- Page 1 Q-208-081 INSTRUCTION MANUAL HIGH SPEED MULTI POWER LINE TRANSDUCER HSQT2-93A...
- Page 2 Q-208-081 Introduction Thank you for your purchase of our product. Read this instruction manual carefully before installation, wiring, and using this product. Keep this instruction manual handy for reference at any time. Have a contact with us or sales agent in case that this instruction manual is lost or damaged. <Caution>...
-
Page 3: Table Of Contents
Q-208-081 Content 1. Product outline 1.1 Usage of product ･････････････････････････････････････････････････････ 3 1.2 Features of product ･･･････････････････････････････････････････････････ 3 1.3 Composition of type ･･･････････････････････････････････････････････････ 3 1.4 Specification code ････････････････････････････････････････････････････ 4 2. Specification 2.1 Rating ････････････････････････････････････････････････････････････････ 4 2.2 Measurement parameter ･････････････････････････････････････････････････ 5 2.3 Option ････････････････････････････････････････････････････････････････ 6 2.4 Specification and performance ･････････････････････････････････････････... -
Page 4: Product Outline
Q-208-081 1. Product outline 1.1 Usage of product This product is a multi-AC transducer for a high-speed response suitable for power control. The analog output of current (average of each phase current), voltage (3-phase 3-wire：the average of each line voltage, average of 3-phase 4-wire：each phase voltage), power, reactive power, and frequency measurement is possible, by connecting with one circuit of electric power system, 1.2 Features of product ●... -
Page 5: Specification Code
Q-208-081 1.4 Specification code Input Output factor Output Auxiliary supply ① ② ０－１ １ １ １ ０ １ ０ ０－ ③ － ④ ● Input specification Mark ① Current input ② Voltage input ( ) is at the 3-phase 4-wire case. ５... -
Page 6: Measurement Parameter
Q-208-081 2.2 Measurement parameter Measurement Class ６ Measuring range ( Operation method Note parameter index Rating 5A 0～5A Current Effective-value Average value of each phase ７ ８ [ A ] arithmetic current (R, S, T) Rating 1A 0～1A 3φ3W：Average value of each line voltage Fundamental-wave Voltage... -
Page 7: Specification And Performance
Q-208-081 2.3 Option Item Specification The countermeasure against Environmental conditions hydrogen-sulfide (H S) gas ：Hydrogen sulfide, 1ppm，40℃，80％RH， Air supplying amount, Less than 1000L/H 2.4 Specification and performance Item Specification Electrical measuring transducers for converting a.c. electrical quantities to analogue or Compliant standard digital signals. - Page 8 Q-208-081 Item Specification 2 times 10 seconds and 1.2 times continuation of rated voltage. Input 40 times 1 second, 20 times 4 seconds, 10 times 16 seconds and 1.2 times continuation of rated current. 1.5 times 10 seconds and 1.2 times continuation of rated voltage. (AC100/110V，AC200/220V， Overload Auxiliary DC24V)
-
Page 9: Ce Marking
Q-208-081 2.5 CE marking (Only auxiliary supply DC24V specification product.) (1) Conformity technical standard ・EMC conformity technical standard EMI(Emission) EN61000-6-4 EMS(Immunity) EN61000-6-2 ・Safety technical standard EN61010-1 CATⅢ(Maximum circuit voltage, 300V)，Pollution degree 2 (2) Specification according to EMC test item Conformity EMC test item Limits technical standard... -
Page 10: Outline Dimension
Q-208-081 3. Handling explanation 3.1 Outline dimension (12.5) 13-M4screw 22-M3screw ９ Note( ) In case of DIN rail (height 15mm) installation. (Please use DIN standard 35mm rail.) ) The dimensions which the switch cover is opening. 3.2 Mounting instruction The environmental conditions of installation space. Please select indoors without low mechanical vibration, dust, and corrosive gas. -
Page 11: Installation And Removal To A Rail
Q-208-081 3.4 Installation and removal to a rail Please use the rail based on the DIN standard of 35mm width. ● Rail installation The upside nail of the slot for rail installation in a BOX bottom is inserted in a rail. Next, if it pushes against the lower side (arrow), it is fixed with a lower slider. -
Page 12: Connection
Q-208-081 3.5 Connection ● 3-Phase 3-Wire ･･･ HSQT2-93A-5-33-1 (A,V,W,var,Hz) ● 3-Phase 4-Wire ･･･ HSQT2-93A-5-34-1 (A,V,W,var,Hz) LOAD LOAD 3S 3L AUX. 3S 3L SUPPLY AUX. SUPPLY S1( ) S2( ) S1( ) S2( ) (＋) (＋) (＋) (＋) (＋)20 (－) (－) (－) -
Page 13: The Relation Of An Input-Output
Q-208-081 3.7 The relation of an input-output (1) Current・Voltage ① ② Input Output Input Output 0～5A 0～5V or 0～5A 4～20mA or 0～10V 1～5V 0～150V 0～150V (V) (V) (V) (mA) DC output DC output 5 2.5 5 (A) 5 (A) 150(V) 150(V) AC input AC input... -
Page 14: Explanation Of Front Switch
Q-208-081 3.7 Explanation of front switch Scaling function. (DIP swich) POWER LINE TRANSDUCER HIGH SPEED MULTI HSQT2-93A TYPE MAX./OFF/BIAS change over for output adjustable. (Slide switch) ADJUST MAX. BIAS ・ ・ ・ ・ ・ ・ ・ ・ Factor number setting for output adjustable. (Rotary switch) DOWN OUTPUT NO. -
Page 15: Calibration And Maintenance
Q-208-081 4. Calibration and maintenance 4.1 Calibration Because output adjustment of this product is carried out beforehand, there is no want for calibration. However, in case an output shifts in long-term use, please adjust in the next way. (1) Output load should connect and adjust real load (name plate indication load-resistance within the limits) or the simulation load of resistance equivalent to it. - Page 16 Q-208-081 Head Office : 11-13 Hitotsuya 1-chome, Adachi-ku, Tokyo, 121-8639 Japan. Phone：03-3885-2411 , Fax：03-3858-3966 Kyoto Office : 1-19 Ichinobe-Nishikawahara, Jyoyou-shi, Kyoto, 610-0114 Japan. Phone：0774-55-1391 , Fax：0774-54-1353 Revision B, DATE：July 21, 2010...
