Installation, Assembly, and Operating
Instructions
LIBERTY LIFT
TM
- READ CAREFULLY-
Check entire box and inside all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the figures and parts listed in this document. It is critical that all
parts be carefully inspected by the installer prior to installation to ensure that no damage occurred in
transit and that a damaged part is not used. If any damage occurred in transit, Aqua Creek Products,
LLC must be notified within three days of receipt of unit. Proper installation cannot be overstressed, as
a n i m p r o p e r i n s t a l l a t i o n v o i d s A q u a C r e e k ' s w a r r a n t y a n d m a y a f f e c t t h e s a f e t y o f t h e u s e r .
AQUA CREEK PRODUCTS
9889 GARRY MORE LANE
MISSOULA, MT 59808
1-888-687-3552
FAX: 406-549-2602
IMPORTANT SAFETY INSTRUCTIONS
1. READ AND FOLLOW ALL INSTRUCTIONS
2. WARNING- TO REDUCE RISK OF INJURY, DO NOT PERMIT CHILDREN
TO USE THIS PRODUCT UNLESS THEY ARE CLOSELY SUPERVISED AT
ALL TIMES.
3. WARNING- DO NOT PERMIT CHILDREN TO PLAY ON THIS PRODUCT.
4. SAVE A COPY OF THESE INSTRUCTIONS.
5. ALWAYS LOCK WHEELCHAIR BRAKES AFTER POSITIONING CHAIR ON
PLATFORM.
AQUA CREEK, LLC 2005
JULY 2008
Advertisement
Related Manuals for Aqua Creek Products LIBERTY LIFT
Summary of Contents for Aqua Creek Products LIBERTY LIFT
- Page 1 If any damage occurred in transit, Aqua Creek Products, LLC must be notified within three days of receipt of unit. Proper installation cannot be overstressed, as a n i m p r o p e r i n s t a l l a t i o n v o i d s A q u a C r e e k ’...
-
Page 2: Parts List
Please follow the assembly and instruction operations for the lift that you have purchased. The Liberty Lift will arrive mostly assembled and fastened to a wood pallet. All parts listed in the parts list will be included on the pallet. If the anchor kit was ordered prior to the shipment of the lift, the anchor parts will not be included with the lift. - Page 3 You have only three days to report concealed damage to the trucking company. 2. Your Liberty Lift will arrive mostly pre-assembled in a crate. Remove the lift from the crate and place the lift on the pool deck near where you want to install it.
- Page 4 , f o r m i n g a “ b r i d g e ” b e t w e e n t h e p o o l d e c k a n d t h e p l a t f o r m . 16. Your Liberty Lift is now ready for use.
- Page 5 With each anchor checked for plumb and level, secure the anchors into the core drilled hole using high strength epoxy or hydraulic cement. Make sure there are no void spaces in the epoxy or cement. Let epoxy cure before installing the LIBERTY LIFT.
- Page 6 NEW CONSTRUCTION INSTALLATION: ANCHOR JIG ASSEMBLY For new decks/construction install the supplied ANCHOR JIG ASSEMBLY as shown in the figure below. The Anchor Jig Assembly must be installed parallel to the finished pool wall and must be plumb and level with the top of the finished deck. If the deck is normally sloped keep the area where the Anchor Jig is installed level and slope away from it.
- Page 7 NOTE: It is extremely important to cycle the Liberty Lift all the way to the maximum down and up position each time the lift is used. This will keep the two actuators synchronized to operate in harmony keeping the platform level at all times.
- Page 8 PLACING THE LIBERTY LIFT INTO THE STORAGE POSITION Your new Liberty Lift is designed to fold completely up and out of the way so that you can use the entire pool when the lift is not being used to raise or lower a patron (See Photo 2).
-
Page 9: Control Box
APPLYING DIELECTRIC GREASE: In order to keep the battery/control box terminals from corroding a small packet of dielectric grease has been provided with the Liberty Lift. The Liberty Lift will arrive with dielectric grease already applied to the terminals, but it is recommended that more grease be applied to the terminals every 6 months, or as often as needed to keep the terminals corrosion free. - Page 10 AQUA CREEK PRODUCTS LIBERTY LIFT TROUBLESHOOTING GUIDE PROBLEM: CAUSE: SOLUTION: _______________________________________________________________________ 1. Lift will not move when Remote Control Unit Remote Power cord must remote buttons are pushed. is not plugged in be inserted deeper into properly (Fig 1) the socket on the bottom...
- Page 11 Battery to Control Box Mounting Bracket: Figure 7 Figure 8 Battery NOT Correct Attached Battery Correctly Attached 3. No Power from Battery to Control Corroded Terminals Clean Battery Terminals and Charger Terminals. Figure 9 Figure 10 Battery Contact Terminals Charger Contact Terminals __________________________________________________________________________ 4.
- Page 12 LIBERTY LIFT: LEFT FRAME PARTS DIAGRAM ITEM # QTY DESCRIPTION PART NUMBER 1 LIBERTY BASE FRAME (L)* F-009BFL (F-009BFR)* 1 LIBERTY UPPER ARM (L)* F-009UAL (F-009UAR)* 1 LIBERTY LOWER ARM F-009LA 1 LIBERTY VERTICAL ARM (L)* F-009VAL (F-009VAR)* 1 LIBERTY LATCH CATCH...
- Page 13 LIBERT LIFT: PLATFORM ASSEMBLY ITEM # QTY DESCRIPTION PART NUMBER 1 LIBERTY PLATFORM F-009PA 1 LIBERTY TAILGATE F-009TA 1 LIBERTY HANDRAIL, RIGHT F-009HRR 1 LIBERTY HANDRAIL, LEFT F-009HRL 1 LIBERTY PIN ASSEMBLY, RIGHT F-009PAR 1 LIBERTY PIN ASSEMBLY, LEFT F-009PAL 1 LIBERTY TAILGATE HANDLE F-009TH 1 LIBERTY TAILGATE LINKAGE BAR...
- Page 14 LIBERTY LIFT: ADDITIONAL PARTS ITEM # QTY DESCRIPTION PART NUMBER 24V BATTERY CHARGER F-044CH JUMBO HANDSET REMOTE F-100JH ANCHOR INSERT P-7200ANB 1"-8 HEX NUT, S.S. NUT1-8SSHEX DIELECTRIC GREASE DIELECTRICGREASE...
- Page 15 Aqua Creek Products, LLC Limited Warranty: LIBERTY LIFT Aqua Creek Products, LLC (a.k.a. Aqua Creek) warrants to the original end user purchaser that products manufactured by Aqua Creek, when properly installed in accordance with assembly and installation instructions, and properly used and maintained, shall be free from defects in material and workmanship for a period of three (3)
