INSTRUCTION MANUAL
EN 17" 3-in-1 Gas Push Lawn Mower
FR 17" 3-in-1 Tondeuse A Gazon A Propulsion de Gaz
ES 17" 3-en-1 CORTADORA DE CÉSPED A GASOLINA
Model # DB8617P
Have product questions or need technical support? Please feel free to contact us!
Website:
www.Amerisuninc.com
www.powersmartusa.com
Toll free: 1-800-791-9458 Mon-Fri 9-5 EST
Email: support@amerisuninc.com
1
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Powersmart DB8617P
Summary of Contents for Powersmart DB8617P
- Page 1 EN 17" 3-in-1 Gas Push Lawn Mower FR 17" 3-in-1 Tondeuse A Gazon A Propulsion de Gaz ES 17" 3-en-1 CORTADORA DE CÉSPED A GASOLINA Model # DB8617P Have product questions or need technical support? Please feel free to contact us! Website: www.Amerisuninc.com...
-
Page 3: Table Of Contents
Maintenance……………………………………………………………... Storage……………………………………………………………………. 21 Troubleshooting…………………………………………………………. Exploded view & parts list……………………………………………… Warranty………………………………………………………………… TECHNICAL DATA 17" 3-in-1 Gas Push Lawn Mower Model # DB8617P Engine type: 4 Stroke, OHV, single cylinder with forced air-cooling system Displacement: 127cc Fuel tank capacity: 0.21Gallon Oil capacity: 16.9 fl.oz... -
Page 4: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of ® the information in this manual. PowerSmart reserves the right to change this product and specifications at any time without prior notice. -
Page 5: General Safety Procedures
GENERAL SAFETY PROCEDURES For any questions regarding the hazard and safety notices listed in this manual or on the product, please call (800) 791-9458 Mon-Fri 9-5 EST before using the engine. DANGER: CARBON MONOXIDE Using an engine indoors CAN KILL YOU IN MINUTES. Engine exhaust contains carbon monoxide (CO). -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death. I.General Operation 1. Read, understand, and follow instructions and warnings in this manual and on the machine, engine and attachments. - Page 7 V. SLOPE SPECIFIC Slopes are a major factor related to accidents. Operation on slopes requires extra caution. 1. Travel in the manufacturer recommended direction on slopes. Use caution while operating near drop offs. 2. Avoid mowing wet grass. (Poor footing could cause a slip and fall accident.) 3.
-
Page 8: Warning Label Instructions
WARNING LABLE INSTRUCTIONS Read carefully the manual before use. Danger-flying objects; keep safe distance from the machine as long as the engine is running. Do not open or remove safety shields while engine is running. Pay more attention to the operator’s hands and feet to avoid injury Do not open or remove safety shields while engine is running. - Page 9 Look behind while backing Steep slope hazard When repairing, please pull off the spark plug boot, then repair it according to the operational manual Hot surfaces When mowing,please wear the glasses ad ear plugs to defend the operator himself Keep bystanders away. Safety label found on the lawn mower: KEEP HANDS AND FEET AWAY.
-
Page 10: Knowing Your Lawn Mower
KNOWING YOUR LAWN MOWER Please use the illustration below to familiarize yourself with the location and function of the components that control of your lawn mower. Recoil Starter handle Cutting height adjustment lever Grass catcher Primer bulb Cutting height adjustment lever Fuel tank cap Rear wheel Rear discharge door... -
Page 11: Lawn Mower Preparation
LAWN MOWER PREPARATION The following section describes steps necessary to prepare the lawn mower for use. If after reading this section, you are unsure about how to perform any of the steps please call (800) 791-9458 Mon-Fri 9-5 EST for customer service. Failure to perform these steps properly can damage the lawn mower or shorten its lifespan. -
Page 12: Recoil Starter Handle
ATTACH LOWER & UPPER HANDLE 1. Loosen two knobs and turn the folded upper tube to match the lower tube, and tighten the knob. 2. Turn the lower tube to an angle that maches the base and tighten with two screws. （Two screws are in the accessories bag.）... -
Page 13: Grass Catcher
SIDE DISCHARGE CHUTE To convert mower for side discharge, the grass catcher has been removed and that the rear discharge door is closed. 1. Lift the spring-loaded discharge cover located on the side of the mower. 2. Slide two hooks of the side discharge chute under the hinge pin and lower the spring on the side discharge cover. -
Page 14: Operation
OPERATION GAS AND OIL FILL-UP The engine comes shipped without oil or gasoline. Be sure to add oil and gasoline before starting the engine. 1. Add oil before starting mower for the first time. 2. Service the engine with gasoline as instructed. Warning: Use extreme care when handling gasoline. -
Page 15: Engine Start/Stop Control
Warning: 1. Gasoline is extremely flammable and is explosive under certain conditions. 2. Refueling in a well-ventilation area with the engine stopped. Do not smoke and allow flames or sparks in the area where gasoline is stored or where the fuel tank is refueled. 3. - Page 16 NOTE: After repeated failed attempts to start the engine, please consult the troubleshooting guide before attempting again. If problems persist, please call customer service. Note: on’t allow the starter grip to snap back against the engine. Return it gently to prevent damage to the starter STOP THE ENGINE Release the engine start/stop control to stop the engine.
- Page 17 USING AS A REAR BAGGER To use the grass catcher to collect clippings while you are operating the mower. 1. Attached grass catcher following instruction in the lawn mower preparation. Grass clippings will automatically collect in bag as you run the mower. Operate mower until grass catcher is full. 2.
-
Page 18: Maintenance
MAINTENANCE Proper routine maintenance of this mower will help prolong the life of the machine. Always observe safety rules when performing any maintenance. The warranty on this lawn mower does not cover items that have been subjected to operator abuse or negligence. - Page 19 The lawn mower should be checked before each use for proper oil level. This is a critical step for proper engine starting. To check the oil level: 1. Make sure the lawn mower is on a level surface. 2. Clean around oil fill. Remove dipstick and wipe the dipstick with a clean rag. Insert the dipstick into the oil fill opening without screwing in.
- Page 20 2. Unscrew the spark plug from the engine using the spark plug wrench provided. There is limited space for the wrench to turn. Use both rows of holes in the spark plug wrench to gain leverage to loosen the plug. 3.
-
Page 21: Storage
STORAGE CAUTION: Never place any type of storage cover or tarp on the MOWER while it is still hot. If the MOWER is being stored for extended periods of time (30 days or more), drain fuel tank and carburetor bowl. When storing the mower for extended periods of time: 1. -
Page 22: Troubleshooting
TROUBLESHOOTING Problem Cause Solution Engine start/stop lever Engage engine start/stop lever. disengaged. Spark plug wire Connect spark plug wire. disconnected. Fuel tank empty or stale fuel. Fill tank with clean, fresh gasoline. Engine fails to start Engine not primed. Press primer bulb. Faulty spark plug. -
Page 23: Exploded View & Parts List
EXPLODED VIEW AND PARTS LIST... - Page 24 Item Stock# Description Item Stock# Description 303190328 Engine 303181203 Rear axle seaming 303020627 203050387 Bolt M8X25 8"Left wheel 203050381 Side discharge 303030087 Locknut M6 deflector 303090066A 203050523 Spring pin shaft Rear base 303130335 303130336 Rear cover torsional Torsional spring spring left 303160456 203050524 Side discharge Bracket...
- Page 25 Engine explode view and part list...
- Page 26 Item Stock # Description Item Stock # Description E01-1 E04-8 11310-Z3E0111-00A1 CRANKCASE SUBASSEMBLY. 13111-Z3E0110-00A0 PISTON E01-2 90682-Z240110-0000 SEAL, OIL E04-9 13200-Z3E0110-00A0 RING ASSY, PISTON E01-3 90682-Z030210-0000 SEAL, OIL E05-1 90107-0516-01 SCREW E01-4 90103-0410-51 SCREW E05-2 80001-Z2P0210-Q200 HOUSING, ENGINE E01-5 11321-Z2P0110-0000 PIECE, BREATH E05-3 28200-Z2P0310-Q2A0...
-
Page 27: Warranty
To make a claim under this Limited Warranty, you must return the entire power tool product; transportation prepaid, to PowerSmart. The owner must include a legible copy of the original receipt, which shall list the date of purchase, along with the company’s name where the product was purchased.
