ..........A-1 Tools needed for installation .

  • Page 7: Installation Instructions

    2. EXHAUST SYSTEM – must be rigid metal or flexible stiff-walled metal exhaust ducting. See Exhaust Requirements. Control panel Door Pliers Cutting knife Level Screwdriver (standard) Installation Instructions Adjustable leg Pipe wrench (gas only) Duct tape SAMSUNG Dryer Owner’s Instructions Nut drivers Crescent spanner...

  • Page 8: Ducting Requirements

    24.4 m (80 ft.) 20.7 m (68 ft.) 17.4 m (57 ft.) 14.3m (47 ft.) * Do not use non-metallic flexible duct. A-2 SAMSUNG Dryer Owner’s Instructions ELECTRIC AND GAS DRYER Weather Hood Type Use only for short-run installation 2.5” (6.35 cm)

  • Page 9: Important To Installer

    Closet front must have two unobstructed air openings for a combined minimum total area of 72 in² with 3” minimum clearance on the top and bottom. A louvered door with equivalent space clearance is acceptable. Installation Instructions SAMSUNG Dryer Owner’s Instructions A-3...

  • Page 10: Mobile Home Installation

    A minimum of 72 in² (183 cm² ) of unobstructed space is required. Call 1-800-SAMSUNG for information on purchasing the Floor Anchoring Kit as an accessory. All mobile home installations must be exhausted to the outside with the exhaust duct termination securely fastened to the mobile home structure, using materials that will not support combustion.

  • Page 11: Electrical Conne Ctions

    REPLACEMENT PARTS AND ACCESSORIES If your dryer requires replacement parts or accessories, contact the dealer from whom you purchased your dryer or the SAMSUNG customer care center at 1-800-SAMSUNG (726-7864). INSTALLATION Parts and literature are packaged inside your dryer drum. To install: 1.

  • Page 12: Dryer Exhaust Tips

    1. Restricting your dryer with a poor exhaust system. 2. Using a plastic, thin foil, or non-metal flexible duct. 3. Using unnecessarily long duct runs with many elbows. 4. Allowing crushed or clogged ducts and vent. A-6 SAMSUNG Dryer Owner’s Instructions...

  • Page 13: Door Reversal

    7. Reassemble the screw (Step 4) on the Frame Front 8. Place the door on the other side and reattach it to the dryer. 9. Reassemble the holder lever. 10. Reassemble the screws in the remaing holes. SAMSUNG Dryer Owner’s Instructions A-7...

  • Page 14: Operating Instructions, Tips

    Operating Instructions, Tips Control Features vary by model.  OVERVIEW OF THE CONTROL PANEL B-1 SAMSUNG Dryer Owner’s Instructions...

  • Page 15

    The indicator light above the pad will illuminate when Wrinkle Prevent is selected. Chasing lights appear in the display when the Wrinkle Prevent option is selected. The load is dry, and can be removed at any time during the Wrinkle Prevent cycle. SAMSUNG Dryer Owner’s Instructions B-2...

  • Page 16

    Power Button Press once to turn your dryer on, press again to turn it off. If your dryer is left on for more than 10 minutes without any buttons being touched, the power automatically turns off. B-3 SAMSUNG Dryer Owner’s Instructions...

  • Page 17: Child Lock

    My Cycle. Note : You can change My Cycle setting by repeating same process above. The last used setting will be displayed at next time you choose My Cycle. SAMSUNG Dryer Owner’s Instructions B-4...

  • Page 18: Rack Dry(select Models

    Foam rubber pillows Sneakers WARNING – Drying foam rubber, plastic, or rubber on a heat setting may cause damage to the item and lead to a fire hazard. B-5 SAMSUNG Dryer Owner’s Instructions SUGGESTED TEMP. SETTINGS Heat (Low/Extra Low) Heat (Low/Extra Low) Air Fluff...

  • Page 19: Clean The Lint Filter

    When the cycle is complete, the Door Lock light will go out and “End” will appear in the display. • Pressing Power cancels the cycle and stops your dryer. • The Drying, Cooling, and Wrinkle Prevent indicator lights will illuminate during those portions of the cycle. SAMSUNG Dryer Owner’s Instructions B-6...

  • Page 20: Care And Cleaning

    Clean with a soft, damp cloth. Do not use abrasive substances. Protect the surface from sharp objects. Dryer Exhaust System Should be inspected and cleaned yearly to maintain optimum performance. The outside exhaust hood should be cleaned more frequently to ensure proper operation. C-1 SAMSUNG Dryer Owner’s Instructions...

  • Page 21: Things To Avoid

    fluff the item. DO NOT dry kapok or foam pillows in dryer. Use the Air Fluff cycle or the Time Dry cycle and the Low or Extra Low temperature setting depending on the care label instructions. SAMSUNG Dryer Owner’s Instructions D-1...

  • Page 22: Troubleshooting

    • Dryer load is too small. Add more items or a few towels and restart the cycle. before load • Dryer load is too large. Remove some items and restart the dryer. is dry E-1 SAMSUNG Dryer Owner’s Instructions...

  • Page 23: Information Codes

    Door open sensing problem. Door open error When the door is open, the dryer will not operate. For any codes not listed above, call 1-800-726-7864 (1-800-SAMSUNG). Troubleshooting Solution Call for service. See below. Call for service. See below. Be sure the door is latched shut. If problem continues, call for service.

  • Page 24: Appendix

    Hot is 105° –125° F/ 41° – 52° C, for Warm 85° – 105° F/29° – 41° C and for Cold 60° – 85° F/16° – 29° C. (Wash water temperature must be a minimum of 60° F/16° C for detergent activation and effective cleaning.) F-1 SAMSUNG Dryer Owner’s Instructions Appendix Special Instructions...

  • Page 25: Protecting The Environment

    Appendix FRONT LOADING DRYER Inches (cm) 38” (96.5) C. Depth with door open 90° 27” (68.6) D. Depth 56.8 kg 5300 W NO HEAT HEATING SAMSUNG Dryer Owner’s Instructions F-2 Inches (cm) 49” (124.5) 30.25” (77.0) 268 W 5445 W...

  • Page 26: Cycle Chart

    Freshen Up High (No change) Time Dry High Wrinkle Medium Release Air Fluff - (No change) Quick Dry High F-3 SAMSUNG Dryer Owner’s Instructions Appendix Default Sensor dry Time level Normal dry 44 min Normal dry 60 min Normal dry...

  • Page 27

    Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will provide in-home service during the warranty period at no charge, subject to availability within Canada.

  • Page 28

    NO WARRANTY OR GUARANTEE GIVEN BY ANY PERSON, FIRM, OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

  • Page 29

    Memo SAMSUNG Dryer Owner’s Instructions F-6...

  • Page 30

    Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Samsung Electronics Canada, Inc. 1-800-SAMSUNG (726-7864) www.samsung.ca...
