Rear View
Antenna
WAN
LAN
Reset
Power
WPS
To connect the supplied antenna
10/100 RJ-45 Ethernet Port to connect to a modem or router
10/100 RJ-45 to connect to Ethernet network card or Hub/Switch
To reset the WBR-6800 to factory default settings.
Press and hold the reset button for 5 seconds.
(All your customized settings will be lost)
Connect to the included Power Adapter
WiFi Protected Setup Push Button
Press the button for 1 second to initiate WPS.
8
