- Page 1 CLOUDFORGE ENVIRONMENTAL HUMIDIFIER USER MANUAL...
- Page 3 WELCOME Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service. If you have any questions or suggestions, please don’t hesitate to contact us. Visit www.acinfinity.com and click contact for our contact information. EMAIL LOCATION support@acinfinity.com...
- Page 4 MANUAL CODE CF2207X1 PRODUCT MODEL UPC-A CLOUDFORGE T3 AC-CFT3 819137023611 CLOUDFORGE T5 AC-CFT5 819137023635 CLOUDFORGE T7 AC-CFT7 819137023628 819137023642 CLOUDFORGE T9 AC-CFT9...
-
Page 5: Manual Index
..............Page 14 Universal Infinity System ............Page 18 Connecting to UIS™ Controllers ........... Page 19 Cleaning ..................Page 20 Programming ................. Page 22 Other Settings ................Page 26 Other AC Infinity Products ............. Page 27 Warranty ..................Page 28... -
Page 6: Product Warning
PRODUCT WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: Ensure your power source conforms to the electrical requirements of this product. Read all instructions before installing and using this product. Do not attempt to hardwire this product. Performing any retrofitting actions may result in personal injury and/or electrical damage, and will void this product's warranty. -
Page 7: Key Features
KEY FEATURES TARGETED ZONE Includes a directional cap and stretchable tube, or pipe and nozzles, for various humidity distribution methods in spaces like grow tents, DIY grow rooms, living spaces, and greenhouses. PRECISION DETECTION Swiss-made thermal alloy sensor made of SAE grade-316 steel detects humidity changes and provides up-to- the-minute readings. -
Page 8: Product Contents
PRODUCT CONTENTS CLOUDFORGE T3 4.5L FLEXIBLE HUMIDIFIER HOSE (x1) (x1) CLOUDFORGE T7 PIPE ELBOW 5-WAY ELASTIC HUMIDIFIER BASE PIPE NOZZLE NOZZLE BANDS (x1) (x1) (x1) (x1) (x1) (x4) ALL MODELS SENSOR PROBE UIS EXTENSION NEBULIZER HOOK AND PROBE MOUNT CORD (M-M) -
Page 9: Installation
INSTALLATION CLOUDFORGE T3 STEP 1 Add water into the tank. You may detach the tank to fill it with water. We recommend using distilled water to reduce the amount of mineral build-up. NOTE: Do NOT pour water into the central pipe. This will prevent your... - Page 10 INSTALLATION CLOUDFORGE T3 STEP 2 You may swap the directional flow cap with the included flexible hose for extended targeted flow.
- Page 11 INSTALLATION CLOUDFORGE T7 STEP 1 Add water into the tank. You may detach the tank to fill it with water. We recommend using distilled water to reduce the amount of mineral build-up. NOTE: Do NOT pour water into the central pipe. This will prevent your humidifier from functioning properly.
- Page 12 INSTALLATION CLOUDFORGE T7 STEP 2 Top the center lid opening with the included base. Attach the pipe onto the base, followed by your choice of nozzle: Elbow nozzle* for unidirectional flow 5-way nozzle for omnidirectional flow *Make sure the elbow nozzle is placed over the pipe with the interior ridge facing the ground.
- Page 13 INSTALLATION CLOUDFORGE T7 STEP 3 You may use your own PVC pipes to extend the reach of your humidifier. Line the pipe with the included elastic band and attach it to the base or elbow nozzle.
- Page 14 POWERING AND SETUP CLOUDFORGE T3 STEP 1 Plug the sensor probe into the 3.5mm jack located at the rear side. Route the probe head to spot areas as needed.
- Page 15 POWERING AND SETUP CLOUDFORGE T3 STEP 2 You may plug the included UIS extension cord into the rear side port to connect your humidifier to your UIS controller. STEP 3 Plug the humidifier's power plug into an outlet to power it.
- Page 16 POWERING AND SETUP CLOUDFORGE T7 STEP 1 Plug the sensor probe into the 3.5mm jack located below the display screen. Route the probe head to spot areas as needed. You may also use the included probe mount to cable manage the corded probe.
- Page 17 POWERING AND SETUP CLOUDFORGE T7 STEP 2 You may plug the included UIS extension cord into the front side port to connect your humidifier to your UIS controller. STEP 3 Plug the humidifier's power plug into an outlet to power it.
- Page 18 UIS device with their own automated programming like temperature, humidity, cycles, schedules, and dynamic levels, while also pairing with the AC Infinity app. Central controllers and grow devices will be sold separately and may still be in development...
- Page 19 CONNECTING TO UIS CLOUDFORGE humidifiers can connect with CONTROLLER 69 (sold separately) as part of an integrated system using the included UIS extension cord. EXTENSION CABLE Use the included UIS M-M extension cord to connect the humidifier to your CONTROLLER 69 unit. Your CONTROLLER 69 unit will override all onboard settings and assume control (parameters must be adjusted on CONTROLLER 69) when connected in...
- Page 20 CLEANING Change water reservoir at least once every 4 days. Clean and maintain the unit at least once per week. STEP 1 Unplug your humidifier and remove the tank from the base. STEP 2 VINEGAR Pour out any water sitting in the base. Pour two cups of distilled water and one tablespoon of vinegar into the base.
- Page 21 CLEANING STEP 3 Use the included brush to remove any build-up from the nebulizer(s). STEP 4 Pour out the vinegar water mixture and wipe the base dry. Replace the tank to finish.
- Page 22 PROGRAMMING 2. HUMIDITY BUTTON 3. AUTO BUTTON 1. POWER BUTTON Cycles through the humidifier's Sets the low humidity trigger, Turns your humidifier ON or OFF. misting levels between 0 and 4. ranging between 35 and 95% in 5% increments. 4. TIMER BUTTON 6.
- Page 23 PROGRAMMING HUMIDIFIER MODES Tap one of the following buttons on the controller to access that button's programming mode: POWER, MIST, AUTO (low humidity trigger), and TIMER (to OFF). POWER MODE Turns your humidifier ON or OFF. The LCD screen will not display while it is off. You must power your humidifier on before adjusting settings in other modes.
- Page 24 PROGRAMMING AUTO MODE (LOW HUMIDITY TRIGGER) Tapping the auto button sets the low humidity trigger. Your humidifier will activate if the probe’s reading falls below this threshold. Once triggered, your humidifier will ramp up to the level set in MIST mode. If the probe’s reading rises above this trigger point, the humidifier will stop emitting mist.
- Page 25 PROGRAMMING ALERT ICONS The alert icons are displayed above the humidity reading. Icons may flash when the controller signals an alert to notify you of any triggered functions. WATER LEVEL LOW Displays when the tank's water level is low. Your humidifier's power, mist, auto, and timer buttons will flash and will pause programming until the tank is replenished.
-
Page 26: Other Settings
OTHER SETTINGS FACTORY RESET Holding the auto and timer buttons together for 3 seconds will HOLD + reset your humidifier and restore factory settings. This clears all user parameters in each mode. CONTROLLER LOCK Holding the power button will lock the humidifier in your current HOLD + mode. - Page 27 Features 2000D thick oxford canvas lined with inner diamond-patterned mylar that maximizes grow light luminosity, and a reinforced frame with 150 lb. weight capacity. Includes a mounting plate to install your AC Infinity controller onto. Thermo-Hygrometers The CLOUDCOM series is a line of smart thermo-hygrometers designed to accurately detect and measure your space's temperature and relative humidity.
-
Page 28: Warranty
WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues. - Page 29 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc.
