F-MTY400 / F-MTY400-C / F-MTY400-G / F-MTY400-T / F-MTY400-W
MANDATORY
LEAVE THIS MANUAL WITH OWNER
Read and follow all instructions.
Lift safety can only be ensured if the lift is
installed and operated according to these
instructions.
• FOR SAFETY REASONS
• NEVER
swim alone
• NEVER
use the lift with a dry pool
• NEVER
apply direct water pressure to the electronics
• NEVER
permit children to play on or around the lift
• DO NOT
allow children to use the lift without adult
supervision
READ CAREFULLY
Check entire box and all packing
materials for parts. Before beginning
assembly, read the instructions and
identify parts using the figures and
parts listed in this document.
It is critical that all parts be carefully
inspected prior to installation. If any
damage occurred in transit, Aqua Creek
Products, LLC must be notified within
three days of receipt of unit.
Proper installation cannot be
overstressed, as an improper
installation voids Aqua Creek's warranty
and may affect the safety of the user.
MIGHTY 400 - BLUE
USE THIS MANUAL FOR PART #'s:
CATALOG NO. F-MTY400
Aqua Creek Products, LLC
9889 Garrymore Lane
Missoula, MT 59808
Toll Free: (888) 687-3552
Local/Intnl: (406) 549-0769
www.aquacreek.com
9/28/2022 1:39:29 PM PAGE - 1
Advertisement
Related Manuals for Aqua Creek Products MIGHTY 400-BLUE
Summary of Contents for Aqua Creek Products MIGHTY 400-BLUE
- Page 1 If any damage occurred in transit, Aqua Creek Products, LLC must be notified within three days of receipt of unit. Aqua Creek Products, LLC 9889 Garrymore Lane Proper installation cannot be Missoula, MT 59808 overstressed, as an improper Toll Free: (888) 687-3552 installation voids Aqua Creek’s warranty...
- Page 2 Aqua Creek Products IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING WARNING - To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. This appliance is not intended for use by persons (including children) with reduced...
- Page 3 Aqua Creek Products TABLE OF CONTENTS PAGE PRODUCT ASSEMBLY PAGE PRODUCT DOCUMENTS ELECTRONICS INSPECTION COVER SHEET IMPORTANT SAFETY WARRANTY INSTRUCTIONS TABLE OF CONTENTS CARE PRODUCT COMPONENTS CRADLE ASSEMBLY FOOTREST ASSEMBLY REMOTE FUNCTION INSPECTION REPORT VISUAL INSPECTION PHYSICAL INSPECTION MIGHTY 400 - BLUE - CATALOG NO. F-MTY400...
- Page 4 Aqua Creek Products PRODUCT COMPONENTS MIGHTY 400 - BLUE - INV01698 ITEM PART NO. QTY. REV. DESCRIPTION 1. MAST ASSEMBLY COMPONENTS INV02754 ASSEMBLY - SPINDLE - ANCHOR 1.90" DIA. INV02792 ASSEMBLY - MAIN FRAME - MTY INV02755 ASSEMBLY - MOTOR MOUNT INV02795 ASSEMBLY - CONTROL ARM - MTY - 51.25"...
- Page 5 Aqua Creek Products PRODUCT ASSEMBLY LIFT THE MIGHTY 400 MAST ASSEMBLY FROM THE SHIPPING CONTAINER. INSERT THE 1.90" [48mm] POST OF THE MAST ASSEMBLY INTO THE DECK ANCHOR. EASE THE MAST ASSEMBLY DOWN UNTIL IT RESTS ON THE DECK SURFACE. ROTATE THE BASE UNTIL THE FIXING ANCHOR HOLE LINES UP WITH THE FIXING ANCHOR.
- Page 6 MIGHTY 400 - BLUE CATALOG NO. F-MTY400 THE AQUA CREEK FOOTREST ASSEMBLY IS DESIGNED TO FIT UNDER THE SEAT AND IS INSTALLED INSIDE THE 2" SQUARE TUBING THAT SUPPORTS THE SEAT FROM UNDERNEATH. TO INSTALL THE FOOTREST; INSERT THE FOOTREST ASSEMBLY INTO THE 2"X2" SQUARE TUBING THAT SUPPORTS THE SEAT UNTIL THE PLASTIC INSERT OF THE FOOTREST ASSEMBLY SITS FLUSH AGAINTS THE END OF THE 2"X2"...
- Page 7 MIGHTY 400 - BLUE CATALOG NO. F-MTY400 ROTATION LEFT (COUNTER CLOCKWISE) ROTATION RIGHT (CLOCKWISE) DOWN ROTATE RIGHT (CLOCKWISE) ROTATE LEFT (COUNTER CLOCKWISE) FLOOR LEVEL DOWN 9/28/2022 1:39:29 PM PAGE - 7...
- Page 8 Aqua Creek Products Annual Pool Lift Safety INSPECTION REPORT LIFT / INSPECTION INFORMATION Test Date: For Additional Support Assistance Call: Pool Lift Model: Serial Number: Toll Free: 888-687-3552 International: 1+406-549-0769 Inspected By: Find additional trouble shooting info. and videos at: https://aquacreekproducts.com/help-center/troubleshooting/...
- Page 9 Aqua Creek Products Annual Pool Lift Safety INSPECTION REPORT 1. OVERALL VISUAL INSPECTION Corrosion is common with anything in a swimming pool environment; even stainless steel. Proper and regular maintenance and cleaning will prevent most instances of corrosion. Replace any components that have corrosion caused pitting, cracking, thinning of the base metal, or other instances of corrosion that can't be eliminated and/or minimized through thorough cleaning.
- Page 10 Aqua Creek Products Annual Pool Lift Safety INSPECTION REPORT 1. PHYSICAL POOL LIFT TEST A physical test of the lift function is required when doing an annual inspection. NOTE: The lift should always be run through a completed cycle without a load prior to each use. The annual test should be ran both empty and with a typical load weight to test the lift's functions.
- Page 11 Aqua Creek Products Annual Pool Lift Safety INSPECTION REPORT 1. ELECTRONICS INSPECTION Most electronic issues are due to pool electrical connections and/or a defective battery. Always remove the battery and place it on the charger when the lift is not in use. NOTE: Even if your lift is equipped with a solare charger, it is a good idea to place the battery on the wall charger periodically or during extended periods of non-use or storage.
- Page 12 Local/Intnl: (406) 549-0769 www.aquacreek.com Aqua Creek Products, LLC (a.k.a. Aqua Creek) warrants to the original end user purchaser that products manufactured by Aqua Creek, when properly installed in accordance with assembly and installation instructions, and properly used and maintained, shall...
- Page 13 Aqua Creek Products PROPER CARE OF LIFTS For service and/or replacement parts, contact Toll free: (888) 687-3552 DAILY WEEKLY MONTHLY BEFORE PROCEDURE EACH USE Check battery level indicator on control box. Run the lift through a complete test cycle (fully extend actuator) to verify it is functioning properly.
