- Page 1 W-DMX MicroBox G6 User Manual Wireless Solution Sweden AB 2022-09-30...
-
Page 2: Table Of Contents
W-DMX MicroBox G6 2022-09-30 Contents Safety information English .......... - Page 3 W-DMX MicroBox G6 2022-09-30 Industry Canada .........
-
Page 4: Safety Information
W-DMX MicroBox G6 2022-09-30 Safety information English 1. Please read these instructions and safety instructions carefully before using this product. 2. Keep these instructions for future reference. 3. Never plug the product into the mains supply while it is still in its packaging. Never cover during use. -
Page 5: Introduction
2022-09-30 Introduction Welcome to the Wireless DMX family! We hope you enjoy your brand-new devices – Wireless Solution is the industry’s leading system for transmitting and receiving DMX signals reliably, and we thrive on avid users like you who use our products. We appreciate all your constructive feedback! Before you use, you must know: there are two main operating modes: •... - Page 6 W-DMX MicroBox G6 2022-09-30 Figure 1: Topologies W-DMX™ is unique in its use of advanced radio technologies that are also used in mobile phones and military communication. Rather than using fixed frequency channels, W-DMX™ uses Frequency Hopping technology to continu- ally check the radio channels for interferences and to rapidly move operation to clear radio channels.
-
Page 7: User Interface
W-DMX MicroBox G6 2022-09-30 User interface Though the interface display appears simple, there is a lot of information you can read back, which will help you properly set up your system and help you understand how your devices are operating. -
Page 8: Hardware
W-DMX MicroBox G6 2022-09-30 Hardware Figure 3: Front panel overlay 1. Kensington security slot 2. XLR 5 pin (Female on R-512 models, male for F-1 models) 3. Power switch - Power switch only works when operating with batteries, not with USB power. -
Page 9: Operation
W-DMX MicroBox G6 2022-09-30 Operation All W-DMX™ G6 devices uses similar user interfaces, however some model-specific differences may apply. Basic setup – Linking devices A basic setup is defined by the link between two devices. This means that, in order to send data from a transmitter to a receiver, it’s necessary to link the devices:... -
Page 10: Group Unlink
W-DMX MicroBox G6 2022-09-30 Group unlink Press and hold the red function button on the transmitter for at least 3 seconds. This will unlink all currently powered receivers that are linked to this transmitter. Linking multiple transmitters with multiple receivers When multiple receivers need to be linked up with different transmitters, repeat the process in 6.1., but... -
Page 11: W-Dmx™ Configurator App & Bluetooth
W-DMX MicroBox G6 2022-09-30 While operating as a TX you can change between modes at any given moment: 1. Press the red function button rapidly 3 times. 2. Press and hold the red function button for at least 3 seconds. -
Page 12: Turning Bluetooth On/Off
W-DMX MicroBox G6 2022-09-30 Turning Bluetooth on/off The MODE LED will flash with a blue light every two seconds when Bluetooth is enabled. When Bluetooth is disabled, no blue flashes will appear on the MODE LED. Bluetooth can be switched on or off at any time: 1. -
Page 13: Upgrades And Updates
W-DMX™ Configurator app. Firmware Update Wireless Solution is committed to developing and improving its wireless technology – this means that we every now and then releases new firmware versions. Sometimes it might be added functionality, but since even the best makes mistakes sometimes – we might release bug fixes also. All G6 products is updateable via our W-DMX™... -
Page 14: Compliance Information
FCC Declaration of Conformity We Wireless Solution Sweden AB, Johan Willins gata 6, 416 64 Gothenburg, Sweden, declare under our sole responsibility that this product complies with Part 15 of FCC Rules. Operation is subject to the... -
Page 15: Fcc Radio Frequency Interference Warnings & Instructions
W-DMX MicroBox G6 2022-09-30 • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause unde- sired operation. FCC Radio Frequency Interference Warnings & Instructions This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
