Celestron 22010 Instructions Manual

Telescope Instructions
1
To setup the tripod unfold the legs by pulling
them apart until the center support bracket
locks in place.
4
To attach the finderscope, start by removing the
two nuts located on the top of the telescope
tube. Place the finderscope bracket over the
two exposed threaded posts. Secure it in place
by replacing the two nuts. Be sure the eyepiece
end of the fi nderscope faces the same direction
as the eyepiece of the scope.
7
Point the telescope at a distant target by sighting
through the finderscope.
Binocular Instructions
1
Adjust the binoculars to fit the distance between
your eyes by grasping each side of the binocular and
rotating the barrels closer together or further apart
as needed. You should see one round image when
looking through the binoculars with both eyes.
2
To adjust the height of the tripod, fl ip the lever
at the bottom of the tripod leg. Slide the inner
portion of the leg out to the desired height and
secure the leg by fl ipping the lock lever.
5
Loosen the set screw on the back of the focusing
assembly and insert the star diagonal. Secure the
diagonal in place by tightening the set screw on
the focus assembly.
8
Look through the eyepiece of the main telescope
to see your target up close. Focus the image by
turning the two knobs on the focusing assembly
until you get a sharp image.
2
To focus, rotate the focusing wheel between the
two barrels until the image is sharp.
3
To attach the optical tube to the tripod, start by
threading the mounting bolt at the top of the
tripod into the threaded hole on the bottom of
the telescope tube.
6
Loosen the set screw on the star diagonal and insert
10mm (60x) eyepiece. Secure the eyepiece in place
by tightening the set screw on the star diagonal.
#22010
