42" rough cut trailmower owner's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

OWNERS
MANUAL
Model No.
45-03621
45-03622
CAUTION:
Read Rules for
Safe Operation
and Instructions
Carefully
PRINTED IN USA
™
IMPORTANT: BATTERY REQUIRED!! The battery is NOT included
with the deck but must be purchased separately. A 12 volt lawn tractor
battery with 260/300 cold cranking amps and dimensions of 6-1/8"H x
7-5/8"L x 5-1/8"W is recommended to operate the machine.
• Safety
• Assembly
• Operation
• Maintenance
• Parts
the fastest way to purchase parts www.speedepart.com
42" ROUGH CUT
TRAILMOWER
FORM NO. 49463 (REV. 10/01/08)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 45-03621 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Agri-Fab 45-03621

Summary of Contents for Agri-Fab 45-03621

  • Page 1 ™ OWNERS MANUAL Model No. 45-03621 45-03622 CAUTION: Read Rules for Safe Operation and Instructions Carefully PRINTED IN USA 42" ROUGH CUT TRAILMOWER IMPORTANT: BATTERY REQUIRED!! The battery is NOT included with the deck but must be purchased separately. A 12 volt lawn tractor battery with 260/300 cold cranking amps and dimensions of 6-1/8"H x...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY RULES ... 3,4 SAFETY AND OPERATIONAL DECALS ... 5,6 HARDWARE CHART ... 7 ASSEMBLY ... 8-11 OPERATION ... 12-16 CUSTOMER RESPONSIBILITIES ... 17-20 STORAGE ... 21 REPAIR PARTS ... 22-26 WIRING DIAGRAM ... 27...

  • Page 3: Safety Rules

    Safe Operation Practices for Tow Behind Mowers IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD I. GENERAL OPERATION • Read, understand, and follow all instructions in the manual and on the machine before starting. • Read this operator’s manual carefully. Become familiar with the controls and know how to operate your mower properly. • Only allow responsible adults, who are familiar with the instructions, to operate the machine.
  • Page 4 IV. SERVICE • Use extra care in handling gasoline and other fuels. They are flammable and vapors are explosive. Use only an approved container. Never remove gas cap or add fuel with the engine running. Allow engine to cool before refueling. Do not smoke. Never refuel the machine indoors. Never store the machine or fuel container inside where there is an open flame, such as a water heater.

  • Page 7: Contents Of Parts Bag

    REF. QTY. DESCRIPTION Hex Bolt, 1/2" x 7" B Hex Bolt, 1/4" x 7-1/2" C Hex Bolt, 5/16" x 3/4" D Hex Bolt, 1/4" x 3/4" Screw, Self Tapping #10 x 1/2" Hex Nylock Nut, 1/2" CONTENTS OF PARTS BAG SHOWN FULL SIZE REF. QTY. H J K NOT SHOWN FULL SIZE DESCRIPTION Hex Nylock Nut, 5/16"...

  • Page 8: Install Battery

    INSTALL BATTERY Your Trail Mower requires a 12 volt battery to operate. The battery is NOT included with the unit. It must be purchased separately. • Remove four screws and the Battery Cover from the Mower and set them aside. • Install two Plastic Nuts into the square holes in the Mower Deck under the Battery Cover. • Place the Battery on the Mower Deck between the two Plastic Nuts. • Place the Battery Hold Down on top of the Battery. • Secure the Battery to the Mower Deck with two 1/4 x 7-1/2 hex bolts. • Open the terminal access doors on the Battery Hold Down. • Connect the Red Wire to the positive (+) battery terminal using a 1/4 x 3/4 hex bolt and 1/4 SEMS nut. Tighten securely. • Connect the Black Wire to the negative (-) battery terminal using a 1/4 x 3/4 hex bolt and 1/4 SEMS nut. Tighten securely. • Close the terminal access doors.
  • Page 9 ASSEMBLY TERMINAL ACCESS DOORS 1/4 X 3/4 HEX BOLT & 1/4 HEX NUT (SEMS) BLACK WIRE BATTERY HOLD DOWN 1/4 X 7-1/2 HEX BOLT PLASTIC NUT FIG. 1 REAR QUADRANT 3/8 X 2-3/4 HEX BOLT 3/8 FLAT WASHER 3/8 FLAT WASHER 3/8 HEX LOCK NUT 1/4 X 3/4 HEX BOLT HITCH ASSEMBLY...

  • Page 10: Clutch Cable Adjustment

    INNER NUT SWITCH BODY 1/8" PLUNGER CLUTCH LEVER FOUR SCREWS REAR DRIVE COVER FIG. 2 ASSEMBLY CLUTCH CABLE ADJUSTMENT • Remove four screws from Rear Drive Cover. Lay aside cover and screws. • Place Clutch Lever in “DISENGAGED" position • The Cable should be under slight tension but should not pull the Clutch Lever more than 1/8" away from the Switch Body. NOTE: If the Plunger extends more than 1/8" out from the switch body, the cable tension is too tight and the OUTER NUT...
  • Page 11 INSTALL REAR ROLLER TO DECK • Install Rear Roller Mounting Bracket to rear of deck using two 5/16 x 3/4 Hex Bolts and two 5/16 Hex Nylock Nuts. (See Fig. 3.) • Install Roller to Rear Roller Bracket using 1/2 x 7 Hex Bolt and 1/2 Hex Nylock Nut. • Make sure Roller turns freely on Bolt. 5/16 X 3/4 HEX BOLTS AND 5/16 HEX LOCK NUTS REAR ROLLER MOUNTING BRACKET ROLLER 1/2 X 7 HEX BOLT 1/2 HEX LOCK NUT FIG.

  • Page 12: Operation

    IGNITION KEY SWITCH MOWER BLADE CLUTCH LEVER TOW HITCH OFFSET ADJUSTMENT TOW BAR HEIGHT ADJUSTMENT OPERATION HEIGHT ADJUSTMENT STRAP HEIGHT ADJUSTMENT LIFT LEVER THROTTLE CONTROL FIG. 4 HEIGHT ADJUSTMENT STRAP...
  • Page 13 OPERATION TRACTOR HITCH PIN OR MOWER CLEVIS PIN HAIR COTTER PIN REMOVE MOWER CLEVIS PIN FROM THIS HOLE FIG. 5...
  • Page 14 OPERATION...
  • Page 15 HAIR COTTER PIN LOCATING PIN HAIR COTTER PIN CLEVIS PIN TOW BAR TOW BAR ADJUSTMENT OPERATION HEIGHT ADJUSTMENT LIFT LEVER GROUND LEVEL FIG. 6 HEIGHT ADJUSTMENT STRAP CUTTING HEIGHTS 1-1/2" 2" 2-1/2" 3" 3-1/2" 4" 4-1/2" 5" CUTTING HEIGHT...
  • Page 16 OPERATION This mower has been designed to run offset from the center of the tow vehicle. This allows the operator to drive along side high brush with the tow vehicle while cutting down the brush beside him. The adjustable hitch gives you three offset cutting positions plus straight behind for narrow paths.

  • Page 17: Customer Responsibilities

    CUSTOMER RESPONSIBILITIES WHEEL PIVOT 3 SPINDLE 2 WHEEL 2 SWIVEL 2 WHEEL 2 WHEEL PIVOT 3 QUADRANT 3...

  • Page 18: Cleaning The Mower

    CUSTOMER RESPONSIBILITIES BLADE CARE AND SERVICE CAUTION: DO NOT HANDLE MOWER BLADES WITH BARE HANDS. CARELESS OR IMPROPER HANDLING MAY RESULT IN SERIOUS INJURY. BLADE CARE For best results mower blades must be kept sharp. The blades can be sharpened with a file or on a grinding wheel. Do not attempt to sharpen blades while they are still on the mower. BLADE SERVICE (Refer to fig. 9) TO REMOVE BLADE ASSEMBLY FROM DECK •...
  • Page 19 CUSTOMER RESPONSIBILITIES SWITCH BODY 1/8" PLUNGER CLUTCH LEVER FOUR SCREWS REAR DRIVE COVER CLUTCH CABLE ADJUSTMENT INNER NUT • Remove four screws from Rear Drive Cover. Lay aside cover and screws. • Place Clutch Lever in “DISENGAGED" position • The Cable should be under slight tension but should not pull the Clutch Lever more than 1/8" away from the Switch Body. NOTE: If the Plunger extends more than 1/8" out from the switch body, the cable tension is too tight and the OUTER NUT...

  • Page 20: Customer Responsibilities

    CUSTOMER RESPONSIBILITIES V-BELT REPLACEMENT • V-belt must be replaced if it becomes stretched to the point that it can no longer be adjusted, or if it becomes frayed or otherwise can not function properly. • Move Blade Clutch Lever to the “DISENGAGED" position. CAUTION: DISCONNECT SPARK PLUG WIRE REMOVING OLD V-BELT • Remove Rear Drive Cover. • Remove Front Drive Cover. • Remove Hair Pin and Clevis Pin from Clutch Cable. • Loosen two Rear Belt Guides and pivot them away from Blade Pulley.

  • Page 21: Storage

    STORAGE...
  • Page 22 42" ROUGH CUT TRAILMOWER - MODELS 45-03621 & 45-03622...
  • Page 23 42" ROUGH CUT TRAILMOWER - MODELS 45-03621 & 45-03622 ITEM PART NO. DESCRIPTION HA24255 MOWER DECK HA24378 GUARD WHEEL HA23193 SCREW 3/8-16 X 1-1/4 THD. FORMING HA24292 BRACKET BELT GUIDE HA24293 ROD BELT GUIDE HA3090 PIN HAIR COTTER HA24294 V-BELT (B SEC. 60" O.C.) HA24295 CHANNEL CLUTCH LEVER 45100 BOLT 1/2-13 X 4" HEX HEAD 10. HA120396 WASHER 1/2 FLAT 11. 43262 NUT 1/2-13 HEX LOCK 12. HA14232 WASHER FLAT 13. HA24296 ROD CLUTCH LINK 14. 44101 PIN, COTTER 3/32" X 3/4" 15. 43081 WASHER FLAT 5/16" STD. WRT.
  • Page 24 42" ROUGH CUT TRAILMOWER - MODELS 45-03621 & 45-03622...
  • Page 25 42" ROUGH CUT TRAILMOWER - MODELS 45-03621 & 45-03622 ITEM PART NO. DESCRIPTION 64906 IDLER MOUNTING BRACKET 64899 IDLER ARM 24472 BUSHING 43070 WASHER FLAT 43003 WASHER 3/8" LOCK 49640 BOLT 3/8-16 X 1-1/2" HEX HEAD (SCOTCH GRIP) 49148 SPACER HA21341 IDLER PULLEY (FLAT) 43432 BOLT 3/8-16 X 2-1/2" HEX HEAD 10. 43082 NUT 3/8-16 HEX LOCK 11. HA22981 GUIDE BELT 12. HA22224 SCREW 3/8-16 X 3/4 SELF TAPPING 13. 43087 BOLT 3/8-16 X 1-1/4" HEX HEAD 14. HA15200 WASHER FLAT 15. HA21362 NUT 3/8-16 NYLOCK 16.
  • Page 26 42" ROUGH CUT TRAILMOWER - MODELS 45-03621 & 45-03622 ITEM PART NO. DESCRIPTION 25273 TUBE DRAWBAR (MODEL 45-0361) HA24441 STRAP HITCH HA20186 SPRING EXTENSION 44180 BOLT 5/16-18 X 2" HEX HEAD 47810 NUT, HEX 5/16-18 NYLOCK 64909 HITCH ASSEMBLY 43509 BOLT 3/8-16 X 2-3/4 HEX HEAD 1038 NUT 3/8 NYLOCK JAM 10. HA21362 NUT, HEX 3/8-16 NYLOCK 11. HA23636 PIN CLEVIS 12. 47134 PIN HAIR COTTER .08 X 1.58 13. 49157 LEVER CLUTCH 14. 43062 BOLT 3/8-16 X 1-1/2 HEX HEAD 15. HA19445 SPRING COMPRESSION ITEM PART NO.

  • Page 27: Wiring Diagram

    WIRING DIAGRAM...
  • Page 28 REPAIR PARTS Agri-Fab, Inc. 809 South Hamilton Sullivan, IL. 61951 217-728-8388 © 2004 Agri-Fab, Inc. www.agri-fab.com...
