- Page 1 LED Installation Guide...
- Page 2 LED HOUSING PARTS Fuselage Mounting Plate Wingtip Housing LED Housing Pack 1 LENSE PARTS Wing Tip Cover Bulb Cover CLEAR PARTS LOOSE PARTS 1 x 5mm Ø x 140mm plastic tube (Clear)
- Page 3 STAGE 1 ANTI COLLISION LIGHT T11B From page 31 of main Assembly Guide Do NOT attact T11 until Stage 8 in this guide. From page 32 of main Assembly Guide See Important Information on gluing Tyvek before proceeding LED position T11B Drawn to scale...
- Page 4 STAGE 1 ANTI COLLISION LIGHT Return to page 33 of main Assembly Guide...
- Page 5 STAGE 2 CABLE INSTALLATION From page 33 of main Assembly Guide 2 x 5mm Ø x 70mm plastic tube (Clear) Run motor extension cables OUTSIDE of the plastic tube. Run servo ‘Y’ cable INSIDE plastic tubes. Return to page 34 of main Assembly Guide...
- Page 6 STAGE 3 NAVIGATION LIGHTS From page 43 of main Assembly Guide Starboard side illustrated Wingtip Housing Repeat for Port Side STAGE 4 LANDING LIGHTS Leading Edge Housing S Starboard side illustrated Metal LED Pins can be bent if careful. Repeat Leading Edge housing assembly for PORT SIDE. (Use plastic housing part labelled ‘P’)
- Page 7 STAGE 5 WINGS + LEDS Starboard side illustrated Repeat wing build for PORT SIDE. Return to page 44 of main Assembly Guide...
- Page 8 STAGE 6 WINGS From page 44 of main Assembly Guide Servo connector Route both LED connectors through plastic tube into fuselage interior during installation of wing Servo connector Return to page 45 of main Assembly Guide...
- Page 9 STAGE 7 LED LIGHT COVERS From page 51 of main Assembly Guide Wing Tip Cover LED Landing Light Cover (P) Wing Tip Cover LED Landing Light Cover (S)
- Page 10 STAGE 7 LED CONNECTIONS LED Port 4 LED Y Cable LED Port 1 LED Port 3 LED Port 2 Anti-Collision (Red)
-
Page 11: Receiver Setup
Setting up your transmitter to operate the LEDs. Within your transmitter setting, allocate AUX1 to a 3-way switch on your transmitter. Refer to your transmitter guide for assistance. To switch between LED modes, change the position of the switch accordingly. For assistance and enquiries contact: support@microaces.com... - Page 12 STAGE 8 HATCH INSTALLATION Return to page 51 of main Assembly Guide...
