AVT MD/HD Application ..................29 DPA XL Firmware Update ....................34 5.3.1 Launch the DPA XL Firmware Update Programs Manually ........34 Appendix A. Technical Support and Return Merchandise ....35 Appendix B. Warranty Information and Limitation Statements ..36 Appendix C.
The DPA XL communicates with the PC using either a USB cable or via Bluetooth (Class I or Class II), and comes standard with the latest Technology and Maintenance Council (TMC) Recommended Practice (RP) RP1210-compliant drivers, as well as Society of Automotive Engineers (SAE) J2534-compliant drivers.
Wired PC Communications Type USB Version 1.1 or Higher Wired Connection USB Cable (up to 15 feet) Wireless Connection Bluetooth (DPA XL is equipped with Class 1 radio) Vehicle-Side Connector DB25 Female PC-Side Connector Standard B-Type USB Jack Auxiliary Power Jack...
Benchtop programming Usage with a SAE J1939 Breakout box WARNING The DPA XL should NOT be powered via the 12V DC power jack and DB-25 (Deutsch or OBD-II cable) simultaneously. Connecting to multiple power sources may cause damage to the hardware.
Standards and Protocols Supported). The DPA XL Configuration Utility will tell you what protocols, API versions, and Product Version are supported. You can also use the DPA XL Configuration Utility to get the current firmware version. Utility can be found in: Start ➔...
1.7.2 General Setup for RP1210 OEM Application The following examples show how to select the DPA XL tool you will be using. Selecting an RP1210 adapter, commonly referred to as a Vehicle Datalink Adapter (VDA) varies widely from different OEM applications; however, the terminology remains similar. The following table helps to introduce you to the terminology and helps you to make the correct selections the first time.
Select Vendor of DGDPAXL Select Protocol of SAE J1939, CAN, SAE J1708 or SAE J1850 Select Devise Name of DPA XL Device may be grayed-out on some selections Select Channel of Auto, 1, 2, 3, or 4. Channel may not appear with some selections Click OK 1.7.4...
1.7.6 Cummins INSITE NOTE: Steps are for version 8.6.196 / DP; other versions vary slightly. PowerSpec Version 5.5 or newer is required to use the DPA XL. Older versions of PowerSpec were not completely RP1210-compliant. 1. Start Program 2. Locate text box bottom, middle, click on down arrow 3.
8. Highlight and click selection 9. Select the OK button 10. Verify DG DPA XL (SA) USB (or (MA) USB) is listed underneath Device Description: 11. Select the OK button • Wait a few minutes to establish connection. If connection doesn't occur, re-boot the •...
Page 14
1.7.13.2 Volvo/Mack Premium Tech Tool (PPT) – Ver 1.X 1. Start Program 2. Select Settings from the PTT menu 3. Go to the Communication Unit configuration tab: • It is here that you select the settings for each adapter that you may use. For example, if you have an RP1210A adapter, it is here that you select which adapter, port, and protocol.
International Truck and Engine – Master Diagnostics 1. Start program 2. Choose File ➔ MD Settings➔ COM Device ➔ Window with general VDA selection 3. Select Dearborn Group DPA XL ➔ Window with specific port select your tools Device Name. 1.7.14.2 Navistar Hydraulic ABS 1.
Page 16
1. Select NavKal icon from desktop 2. Enter username and password (if required) 3. Select Connection ➔ Select COM Link ➔ DG Technologies DPA XL ➔ DPA XL ➔ select J1708 or J1939 depending on engine type 4. "Searching for Engine" appears 5.
In general, there will be a screen that will appear at some point that allows a user to select a J2534-compliant Vendor and Device for the reflashing event. When you see this type of screen, choose DG Technologies and/or the DPA XL. Figure 3 Example of General Motors TIS2Web - J2534 Application VDA Selection Screen...
2.5 Status Indicators The DPA XL has three status LEDs that indicate activity of the following functions: • PC Connection – Indicates that the DPA XL has established a connection to the PC, and if the link is active. • Vehicle Connection – Indicates that the vehicle network connection is established / active.
Page 19
DPA XL Back Label: LED Name LED State Description PC has not initialized communication with DPA XL via PC Connection the USB or Bluetooth data link. PC has initialized communication with DPA XL via the On Solid Red USB or Bluetooth data link.
Only the Windows 10 & 11 operating system is supported by the DPA XL. The installation for the DPA XL includes files that are specific to this tool (found at https://www.dgtech.com/downloads/). Most of the utility programs that DG distributes can be used by multiple DG tools and are distributed via DG Tech Utilities install, which is included with the DPA XL software installation.
Page 21
Figure 5 Installation - Required Software Screen 4. After all the software requirements have been met, the InstallShield Wizard for DGTech DPAXL will now be displayed. Click Next to continue. Click Cancel to stop the installation. Figure 6 Installation - Welcome 5.
Page 22
Figure 7 Installation – Select Destination Folder 6. After all files are installed, you can register your tool with DG. When the Product Registration Form displayed below is submitted, you will receive the latest product update information. To register your tool your PC must have internet access and be connected to a DG Technologies tool with power to complete the process.
4 Hardware Connection to the PC The above image depicts typical connection to vehicle. IMPORTANT: the following sequence of connections must be followed, otherwise damage to vehicle or DPA XL may occur. You can use the Adapter Validation Tool software included in DGTech Utilities to troubleshoot communication problems.
4.2 Connect Tool to Computer Connect the DPA XL’s USB cable to the computer. If you are going to use a Bluetooth connection to the DPA XL do not connect the USB cable to the computer - Fig 1.
5.1.1 DG Update – Internet Connection Required The DG Update utility depends on successfully connecting to the Internet (to one of DG’s servers) to retrieve the latest version information and to download the latest drivers and applications if necessary. Many companies install firewalls and virus protection and these may block the DG server queries and responses.
5.1.3 Successful Connect – Update Available In this case above, two of the products are out of date (Red), the user will be automatically presented with a prompt notifying them that there are updates available. Only if updates are available will the Download button and progress bar show up on the screen. The progress bar will keep you informed of the download progress should you choose to download the latest drivers by clicking the Download button.
Figure 13 DG Update - Advanced Settings 5.2 AVT Software If your OEM application is having trouble communicating with the Diagnostic Tool, you can use the Adapter Validation Tool (AVT) to help troubleshoot this problem. AVT allows you to determine: •...
Page 28
• Click on the OBDII car selection if are connecting to a light or medium-duty vehicles. The data bus protocols most often found on these vehicles include CAN/ISO15765, J1850, ISO9141, and ISO14230. J1708 Connector (6-pin Deutsch) J1939 Connector (9-pin Deutsch) OEMs switched to this connector when they This connector only has moved to J1939.
5.2.2 AVT MD/HD Application Figure 16 AVT HD - Main Screen 1. Connect the tool you want to test to the vehicle 2. Select the Vendor and Device you want to test the connection to 3. Then click the Test Connections selection. 4.
Page 30
5.2.2.1 Good Connection (PC to Diagnostics Tool), Good Read of Data (Diagnostic Tool to Vehicle) – Green/Green The screen snapshot below shows the PC successfully connecting to the Diagnostic Tool (RP1210 Status Window). Green in the Status window indicates a good connection to the tool. The Protocol Status bars indicate success/fail for each protocol that is scanned by default.
Page 31
Figure 19 AVT HD - Red / Red 5.2.2.3.1 AVT HD Results If you have installed the Diagnostic Tool drivers and can get AVT to a Green/Green outcome, you should be able to configure your diagnostic application to use the Diagnostic Tool. If your diagnostic application does not display in the VDA selection dialog box, this could indicate one of three things: 1.
Page 32
In the example below, a bad INI file was detected (depicted by a yellow background). Click the Make Changes button and the INI file problem will be corrected. Figure 21 Fix INI - Make Changes 5.2.2.5 Advanced Testing Dialog (Vendor/Device/Protocol) Should you need to scan other protocols to see if they are present, you can do so by using the Advanced Testing Interface.
Page 33
5.2.2.5.1 Baud Rate Drop Down List Box The Baud Rate drop down list box allows the user to select one of the supported protocol speeds for the selected protocol. The entries in this list box come from the VDA vendor’s INI file.
DPA XL drivers are installed, typically: C:\ DGTech\DPAXL\Reflash 6. Click on the Update Device button, if you want to update the firmware in your DPA XL. DO NOT DISCONNECT POWER FROM THE DPA XL DURING A FIRMWARE UPDATE!!! ALLOW THE UPDATE TO FINISH!
Return Merchandise Authorization (RMA) If technical support has deemed that there may be a physical problem with your DPA XL, you will be issued an RMA number. You would then return the product along with any documentation of ownership you have (proof of purchase/price) to the following address:...
(2) years following date of shipment. Cables (both USB and vehicle) are warranted for 90 days. DG Technologies will, at its option, repair or replace, at no cost to the customer, products which prove to be defective during the warranty period, provided the defect or failure is not due to misuse, abuse, or alteration of the product.
The DPA XL has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules (see the back of the DPA XL for FCC and IC specific identifications). These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 38
Changes not expressly approved by DG Technologies, Inc. to the DPA XL could void the user's authority to operate the DPA XL. The following is a sample rear label from the DPA XL depicting the FCC and IC identifiers.
List of Acronyms Used in Document Acronym Description Application Programming Interface Controller Area Network CAN FD Controller Area Network Flexible Data DG Technologies DoIP Diagnostics over IP DPDU API Diagnostic Protocol Data Application Programming Interface DW CAN Dual Wire Controller Area Network Class2 GM’s implementation of SAE J1850 Protocol...
