- Page 1 Quick Installation Guide 4K HD-TVI, AHD, HDCVI, CVBS, to HDMI, VGA, CVBS, indoor MAM-5MM2203M0A...
-
Page 2: Table Of Contents
Table of Contents Package Includes................................4 Installation Guide ......................5 Panel View ........................7 Description 1 – LED Indicator ..........................7 Description 2 – Installation and Cabling ......................8 Description 3 – Video Format & Resolutions ......................8 Description 4 – OSD Settings ..........................9 Installation Diagram ....................10 Further information ...............................11... - Page 3 Safety instructions General safety instructions • Before switching on and operating the system, first read this safety advice and the operating instructions. • Keep the operating instructions in a safe place for later use. • Installation, commissioning and maintenance of the system may only be carried out by authorised individuals and in accordance with the installation instructions - ensuring that all applicable standards and guidelines are followed.
-
Page 4: Package Includes
Important points of warning are marked with a caution symbol. Important points of advice are marked with a notice symbol. Package Includes • MAM-5MM2203M0A x 1pcs • DC12V 500mA power adapter x 1pcs • SMT Self-tapping Screw x 4pcs • Wall Plug x 4 pcs... -
Page 5: Installation Guide
Installation Guide Install On A Table Or A Wall Step 1: Evenly fix SMT screws on a platform and leave a 2mm high clearance. Step 2: Place MAM-5MM2203M0A on the platform and fit its holes in the corresponding screw positions. - Page 6 Step 3: Move MAM-5MM2203M0A until it gets fixed. Use Rubber Pads to Prevent the Product from Slipping down The Platform Fix each rubber pad at each corner of the product.
-
Page 7: Panel View
Panel View Interface Description Power LED To indicate power status (Refer to Description 1). Camera 1 LED To indicate Camera 1 status (Refer to Description 1). Camera 2 LED To indicate Camera 2 status (Refer to Description 1). To control OSD menu (Refer to Description 4). Audio To use a 3.5mm audio cable to connect an audio source from a HD-TVI, AHD, HDCVI camera (Refer to Description 2). -
Page 8: Description 2 - Installation And Cabling
Description 2 – Installation and Cabling 1. Avoid being in areas with electrical interferences, such as mobile phones, micro- waves and so on, when installing your AD001HD4-4K. 2. Remove the power before installation. 3. Audio Input • If connecting to a camera with a built-in microphone, AD001HD4-4K can only output the video source. -
Page 9: Description 4 - Osd Settings
Video Output Format & Resolutions Resolution HDMI CVBS 4K2K 30/ 25Hz 2160p 30/ 25Hz 1080p 60/ 50Hz 60/ 50Hz 1080i 60/ 50Hz 60/ 50Hz 720p 60/ 50Hz 60/ 50Hz 576p 60Hz 60Hz 480p 60Hz 60Hz NTSC When HDMI/ VGA resolution is set to •... -
Page 10: Installation Diagram
Installation Diagram 1 in 4 out Mode (HDMI, VGA, CVBS output at the same time) 2 in 2 out Mode (Dual cameras with PIP) 2 in 3 out Mode (Dual cameras with manual switching Cam 1/ 2) -
Page 11: Further Information
Further information The manual is also available from the eneo web site at www.eneo-security.com. - Page 12 VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
