Installation & Operation Manual
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury
or death. Read the installation, operating and maintenance instructions thoroughly before installing or
M
R
ANUAL 10201
EV 2 (08/22)
$21.00
GAS TILTING KETTLE
GLT-40F
servicing this equipment.
CROWN FOOD SERVICE EQUIPMENT
70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9
Telephone: 919-762-1000
Model GLT-40F
WARNING
A Middleby Company
www.crownsteamgroup.com
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: _____________________
GAS TILTING KETTLE
M
S
ANUAL
ECTION
CO
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Crown GLT-40F
Summary of Contents for Crown GLT-40F
- Page 1 Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. CROWN FOOD SERVICE EQUIPMENT A Middleby Company 70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9 Telephone: 919-762-1000 www.crownsteamgroup.com...
-
Page 2: Important Notes For Installation And Operation
Contact the factory, the factory representative or a local service company to perform maintenance and repairs should the appliance malfunction. Refer to warranty terms. Copyright © 2022 by Crown. All rights reserved. Published in the United States of America. PAGE OF 28 INSTALLATION &... -
Page 3: Table Of Contents
Gas Tilting Kettle Table of Contents RETAIN THIS MANUAL FOR FUTURE REFERENCE. Table of Contents Important Notes For Installation and Operation ..............2 Service Connections ......................4 Installation ..........................5 Operation ..........................8 Cleaning ..........................11 Maintenance ......................... 14 Service ..........................15 Troubleshooting ........................ -
Page 4: Service Connections
GLT-40F 40 Gallon 152 Liter 1100 lbs. [499 kg] Back 4” [102 mm] As continued product improvement is a policy of Crown, specifications are subject to change without notice. PAGE OF 28 INSTALLATION & OPERATION MANUAL 10201 REV 2 (08/22) -
Page 5: Installation
Gas Tilting Kettle NSTALLATION Installation NPACKING IMMEDIATELY INSPECT FOR SHIPPING DAMAGE Immediately after unpacking the steamer, check for possible shipping damage. If the steamer is found to be damaged, save the packaging material and contact the carrier within 15 days of delivery. Prior to installation, verify that the type of gas supply (natural or propane) and electrical service agree with the specifications on the rating plate located on the left side panel as you face the front of the braising pan. - Page 6 Gas Tilting Kettle NSTALLATION To Install 1. Uncrate carefully. Report any hidden freight damage to the freight company immediately. 2. The pressure relief valve is located at the right rear of the unit. This area should be kept clear and should not be in an area where operators will normally stand.
- Page 7 Gas Tilting Kettle NSTALLATION Water Connection On units equipped with an optional water fill valve connect a water line (minimum 1/4”) to the valve with a 1/4” NPT female fitting. Units with dual (hot and cold) valves must have the hot water line connected to side with the hot water valve (red) and cold water line to the cold water valve (blue).
-
Page 8: Operation
Gas Tilting Kettle PERATION Operation NOTICE Contact the factory, the factory representative or a local service company to perform maintenance and repairs should the appliance malfunction. CAUTION If you smell gas during the lighting procedure, immediately shut off the gas supply until the leak has been corrected. WARNING In the event of main burner ignition failure, a 5 minute purge period must be observed prior to re-establishing ignition source. - Page 9 Gas Tilting Kettle PERATION Daily Shutdown 1. Turn power switch “OFF.” 2. Turn thermostat “OFF.” Complete Shutdown 1. Turn power switch “OFF.” 2. Turn thermostat “OFF”. 3. Turn power supply to unit “OFF”. 4. Remove front access panel on left side and turn dial on combination valve to “OFF”. 5.
- Page 10 Gas Tilting Kettle PERATION Daily Operation Daily operation should consist of turning on the power switch and setting thermostat for the desired temperature. It is recommended the kettle be preheated prior to use. Milk or egg based products should be placed in the kettle before heating however, to prevent sticking.
-
Page 11: Cleaning
Gas Tilting Kettle Cleaning Cleaning WARNING Disconnect the power supply to the appliance before cleaning or servicing. WARNING Never spray water into electric controls or components! WARNING The equipment and its parts are hot. Use care when operating, cleaning and servicing. CAUTION Do not use cleaning agents that are corrosive. - Page 12 Cleaning Gas Tilting Kettle Dairy Draw-Off Valve Cleaning 1. Remove the plug by first removing the handle, then turn the plug to line up with the pin and pull with both hands. It is important to use both hands because the plug is heavy. 2.
- Page 13 Gas Tilting Kettle Cleaning Stainless Steel To remove normal dirt, grease or product residue from stainless steel, use ordinary soap and water (with or without detergent) applied with a sponge or cloth. Dry thoroughly with a clean cloth. Never use vinegar or any other corrosive cleaner.
-
Page 14: Maintenance
Maintenance Gas Tilting Kettle Maintenance NOTICE Contact the factory, the factory representative or a local service company to perform maintenance and repairs. WARNING Disconnect the power supply to the appliance before cleaning or servicing. Daily 1. Wash exposed cleanable areas. Monthly 1. -
Page 15: Service
Wiring diagrams for the unit are located in a small envelope affixed to the side panel of left hand console. ORIFICE SIZE UNIT TOTAL INPUT NATURAL PROPANE GLT-40F 120,000 BTU/Hour DMS # 7 (0.201") DMS # 23 (0.154") Manifold Pressure Natural Gas - 3.5 inches W.C. LP Gas - 4 inches W.C. - Page 16 Service Gas Tilting Kettle To Adjust Pressure Switch 1. To obtain access to the pressure switch, the front panel must be removed. Remove the screws on bottom of the panel. Be sure to support the panel to avoid excessive strain on the wiring. 2.
-
Page 17: Troubleshooting
Gas Tilting Kettle Troubleshooting Troubleshooting NOTICE Loose, broken or grounded wiring may cause many of the symptoms listed. Check all wiring and make sure it is intact. PROBLEM PROBABLE CAUSE No current. Check that power is being supplied to the unit. Defective thermostat or pressure switch. -
Page 18: Appendix A, Material Safety Data Sheet
Material Safety Data Sheets Gas Tilting Kettle Appendix ‘A’ PAGE OF 28 INSTALLATION & OPERATION MANUAL 10201 REV 2 (08/22) - Page 19 Gas Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10201 REV 2 (08/22) PAGE OF28...
- Page 20 Material Safety Data Sheets Gas Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10201 REV 2 (08/22)
- Page 21 Gas Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10201 REV 2 (08/22) PAGE OF28...
- Page 22 Material Safety Data Sheets Gas Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10201 REV 2 (08/22)
- Page 23 Gas Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10201 REV 2 (08/22) PAGE OF28...
- Page 24 Material Safety Data Sheets Gas Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10201 REV 2 (08/22)
- Page 25 Gas Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10201 REV 2 (08/22) PAGE OF28...
- Page 26 Material Safety Data Sheets Gas Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10201 REV 2 (08/22)
- Page 27 Gas Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10201 REV 2 (08/22) PAGE OF28...
- Page 28 GLT-40F Gas Tilting Kettle A product with the Crown name incorporates the best in durability and low maintenance. We all recognize, however, that replacement parts and occasional professional service may be necessary to extend the useful life of this appliance.
