TECHNICAL MANUAL – INSTALLATION

Recommendations

Use only original spare parts and consumables supplied by Tema Telecomunicazioni Srl for this equipment. The company shall not be

held responsible for any damage caused by the use of materials that they have not supplied.

The device has been carefully manufactured and tested. In any case, the product is not recommended for use in situations in which

incorrect operating may result in damage to persons and/or property.

We recommend that you carefully read all this manual before starting to use the device.

Do not expose the device to sunlight and protect it from sources of heat, dust, humidity and chemical agents.

This manual is the property of Tema Telecomunicazioni Srl and any duplication and reproduction, even partial, as well as storage on

any type of media is forbidden without written permission from Tema Telecomunicazioni Srl.

Revision

Date

21/02/2018 Update

MAS-AA550-REV07EN

TEMA TELECOMUNICAZIONI S.r.l.

Telecommunications - Electronics

AA-550

with 4 buttons

AA-516R additional index module

PRELIMINARY DOCUMENTATION

AA-550 System Manual – HW version 1.0 - SW version 1.08

Revision reason

Prepared

MM, GBC

Checked/Approved

Page 1 of 67

Table of Contents

Need help?

Do you have a question about the AA-550 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tema Telecomunicazioni AA-550

Page 1 Do not expose the device to sunlight and protect it from sources of heat, dust, humidity and chemical agents. This manual is the property of Tema Telecomunicazioni Srl and any duplication and reproduction, even partial, as well as storage on any type of media is forbidden without written permission from Tema Telecomunicazioni Srl.
Page 2 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL DECLARATION OF CONFORMITY (DoC) We, TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO declare under our sole responsibility that the product: product name Cito telefono - IP SIP VoIP PoE - Doorphone trade name...
Page 3 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL IMPORTANT INFORMATIONS REGARDING THE RECOVERY AND RECYCLING OF THIS ELECTRONIC DEVICE The crossed-out wheeled bin symbol below indicates that this electronic equipment is intended to be disposed in a separate collection and not in an unsorted municipal waste, in order to provide for the treatment of WEEE (Waste Electrical and Electronic Equipment) using best available recovery and recycling techniques.
Page 4: Table Of Contents
6.2. A ................. 15 DDITIONAL FEATURES OF THE KEYPAD EXPANSION 6.3. RELAYS ..................16 CONTROL WITH ACCESS CODES 6.4. C AA-550 ....................16 ALLS GENERATED FROM 6.5. C AA-550 ........................17 ALLS TO 6.6. A ........... 17 CQUISITION OF EXTERNAL CONTACTS FOR SPECIAL APPLICATIONS 6.7.
Page 5 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 12. INFORMATIONS FOR THE WALL INSTALLATION OF THE SYSTEMS ........ 61 MAS-AA550-REV07EN Page 5 of 67...
Page 6: Introduction
INTRODUCTION The AA-550 is a Doorphone that can be connected to any VoIP SIP PBX, as a SIP extension, with the possibility of power either through dedicated external power adapter, or through PoE on the LAN. Alternatively it is possible to be used in a Peer-to-Peer connection and allows the opening of one or two electric locks (two integrated relays).
Page 7 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL VoIP IP LAN section • Integration with the local LAN, 100 BaseT Ethernet port with RJ45 connector • SIP-based VoIP connection in either SIP Proxy Server or Peer-to-Peer mode, PoE (Power over Ethernet) possibility •...
Page 8: Parts Comprising The System (Packing List)
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 3. PARTS COMPRISING THE SYSTEM (PACKING LIST) The AA-550 system consists of the parts included in the following list: • An AA-550 device (external unit with 4 buttons) • A special key for the front panel screws •...
Page 9: Cross-Reference Table Of Features / Services Of The Various Models
3.1. Cross-reference table of features / services of the various models At the base models AA-550 and AA-550C, it is possible to add one expansion module chosen between the two models AA-516P and AA-516K while it is possible to add more AA-516R modules.
Page 10: Technical Specifications
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 4. TECHNICAL SPECIFICATIONS Generals Buttons Four buttons with backlighted label holder Internal heating Anti-humiditiy internal heating circuit Audio section Internal speaker with RMS power 1.3W Possibility of adding an external speaker, RMS power of 1.3W and minimum impedance 8Ω.
Page 11 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL VoIP PoE power supply According to IEEE 802.3af (only for system powering, not for opening electric lock) Ethernet LAN 100 BaseT port Supported VoIP Protocols SIP v2 Supported connecting modes SIP Server or Peer-to-Peer Protocols...
Page 12: Operation
When the call button in idle mode is pressed, AA-550 automatically generates a telephone call through the VoIP PBX. The visitor begins to listen to the speaker of AA-550 the outcome of his request for access, or listen to the ringing tone and the subsequent reply by the operator that was called.
Page 13: Possibility Of Opening Electric Locks By Entering A Passcode
The same operation mode may be applicable in public facilities, large buildings and other environments. The calls (if allowed by the appropriate class of service of the extension number assigned to AA-550 on the PBX) can also be made to mobile phones or trunks and not only just to the extensions of PBX to which it is connected.
Page 14: Device Diagram
5.3. Device diagram The AA-550 Doorphone is connected to the PBX via the LAN RJ-45 port. The contacts of relays will be used to drive an electric door opener and/or a light at the entrance, a gate for pedestrian and/or the driveway gate.
Page 15: Operating Modes
- Night mode / Interval mode, (see par. 9.6). If the system AA-550 is equipped with the 8 buttons expansion the operation described below for the 4 buttons on the base system remains valid and is extended to additional buttons.
Page 16: Relays Control With Access Codes
AA-550 is equipped with a special table of up to 60 characters that allows to create a filter on the selections made by the user, in order to allow or reject it, even without the control of the PBX. This table and this service are very useful for systems equipped with the full keyboard expansion module.
Page 17: Calls To Aa-550
AA-550 that the alarm has been notified. If the called number is busy or does not answer, or in any other case in which AA-550 still does not receive the code acquisition / acknowledgment, at the end of each call attempt AA-550 back to standby and prepares itself for a new alarm notification.
Page 18: Multicast Audio Streaming
Multicast, class D addresses are used and range is from 224.xxx to 239.xxx In our case, AA-550 is able to receive Multicast audio and play it on its speaker (see par. 9.10). Audio can be generated by a PC software application (eg VLC), an IP phone or another AA-550 Doorphone. Infact it is possible to program each AA-550 button to immediately dispatch the audio captured by the microphone (see par.
Page 19: Commands And Codes For The Internal Operator
Normally it is always possible to call AA-550 from any PBX extension to talk with a visitor who stands in the device proximity, to send other DTMF commands, by simply dialing the internal extension number to which AA-550 is connected.
Page 20: Signaling Led And Aa-550 Front Panel Description
7.1. Signaling Led and AA-550 front panel description Positioned above the speaker, AA-550 has a frontal signaling Led with two different modes of operation. Whn the system is in stand-by, the Led is off. When the system is busy, the Led lights steadily and remains lit for the duration of the conversation Below are showed the parts on the system and their function.
Page 21: Installation
The units are presented with the exterior part elegant and compact, the only part that will be visible and with the wall plastic box to be recessed into the wall. It is possible to power AA-550 via the Ethernet connection if PoE (Power Over Ethernet) is available.
Page 22 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL Wall flat metal COVER (Accessory option AA-517-C) As already mentioned in the assembly operations of the system, there exists the possibility of interposing between the front of the system and the wall (where you will find the rear flush plastic box) an optional flat frame which has two main purposes of use.
Page 23 TEMA TELECOMUNICAZIONI SRL COMPLETE outdoor BOX (Accessory option AA-517-S) The complete box is a cover that completely houses the AA-550 system, both the front panel which is protected as using the AA-517-T shield, and also the plastic rear box of the system.
Page 24: Inserting Or Replacing The Names Associated With The Buttons
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 8.2. Inserting or replacing the names associated with the buttons Die-cut paperboard nameplates The front panel has the label holder fields embedded in the body of the buttons. It is possible to access from the front of the system and you have to work with the supplied puller.
Page 25: Connections
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 8.3. CONNECTIONS 8.3.1. Connection of the base system AA-550 Once that the bottom rear plastic box of the system is arranged in the wall, take the front panel with the electronic board, insert the two transparent plastic pins present on frame into the appropriate holes on the wall box and get ready to connect the wires to the terminal blocks.
Page 26: Connecting The System Expansion Aa-516P And Aa-516K
TBE3 terminals block for the Twilight service keys backlighting when controlled by the relay 2 of the AA-550 base system and redistribution of the command to the eventually AA-516R expansions present in the plant For details of the connection of the signals on terminal block TBE3, see section 8.5.7...
Page 27: Connecting The System Expansion Aa-516R
TBE3 terminals block for the Twilight service keys backlighting when controlled by the relay 2 of the AA-550 base system and redistribution of the command to the eventually AA-516R expansions present in the plant For details of the connection of the signals on terminal block TBE2, see section 8.5.7...
Page 28: Description Of The Terminal Blocks Of Relays
As described for the terminal block called TB1 (terminal block of relay1) therefore applies also to the block called TB3 (terminal block of the relay2). Below is drawn the existing electrical connection on the AA-550 system board for each block.
Page 29: Description And Examples Of Operation Modes With The Internal Relays, Connections
8.5.1. CASE 1 – drive of two electric locks with system powered In this example AA-550 activates the two separate electric locks with a voltage pulse common to its own supply voltage from an external power supply. In the example the relay1 acts on the electric lock of driveway gate, while the relay2 acts the electric lock of the pedestrian gate.
Page 30: Case 2 - Drive Of Two Electric Locks, System Poe Powered, One Power Supply
8.5.2. CASE 2 – drive of two electric locks, system PoE powered, one power supply In this example AA-550 activates the two separate electric locks with a pulse of voltage common to the two electric locks (from an external power supply). In the example the relay1 acts on the electric lock of driveway gate and triggers the relay2 to follow for activate the electric lock of the pedestrian gate.
Page 31: Case 3 - Drive Of Two Electric Locks With System Powered With 3 Different Power Supplies
AA-550 it is possible to get a great flexibility of use in driving loads with different electrical characteristics between them.
Page 32: Case 4 - Drive Of Two Electric Locks, System Poe Powered, Two Separate Power Supplies
8.5.4. CASE 4 – drive of two electric locks, system PoE powered, two separate power supplies AA-550 activates the two separate electric locks and takes the power supply itself. Case with three different and separate supply voltages. In this example, however, the power source of the system is the LAN + PoE connection.
Page 33: Case 5 - Drive Of An Electric Lock And An Opening Buzzer
The device drived by the AA-550 relay2 provide to notify (for the time of activation of the relay1) that a person is entered in the warehouse. Automatically, every time a gate is opened, is carried out an alert for the warehouse employees.
Page 34: Input Connection For Acquisition Of External Contacts
In case of activation conditions, AA-550 stores it in non-volatile memory and is responsible for triggering the cycle of notifications. In case of AA-550 power off, when the power come back the system alerts will be resumed. The connector TB5 contacts also has the terminals for connecting an additional external speaker.
Page 35: Connection Between Base Unit And Expansions
8.5.7. Connection between base unit and expansions Here are some examples of compositions obtainable by the various modules of the AA-550 system. In addition to the required connections to the AA-550 base system between a module and another one (as detailed in the descriptions and examples on previous pages), for the backlight of the AA-556R expansion legend module are required other connections as indicated in the following table.
Page 36: Connecting Aa-516R Modules In Cascade Starting From Aaa-550 Base Module
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 8.5.8. Connecting AA-516R modules in cascade starting from a AA-550 base module Power supply 12Vac AA-550 AA-516R AA-516R 8.5.9. Connecting AA-516R modules in cascade starting from a AA-516R powered module Power supply 12Vac AA-516R AA-516R...
Page 37: Programming
The default IP address of AA-550 is “192.168.0.10”. Remember that in order to successfully connect to the web interface of AA-550, it is necessary that, in the IP addresses configuration of your PC, is present the subnet 192.168.0.x, where "x" is any number between 1 and 254 and different from 10.
Page 38 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL Once you find the right connection, click on it with the right mouse button and from the pull-down menu that appears choose "Properties". Then the following window appears: From the previous window, click "Internet Protocol (TCP / IP)" and click on "Properties". This will open the following window where it is possible to configure the IP addresses that the network card will use: If the PC is already on subnet 192.168.0.x with a mask 255.255.255.0, ignore the following steps.
Page 39: Access To Programming And Reset Address And Password
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 9.2. Access to programming and reset address and password To program the device, it is sufficient to use a standard browser such as Explorer, Firefox, Chrome or other. The default address of the device is 192.168.0.10 with a mask of 255.255.255.0, and the user / password with which to connect are master / master.
Page 40: Network Parameters
Subnet mask: indicate the subnet mask to be assigned to AA-550. • Default gateway: indicate the gateway that can enable AA-550 to access to internet. • Primary and secondary DNS server: indicate the addresses of two DNS servers you want to use to resolve IP addresses.
Page 41: Sip Parameters
SIP server address: specify the IP address of the SIP PBX to which AA-550 should connect. • Port: is the port number of the SIP PBX AA-550 which has to forward incoming calls. Generally it is the 5060, but some stations use a different port.
Page 42: General Parameters
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 9.5. General parameters In this section it is possible to set parameters for general use, such as call duration, audio volume, tones, ringing and so on: • Calling try time: determines how long should be, in seconds, the call attempt to the extension (the called number is ringing but not responding).
Page 43 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL • Microphone volume: Sets the microphone sensitivity and consequently the volume of the audio to the user within the company. Possible values range from 0 (very low) to 9 (very strong). • Input for Push-to-talk: with a value different of 0 (for example 1 if you wish to use input 1), the device will use the indicated input to activate the microphone (Push-to-talk).
Page 44: Set Of The Operating Mode
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 9.6. Set of the operating mode In the operating mode, it is possible to set the mode to DAY / NIGHT / INTERVAL, either manually or automatically (following time slots per week). This page is also configured to change the codes to the remote phone and coordinates the installation (used to relay Twilight mode 2, see par.
Page 45: Relay And Input Settings
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 9.7. Relay and input settings On this page it is possible to choose the operating mode of the two internal device relays and the operating mode for external inputs: • Mode: sets the function to be associated to the relay. It is possible to choose between: Electric lock: is activated only upon receiving the activation code.
Page 46 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL • Call..: number or IP address of the phone to contact when the alarm condition is triggered. The input could be also used as “door opener”: enter the number of the relay preceded by #. For exampe #1 activate the relay 1, #2 activate the relay 2.
Page 47: Camera
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 9.8. Camera This programming page is also available in the base version of the device, but it obviously affects only on the version with camera (AA-550C): • Brightness, contrast and color: can be adjusted to fit the image to your needs, but generally the default...
Page 48: Call Buttons
TEMA TELECOMUNICAZIONI SRL 9.9. Call buttons The basic configuration of AA-550 comes with 4 call buttons. The configuration page of the keys, however, is complete and allows you to configure both the version with 12-button expansion that the version with numeric keypad.
Page 49 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL Finally, for a Doorphone equipped with a numeric keypad, it is possible to configure: • Prefix to add: number or group of numbers precede any selection made by the caller. This allows you to not publish outside the true internal numbering (for example, the numbers may be from 2200 to 2250, but the legend will get numbers that can be reached from 00 to 50, by inserting 22 as a prefix) or to prevent the user can enter an unwanted prefix (for example '0 'to access the trunk line).
Page 50: Messages Management
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 9.10. Messages management In this window it is possible to change/listen to the messages for “Calling”, “Alarms”, “Announcement” and “Ringer”. Memory contains a default message for each position, the user can change any of them and the messages format must be WAV PCM 8 kHz, 16 bit, mono.
Page 51 Audio Multicast streaming By enabling this feature, AA-550 will listen to the specified address / port, and can reproduce on its speaker any received audio streaming. This function has a lower priority than the normal telephone operation of the system (outgoing or incoming calls will block or prevent the reproduction of the audio stream).
Page 52: Automatic Announcements
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 9.11. Automatic Announcements It is possible to program the diffusion of announcements at pre-set times, which can take place on the local speaker or streamed to other devices. Daily activation: it is possible to automate the diffusion of a daily announcement (which will take place at the set time) for each day.
Page 53 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL Periodic activation from file: it is possible to upload a text file in "csv" format (easily editable with "Excel") that contains, for each day of the year, up to 5 times in which to make the announcement diffusion. To compile the file simply download the default one...
Page 54: Rfid Management
TEMA TELECOMUNICAZIONI SRL 9.12. RFID management AA-550 is not equipped with RFID reader, however, being the common programming software to all hardware versions, this mask is still usable. Also models with the keyboard allow you to also enter manually the identification code to activate the door opener relay.
Page 55: Calls Report
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 9.13. Calls report For the version with the camera (AA-550C), it is possible to have a call report (ie each time a visitor presses a button, the device saves the event, see par. 9.5), in each of it will be shown the date/time of the event, the dialed number and the picture of the framed area.
Page 56: Maintenance
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 10. MAINTENANCE 10.1. System On this page it is possible to check the current firmware version, update software, and backup / restore the system configuration: • MAC address: is the physical address assigned to the network interface.
Page 57: Login Credentials
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 10.2. Login credentials By default, the user name and password for access to the configuration are master/master (lowercase). It is not possible to have more than one user (there are not hierarchical levels of programming), but it is possible to change the login credentials: The password should be introduced twice for confirmation.
Page 58: Presentation And Use Of The Program "Aa Video Console
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 11. PRESENTATION AND USE OF THE PROGRAM "AA Video Console" It's a program that comes along with the Doorphone and can be installed on a PC with Windows XP operating system or later. The program allows you to see the area framed by the built-in camera of AA-550C, to operate the device relays from the program window and then lets you talk with the visitor if the PC where it is installed has a sound card with speakers and microphone.
Page 59: Software Configuration For Sip Server Mode
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 11.2. Software configuration for SIP Server mode The video stream that the program will show comes directly from the data stream of the IP address of AA-550C. The audio of the conversation with AA-550C or the voice communication with the visitor is a normal VoIP communication between two SIP phones.
Page 60: Software Configuration For Peer-To-Peer Mode
Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL 11.3. Software configuration for Peer-To-Peer mode In this configuration mode, the software does not register on a PBX, but makes calls directly to the address specified in AA-550C. So the video stream and the audio of the conversation with AA-550C will take place without the intervention of the PBX (the two devices doesn’t need to be registered to any existing SIP Server).
Page 61 12. INFORMATIONS FOR THE WALL INSTALLATION OF THE SYSTEMS It is possibile to install AA-550 systems and its expansions in many ways. These ways can be different based on the fact of using only one system or one system with one or more expansions or using the protection accessories like frames, shields or full box.
Page 62 TEMA TELECOMUNICAZIONI SRL Double system, composed of two elements, base system plus one expansion module If it is used a AA-550 system with one expansion module, for example one AA-516K or AA-516P or AA-516R, please follow the next indications. Provide to recess the plastic back box at the right distance between them. To facilitate the installation, with each back box is provided a particular tube cable that allows to horizzontaly hook the metallic shells side by side, in order to keep them in the right position to be recessed in the wall.
Page 63 TEMA TELECOMUNICAZIONI SRL Triple system, composed of three elements, base system plus two expansion module If it is used a AA-550 system with two expansion module, for example one AA-516K + AA-516R, please follow the next indications. Provide to recess the plastic back box at the right distance between them. To facilitate the installation, with each back box is provided a particular tube cable that allows to horizzontaly hook the metallic shells side by side, in order to keep them in the right position to be recessed in the wall.
Page 64 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL Page with measures for the installation of the system with only one element: MAS-AA550-REV07EN Page 64 of 67...
Page 65 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL Page with measures for the installation of the system with two elements side by side: MAS-AA550-REV07EN Page 65 of 67...
Page 66 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL Page with measures for the installation of the system with three elements side by side: MAS-AA550-REV07EN Page 66 of 67...
Page 67 Doorphone AA-550 TEMA TELECOMUNICAZIONI SRL REMARKS: MAS-AA550-REV07EN Page 67 of 67...
