If the operator panel is equipped with two ethernet ports, then a second tab is
shown in the IP settings dialog. The default setting for LAN B is "Obtain an IP
address via DCHP".
3.4
Date / Time
3.5
Edit project
3.5.1
This option enables the function to copy an iX Developer project from an external
memory, USB flash drive or storage device connected to one of the operator panels
USB-ports.
3.5.2
This option enables the function to copy the iX Developer project and all the files
needed to run the application to an external SD card.
Beijer Electronics, MAEN205G
The date/time settings dialog allows setting
of the Time zone, date, time and also setting
automatic adjustment of clock for daylight
saving.
The edit project / restore image dialog allows
modifying the project in an operator panel
and, if needed, restore the panel image to a
previous version.
Copy project from external memory
Copy project to SD card
Service menu
10
