This operating manual is downloadable from http://www.siselectromed.com/ CAUTION: Due to periodic revisions, always check that you are reading the most up to date version of this manual. Please read this manual carefully before using the SIS equipment. Page 1. SIS MANUFACTURING LTD, NZ. MAY 2017.
Please unpack the shipping package carefully and inspect contents immediately on receipt. You must check that all ordered equipment is included in the shipping box and notify SIS Manufacturing Ltd New Zealand immediately of any missing items from your order.
AUGUST 2016 ONWARDS: For a 3.5mm type connector, insert the harness connector plug directly into the SIS machine connection socket. 2.2. ELECTRODE HARNESS POLARITY It is usually easier to position and secure the SIS electrodes to the body or to Page 4 SIS MANUFACTURING LTD, NZ. MAY 2017.
• harness is the SIS Return Electrode. ! NOTE: The silver-nylon side of an SIS electrode is the active surface that contacts the body. 2.3. CONNECTION OF ELECTRODE HARNESS TO SIS ELECTRODES Insert the two gold metal 'banana plugs' at the ends of the SIS electrode harness into the two white plastic connectors at the ends of the SIS electrode wires;...
Diagrams of SIS electrode applications for some common infections are available from http://www.siselectromed.com/ applications/ ! NOTE: The SIS machine M200 can be targeted at almost any infected tissue. However, the device cannot determine the type of microbe(s) present; standard diagnostics and differentiating information based on anatomical location, clinical signs, presentation and laboratory testing must be applied.
Page 7
SIS electrodes.* Secure electrode to body. *This electrode positioning configuration focuses silver ion flow into the target organ or tissue between the two SIS electrodes. 'Wasted' current flow through the skin between the electrodes is thereby prevented or minimized. Page 7...
Page 8
SIS MACHINE M200 MODEL OPERATING MANUAL 4.6. ELECTRODE SKIN CONTACT The contact of the entire surface of an SIS electrode positioned onto normal intact (i.e. non-damaged) skin should be as uniform as possible to surface anatomy geometry. The lower end of dry, intact skin electrical resistance (R), measured in units of 'Ohms' (Ω), is approximately 50kiloohms (kΩ).
(7.5microamperes). 5.2. ELECTRODE MONITORING SELECTION Monitoring (MNT) of the contact of the SIS or other electrode(s) with the body for in vivo applications, or with the stimulation target or circuit interface for in vitro applications can be user enabled or disabled.
(not supplied with the SIS machine). If SIS electrodes are used, the rate of silver ion introduction into the water will depend on the SIS electrode size; larger electrode size will give a faster rate of silver ion production, and vice versa.
The CIRCUIT MONITORING audio-visual alerts are based on real-time updating statistical and algorithmic analysis of Total Circuit Resistance measurements due to any changes of the contact of the SIS electrodes with the body or with their in vitro interfaces. This complex monitoring system ensures reliable delivery of the pre- and user-programmed target Output Currents and Output Voltages with extended, continuous use.
SIS MACHINE M200 MODEL OPERATING MANUAL 7.3. Electrode Harness Check This procedure tests the integrity of the SIS electrode harness for non-visible internal core breaks: 1. Power off the device. 2. Follow 2.1. CONNECTION OF ELECTRODE HARNESS TO SIS MACHINE instructions. Do not connect electrodes to the harness.
SIS MACHINE M200 MODEL OPERATING MANUAL 8. CONTRAINDICATIONS AND SAFETY DO NOT POSITION ELECTRODES OVER THE BRAIN. CONSULT WITH A SPECIALIST HEALTHCARE PROFESSIONAL BEFORE APPLICATION. DO NOT POSITION ELECTRODES OVER THE HEART (CENTRAL AND LEFT SIDE OF CHEST). CONSULT WITH A SPECIALIST HEALTHCARE PROFESSIONAL BEFORE APPLICATION.
Nothing in this medical disclaimer will limit any of the liabilities of SIS Manufacturing Ltd NZ in any way that is not permitted under applicable law, or exclude any of its liabilities that may not be excluded under applicable law.
) has been used, do not tear off the tape from the electrode. Cut the tape back to the SIS electrode size and shape, leaving the tape as a layer permanently stuck to the non-stimulation white foam surface of the electrode.
SIS MACHINE M200 MODEL OPERATING MANUAL 11. WARRANTY Each new SIS machine (“the Device”) carries a 3 year limited Warranty for defects in materials, components, assembly and operation of its electronic hardware. This Warranty is subject to all of the following exclusions and conditions. The Device enclosure is not opened except the battery compartment nor tampered with in any manner.
If a device is found to be faulty, we will honor this Warranty as quickly and efficiently as we can and either repair or replace the defective device at our discretion. We will return to you a fully functional SIS machine that meets all of its design and functional specifications perfectly, as speedily as possible.
SIS MACHINE M200 MODEL OPERATING MANUAL 14. DEVICE SPECIFICATIONS Additional Parameter Unit Minimum Typical Maximum Accuracy Notes Input Battery Voltage Output Measured Voltage in across Current 6.91 ±10mV 30kΩ 0.1% Stimulation Sense Mode(s) Resistor † Measured across Output ±100nA (1uA-20uA) 30kΩ...
SIS MACHINE M200 MODEL OPERATING MANUAL 15. MANUFACTURER'S DECLARATION RADIATED EMISSIONS CONFORMITY AS/NZS CISPR 11: 2011 (CISPR 11: 2010 Ed 5.1) Industrial, scientific and medical (ISM) radio-frequency equipment EN 60601-1-2 FCC15B FCC STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to...
Page 24
The specifications, descriptions and data within this document are subject to change without notice. This publication supersedes all previous publications on this subject. The SIS machines, SIS electrodes and SIS technology are patent pending devices. The SIS machine logo and “SIS” letters are Registered Trade Marks.
