Q U I C K S TA R T
Not following these instructions could cause
damage to your vehicle and DPA.
Quickstart Guide
1.Connect the screw lock USB (fig. 1) and diagnostic connectors (fig.
2) to the DPA XL hardware. Do not connect the USB cable to the
computer at this time.
2.Download and Install the DPA XL Software:
www.dgtech.com/downloads
3. Launch the installation program.
4. When you get to the registration screen, connect the USB cable to
the computer and fill out the registration information.
5. When installation is successful, click Finish.
Setup for Diagnostics on Vehicles
1. Always connect the USB cable to the PC first.
2. Connect the Adapter Cable to the vehicle. Using an application such
as DG Diagnostics, you can begin connection to a vehicle or
Electronic Control Module (ECM).
3. You will need to configure all your diagnostic software applications
to use the DPA XL. Refer to the
instructions.
Vehicle Network Solutions
DPA XL User's Manual
for detailed
Fig 2
Fig 1
248.888.2000 | techsupp@dgtech.com
www.dgtech.com
Q U I C K S TA R T
Not following these instructions could cause
damage to your vehicle and DPA.
Quickstart Guide
1.Connect the screw lock USB (fig. 1) and diagnostic connectors (fig.
2) to the DPA XL hardware. Do not connect the USB cable to the
computer at this time.
2.Download and Install the DPA XL Software:
www.dgtech.com/downloads
3. Launch the installation program.
4. When you get to the registration screen, connect the USB cable to
the computer and fill out the registration information.
5. When installation is successful, click Finish.
Setup for Diagnostics on Vehicles
1. Always connect the USB cable to the PC first.
2. Connect the Adapter Cable to the vehicle. Using an application such
as DG Diagnostics, you can begin connection to a vehicle or
Electronic Control Module (ECM).
3. You will need to configure all your diagnostic software applications
to use the DPA XL. Refer to the
instructions.
Vehicle Network Solutions
DPA XL User's Manual
for detailed
Fig 2
Fig 1
248.888.2000 | techsupp@dgtech.com
www.dgtech.com
