  • Page 1 EN 21" 3-in-1 GAS PUSH LAWN MOWER FR 21" 3-in-1 TONDEUSE A GAZON A PROPULSION DE GAZ ES 21" 3-en-1 CORTADORA DE CÉSPED A GASOLINA Model # DB8621PH Have product questions or need technical support? Please feel free to contact us! Toll free: 1-800-791-9458Mon-Fri9-5 EST...
  • Page 3: Table Of Contents

    Operation……………………..………………………………………… 13 Maintenance……………………………………………………………... Storage……………………………………………………………………. 19 Troubleshooting…………………………………………………………. Exploded view & parts list……………………………………………… Warranty………………………………………………………………… TECHNICAL DATA 21" 3-in-1 Gas Push Lawn Mower Model # DB8621PH Engine type: 4 Stroke, OHV, single cylinder with forced air-cooling system Displacement: 209cc Fuel tank capacity: 0.24 Gallon Oil capacity: 16.9 fl.oz...
  • Page 4: Introduction

    INTRODUCTION Thank You for Purchasing a PowerSmart ® Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the information in this manual. PowerSmart ® reserves the right to change this product and specifications at any time without prior notice.
  • Page 5: General Safety Procedures

    GENERAL SAFETY PROCEDURES For any questions regarding the hazard and safety notices listed in this manual or on the product, please call (800) 791-9458 Mon-Fri 9-5 EST before using the engine. DANGER: CARBON MONOXIDE Using an engine indoors CAN KILL YOU IN MINUTES. Engine exhaust contains carbon monoxide (CO).
  • Page 6: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death. I.General Operation 1. Read, understand, and follow instructions and warnings in this manual and on the machine, engine and attachments.
  • Page 7 4. Always keep the machine in gear when going down slopes. Do not coast downhill. 5. Avoid starting and stopping on slopes. Avoid making sudden changes in speed or direction. Make turns slowly and gradually. 6. Use extra care while operating machine with a grass catcher or other attachment(s). They can affect the stability of the machine.
  • Page 8: Warning Label Instructions

    WARNING LABLE INSTRUCTIONS Read carefully the manual before use. Danger-flying objects; keep safe distance from the machine as long as the engine is running. Do not open or remove safety shields while engine is running. Pay more attention to the operator’s hands and feet to avoid injury. Do not open or remove safety shields while engine is running.
  • Page 9 Look behind while backing Steep slope hazard When repairing, please pull off the spark plug boot, then repair it according to the operational manual Hot surfaces When mowing,please wear the glasses ad ear plugs to defend the operator himself Keep bystanders away. Safety label found on the lawn mower: KEEP HANDS AND FEET AWAY.
  • Page 10: Knowing Your Lawn Mower

    KNOWING YOUR LAWN MOWER Please use the illustration below to familiarize yourself with the location and function of the components that control of your lawn mower. Recoil starter handle Oil dipstick Grass catcher Fuel tank cap Cutting height adjustment lever Rear discharge door Rear wheel Lower handle...
  • Page 11: Lawn Mower Preparation

    LAWN MOWER PREPARATION The following section describes steps necessary to prepare the lawn mower for use. If after reading this section, you are unsure about how to perform any of the steps please call (800) 791-9458 Mon-Fri 9-5 EST for customer service.
  • Page 12 3. Lock the cable to the lower handle using cable clip. Cable Clip 4. Insert the recoil starter handle cable into the hook provided on the upper handle. You must engage the start/stop control to release the recoil starter handle. Start/Stop Control Recoil starter handle SIDE DISCHARGE CHUTE...
  • Page 13: Operation

    ADJUSTING THE CUTTING HEIGHT Warning! Cutting height adjustments should only be performed after the engine and blades have come to a complete stop! It is always best to begin cutting your lawn with a higher deck height to prevent scalping your lawn. The cutting height is adjusted with front and rear levers.
  • Page 14 Adding Gasoline Remove the fuel tank cap and check fuel level. If the level is too low, refuel the tank, remember adding fuel not over the fuel upper level. Warning: 1. Gasoline is extremely flammable and is explosive under certain conditions. 2.
  • Page 15 engine has started up. When the engine start/stop Control is released, the engine must stop within a few seconds. If not, contact Customer Service. Warning: The blade begins to rotate as soon as the engine is started. START THE ENGINE To start the engine, perform the following steps: 1.
  • Page 16: Maintenance

    Caution: Do not remove side discharge cover at any time. USING AS A REAR BAGGER To use the grass catcher to collect clippings while you are operating the mower. 1. Attached grass catcher following instruction in the lawn mower preparation. Grass clippings will automatically collect in bag as you run the mower.
  • Page 17 Warning: Never tip the mower more than 90° in any direction and do not leave the mower tipped for any length of time. Oil can drain into the upper part of the engine causing a starting problem. MOWER BLADE To ensure safe operation, have all blade sharpening, balancing and mounting work carried out by an authorized service center.
  • Page 18 5. If necessary, replace the paper element. 6. Reinstall the sponge-like element in the air cleaner casing and reinstall the cover. CAUTION: running the engine with dirty, damaged or missing air cleaner element will cause the engine to wear out prematurely. SPARK PLUG MAINTENANCE The spark plug is important for proper engine operation.
  • Page 19: Storage

    STORAGE CAUTION: Never place any type of storage cover or tarp on the MOWER while it is still hot. If the MOWER is being stored for extended periods of time (30 days or more), drain fuel tank and carburetor bowl. When storing the mower for extended periods of time: 1.
  • Page 20: Exploded View & Parts List

    EXPLODED VIEW AND PARTS LIST...
  • Page 21 Item Stock # Description Item Stock # Description 9999960903 Engine 303071037 21 inch Blade 303090094 Gear box seat 303181407 Blade connector 303100100 Bearing 203052967 Belt cover 303160961 Left hand bevel gear 303110049 Square Key 303020240 Bolt 303060169 Multi wedge pulley 303042005 Flat washer 302040092...
  • Page 22 ENGINE EXPLODE VIEW AND PART LIST...
  • Page 23 Item Stock# Description Item Stock# Description 303020444 Bolt M6X12 303020608 Bolt CRANKCASE COVER, 9020960902 Cylinder head assembly 9563960902 LEFT 9142960901 Rocker arm shaft 303100072 6205 bearing 9230960902 ROCKER ARM 9198960101 Oil filler gauge 303020444 Bolt M6X12 9158960901 CAM SHAFT 9142960902 Rocker shaft baffle 9564960901 Piston ring assembly...
  • Page 24: Warranty

    To make a claim under this Limited Warranty, you must return the entire power tool product; transportation prepaid, to PowerSmart. The owner must include a legible copy of the original receipt, which shall list the date of purchase, along with the company’s name where the product was purchased.
