- Page 1 EVK-M10QSAM Evaluation kit User guide Abstract This document describes the structure and use of the EVK- M10QSAM evaluation kit and provides information for evaluating the u-blox SAM-M10Q GNSS patch antenna module. www.u-blox.com UBX-22026860 - R01 C1-Public...
- Page 2 fitness for a particular purpose of the information. This document may be revised by u-blox at any time without notice. For the most recent documents, visit www.u-blox.com.
-
Page 3: Table Of Contents
EVK-M10QSAM - User guide Contents 1 Product description......................5 1.1 Overview..............................5 1.2 Kit contents..............................5 1.3 System requirements..........................5 2 Specifications......................... 6 2.1 Safety precautions..........................6 2.2 Approvals..............................6 3 Getting started........................7 3.1 Installing u-center 2 software......................7 3.2 Installing hardware..........................7 3.3 Interface default configuration......................7 4 Device description.........................8... - Page 4 Appendix............................ 26 A Glossary..............................26 Related documents........................ 27 Revision history........................28...
-
Page 5: Product Description
Because of the integrated antennas in the SAM-M10Q module, the standard u-blox GNSS EVK aluminum box cannot be used for the EVK-M10QSAM. A plastic cap is attached on the top of the antenna module in EVK-M10QSAM. The purpose of the cap is to prevent air flow inside the SAM-M10Q shield. -
Page 6: Specifications
Table 2: EVK-M10QSAM specifications 2.1 Safety precautions EVK-M10QSAM must be supplied by a PS1 class limited power source. See section 6.2.2.4 of IEC 62368-1:2018 [3] for more information on the PS1 class. In addition to a limited power source, only ES1 class circuits are to be connected to the EVK- M10QSAM, including interfaces and antennas. -
Page 7: Getting Started
2, the u-blox interactive evaluation software tool is required for configuration, testing, visualization and data analysis of u-blox GNSS receivers as well as EVKs. The EVK user guide together with the u-center 2 evaluation tool provide useful assistance during all phases of a system integration project. -
Page 8: Device Description
Figure 4.1 Interface connection The EVK-M10QSAM supports UART and I2C communication interfaces. To connect the EVK to a PC, use a standard SUBD-9 cable or the included USB cable depending on the interface in use. The EVK also includes an on-board USB-to-Serial converter for USB-to-UART communication with the receiver. -
Page 9: Interface Switch
4.1.2 14-pin connector The EVK-M10QSAM front side has a 14-pin connector that provides programmable input/output signals, communication interfaces and supply options. All these pins are ESD protected. The 14-pin connector can be used for communicating with the receiver through the UART and I2C interfaces. -
Page 10: Usb
The USB connector in the evaluation kit can be used for both power supply and communication. The easiest way to evaluate the EVK-M10QSAM operation is to connect the EVK to a PC with the USB cable and then to use the u-center 2 tool to configure and monitor the GNSS functions. The USB connector is internally connected to a USB-to-Serial converter that connects to the UART interface of the u-blox M10 receiver on the EVK. -
Page 11: I2C
External antenna connectivity through SMA connector is not available in the EVK-M10QSAM. 4.3 Time pulse u-blox receivers include a time pulse function that provides pulses with a configurable pulse period, pulse length and polarity (rising or falling edge). The u-center 2 evaluation tool can be used to configure the time pulse parameters. -
Page 12: Safe Boot Button
This button is used to set the receiver into safeboot mode. In this mode, the receiver executes only the minimal functionality. The safeboot mode is not recommended in EVK-M10QSAM because the u-blox M10 receiver is using a ROM-based firmware and thus, it is not necessary to go into safe boot mode. -
Page 13: Measuring Current
AssistNow ™ Online service. On EVK-M10QSAM, the main supply voltage for the u-blox M10 GNSS receiver is 3.3 V. To measure the total GNSS supply current with EVK-M10QSAM, follow these steps: Power up EVK-M10QSAM. -
Page 14: Block Diagram
EVK-M10QSAM - User guide 6 Block diagram EVK-M10QSAM block diagram providing an overview on supply voltages, current measurement and communication interfaces is shown in Figure Figure 5: EVK-M10QSAM block diagram UBX-22026860 - R01 6 Block diagram Page 14 of 29 C1-Public... -
Page 15: Board Layout
EVK-M10QSAM - User guide 7 Board layout Figure 6: EVK-M10QSAM board layout Figure 7: EVK-M10QSAM PCB UBX-22026860 - R01 7 Board layout Page 15 of 29 C1-Public... -
Page 16: Schematic
EVK-M10QSAM - User guide 8 Schematic Figure 8: EVK-M10QSAM schematic UBX-22026860 - R01 8 Schematic Page 16 of 29 C1-Public... -
Page 17: Device Configuration
Figure Figure 9: EVK-M10QSAM receiver configuration view The receiver configuration can be saved to the receiver RAM, or to the battery-backed RAM (BBR). The RAM content is cleared after the power supply is disconnected or in software standby mode and the off... - Page 18 EVK-M10QSAM - User guide Figure 10: EVK-M10QSAM communication ports The COM ports may appear differently in different Windows versions. For example, in Windows 10 it appears as shown in Figure UBX-22026860 - R01 9 Device configuration Page 18 of 29 C1-Public...
-
Page 19: Uart Baud Rate Configuration
EVK-M10QSAM - User guide Figure 11: EVK-M10QSAM communication ports identification on Windows 9.1.1 UART baud rate configuration The baud rate for the UART communication to the receiver can be configured in the CFG-UART1- BAUDRATE configuration key. The default baud rate is set to 9600 as shown in... -
Page 20: Gnss Configuration
EVK-M10QSAM - User guide Figure 12: EVK-M10QSAM UART baud rate configuration Setting a different baud rate will interrupt communication. If other configuration keys were set after, these will not be applied. Therefore, the new baud rate needs to be selected manually to resume communication and apply the remaining configuration items. -
Page 21: Navigation Update Rate
Figure 14: EVK-M10QSAM receiver navigation update rate configuration 9.4 Power modes EVK-M10QSAM supports the following power modes and can be configured with the CFG-PM- OPERATEMODE configuration key. • Continuous mode (FULL): This is the full power mode and the default mode of the receiver. No power save mode is active in this mode. -
Page 22: Backup Modes
• Hardware backup mode: In this mode, other supplies except the backup supply (V_BCKP) are turned off. On the EVK-M10QSAM, this is achieved by turning off the main power supply of the EVK either by removing the USB cable or the 5.0 V supply from the 14-pin connector. -
Page 23: Troubleshooting
The maximum baud rate of 921600 or 460800 baud rate should be sufficient for most use cases. If the baud rate is insufficient, GNSS receivers based on u-blox M10 GNSS technology will skip excessive messages. Some serial port cards/adapters (e.g. USB to RS-232 converter) frequently generate errors. - Page 24 EVK-M10QSAM does not work properly when connected to a GNSS simulator When using EVK-M10QSAM together with a GNSS simulator, please pay attention to proper handling of the EVK. A GNSS receiver is designed for real-life use (i.e. time is always moving forward).
-
Page 25: Common Evaluation Pitfalls
EVK-M10QSAM - User guide 11 Common evaluation pitfalls • Parameters may have the same name but a different definition. GNSS receivers may have a similar size, price and power consumption but can still have different functionalities (e.g. no support for passive antennas, different temperature range). Also, the definitions of Hot, Warm, and Cold Start times may differ between suppliers. -
Page 26: Appendix
EVK-M10QSAM - User guide Appendix A Glossary Abbreviation Definition BeiDou Chinese navigation satellite system Battery-backed RAM Evaluation kit Inter-Integrated Circuit bus Electrostatic discharge Galileo European navigation satellite system GLONASS Russian navigation satellite system Ground GNSS Global Navigation Satellite System Global Positioning System... -
Page 27: Related Documents
Safety Standard IEC 62368-1:2018 u-center 2 User guide, www.u-blox.com/en/info/u-center-2-user-guide u-blox M10 SPG 5.10 Interface description, UBX-21035062, UBX-21035061 (NDA required) For regular updates to u-blox documentation and to receive product change notifications please register on our homepage https://www.u-blox.com. UBX-22026860 - R01 Related documents Page 27 of 29 ... -
Page 28: Revision History
EVK-M10QSAM - User guide Revision history Revision Date Name Status / comments 15-Nov-2022 mban Initial release UBX-22026860 - R01 Revision history Page 28 of 29 C1-Public... - Page 29 EVK-M10QSAM - User guide Contact For further support and contact information, visit us at www.u-blox.com/support. UBX-22026860 - R01 Page 29 of 29 C1-Public...
