INSTALLATION AND OPERATING INSTRUCTIONS
PRO POOL-AT
PART NUMBER: F-046QAB-AT
MANDATORY – LEAVE THIS MANUAL WITH LIFT OWNER
Check entire box and inside all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the figures and parts listed in this document. It is critical that all
parts be carefully inspected by the installer prior to installation to ensure that no damage occurred in
transit and that a damaged part is not used. If any damage occurred in transit, Aqua Creek Products,
LLC must be notified within three days of receipt of unit. Proper installation cannot be overstressed, as
a n i m p r o p e r i n s t a l l a t i o n v o i d s A q u a C r e e k ' s w a r r a n t y a n d m a y a f f e c t t h e s a f e t y o f t h e u s e r .
1.
READ AND FOLLOW ALL INSTRUCTIONS. LIFT SAFETY CAN ONLY BE ENSURED IF THE LIFT
IS INSTALLED AND OPERATED PROPERLY – AS PER THESE INSTRUCTIONS.
2.
WARNING- TO REDUCE RISK OF INJURY, DO NOT PERMIT CHILDREN TO USE THIS
PRODUCT UNLESS THEY ARE CLOSELY SUPERVISED AT ALL TIMES.
3.
WARNING- DO NOT PERMIT CHILDREN TO PLAY ON THIS PRODUCT.
4.
WARNING- NEVER APPLY DIRECT WATER PRESSURE TO ELECTRONIC COMPONENTS.
DO NOT USE THE PRO POOL LIFT FOR WATER-D R A F T S O V E R 1 2 " ( D E C K T O WA T E R L I N E ) .
5.
6.
NEVER OPERATE THIS LIFT UNDER LOAD WITH NO WATER (DRY POOL).
7.
SAVE A COPY OF THESE INSTRUCTIONS.
AQUA CREEK, LLC 2012
TM
QUICK-ATTACH ANCHOR
- READ CAREFULLY-
9889 GARRYMORE LANE
MISSOULA, MT 59808
1-888-687-3552
FAX: 406-549-2602
WARNING
IMPORTANT SAFETY INSTRUCTIONS
MAR 2012
Advertisement
Table of Contents
Related Manuals for Aqua Creek Products PRO POOL-AT F-046QAB-AT
Summary of Contents for Aqua Creek Products PRO POOL-AT F-046QAB-AT
- Page 1 If any damage occurred in transit, Aqua Creek Products, LLC must be notified within three days of receipt of unit. Proper installation cannot be overstressed, as a n i m p r o p e r i n s t a l l a t i o n v o i d s A q u a C r e e k ’...
- Page 2 KIT CONTENTS The QUICK-ATTACH ANCHOR KIT will arrive unassembled. Check the package contents to make sure it includes the following components: [1] ONE (1) ANCHOR JIG-PLATE [ 2 ] F O U R ( 4 ) 1 ” X4” ANCHOR INSERTS [ 3 ] E I G H T ( 8 ) 1 ”...
- Page 3 INSTALLATION: ADA GUIDELINES ADA REQUIREMENTS: The PRO POOL-AT lift is designed and manufactured to be 100% ADA compliant. But for the installed lift to be 100% compliant the installation must meet the requirement for CLEAR DECK SPACE as shown in the diagram to the left. To be compliant, install the lift at 14 to 19 inches [35.6cm to 48.3cm] from the pool edge, and make sure the deck has the required CLEAR DECK SPACE as shown.
- Page 4 4 – POINT PRE-SET ANCHOR INSTALLATION NOTE: THE 4-POINT PRESET ANCHOR CAN BE INSTALLED IN EITHER A NEW POOL DECK OR AN EXISTING DECK. BEFORE INSTALLING MAKE SURE THE WATER-D R A F T I S 1 2 ” O R L E S S ( D E C K T O WA T E R L I N E ) . INSTALL THE LIFT AT A LOCATION WITH 42”...
- Page 6 The Quick-Set Anchor Bolts will be used to fix the lift safely and securely to the pool deck. STEP 1: Using a hand-truck or the Aqua Creek Products Transport Cart (F-428HTshown – sold separately) carefully move the Pro Pool lift to the anchor location.
- Page 7 Lift: Quick-Attach Anchor Kit Aqua Creek Products lifts have a Limited Lifetime Warranty on the frames, not including the powder coat finish. Aqua Creek Products, LLC (a.k.a. Aqua Creek) also warrants to the original end user that all non-frame components...
