Asus ZenWiFi XD5 Quick Start Manual

Quick
Start Guide
ASUS ZenWiFi XD5
AX3000 Dual Band WiFi Router
Model: XD5
Before Setup
Preparing to set up an AiMesh WiFi system
Find three ZenWiFi XD5, and power them on.
1
Use a network cable to connect your modem to the WAN port of one ZenWiFi XD5. This ZenWiFi XD5 will
2
be the AiMesh router, and the other two ZenWiFi XD5 will be the AiMesh nodes.
The LED turns solid blue to indicate that ZenWiFi XD5 is ready for setup.
3
ASUS Router App
Download free ASUS Router APP to set up
and manage your router(s).
AiMesh Setup Steps
01
Prepare
Place your ZenWiFi XD5 router and nodes within 3 meters of
each other during the setup process.
02 AiMesh node
Keep your AiMesh nodes powered on and standby for AiMesh
system settings.
03
Launching ASUS Router APP
Launch ASUS Router APP, and then follow the on-screen
instructions to finish the AiMesh setup.
Troubleshooting
If your AiMesh router cannot find any AiMesh nodes nearby or
synchronization fails, please check the following and try again.
Move your AiMesh nodes closer to the AiMesh router ideally. Ensure that it is within 3 meters.
a
Your AiMesh nodes are powered on.
b
Hardware Explanations
Plug the adapter into the DCIN port.
1
The power LED will light up when your hardware is ready.
2
XD5 Overview
LAN port
DCIN port WAN/LAN port
Specifications:
DC Power adapter DC Output: +12V with max 1.5A current
Operating Temperature 0~40
Operating Humidity 50~90%
AiMesh node
within
3 meters
AiMesh node
WAN/LAN port
Connect your modem to this port
with a network cable.
LAN port
Connect your PC to a LAN port with
a network cable.
C Storage 0~70 C
o o
Storage 20~90%
AiMesh node AiMesh router
AiMesh Setup Steps
within
3 meters
AiMesh node AiMesh router
