- Page 1 S Infrared heater 2500 W with remote control REBO Infrared heater 2500 W with remote control AR-HE-HS2500CRS/WRS *product can differ depending on variety Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
User’s Manual – A S Infrared heater 2500 W with remote control REBO Contents 1. Safety instructions ..........3 1.1 Symbols ............................3 1.2 General instructions ........................3 1.3 General safety distances ....................... 5 1.4 Distances to the bathtub, sink or other sanitary facilities ............5 2. -
Page 3: Safety Instructions
User’s Manual – A S Infrared heater 2500 W with remote control REBO 1. Safety instructions 1.1 Symbols By means of a CE marking, it can be recognized that a product complies with the legal requirements of European legal standards and therefore may be traded within the European Community. - Page 4 User’s Manual – A S Infrared heater 2500 W with remote control REBO altered, otherwise it may cause malfunction, electric shock or even fire. • Do not make knots or kinks in the power cord, as this can quickly lead to an electric shock or even fire.
-
Page 5: General Safety Distances
User’s Manual – A S Infrared heater 2500 W with remote control REBO 1.3 General safety distances • There must be at least 29.5 in (0.75 m) distance between the heater and the ceiling. • The distance of the device from the ground must be at least 71 in (1.80 m) when wall-mounted. •... -
Page 6: Parts List
2. Parts list 1. Switch 2. Heating element 3. Bracket 4. Cable 5. Safety bar 6. Grille 7. Remote control 3. Technical specifications Model AR-HE-HS2500CRS AR-HE-HS2500WRS 4260627427284 4260627427635 Power 2500 W 2500 W Voltage AC 220 - 240 V AC 220-240 V... -
Page 7: Installation
User’s Manual – A S Infrared heater 2500 W with remote control REBO objects that are within reach. As a result, the infrared radiation is perceived as very pleasant and can be very effective. Only through this mode of action infrared radiators are particularly suitable for outdoor use. - Page 8 User’s Manual – A S Infrared heater 2500 W with remote control REBO Procedure • Connect the heater body with the holder: o Place 4 x feet (1.1) into the slots on the bottom of the base (1.3) of the pole (2). o Tighten pole (2) into the stand center (1.2) by turning the pre-attached stand center cover clockwise until tight.
- Page 9 User’s Manual – A S Infrared heater 2500 W with remote control REBO o Use M5*10 (4x) screws attach the fixed support (2x) to the back panel of device o Loosen the Fixing knobs (2X) of the holder, then assemble the device and the holder as shown following.
-
Page 10: Wall Mounting
User’s Manual – A S Infrared heater 2500 W with remote control REBO o Now the device is attached with the holder. The heater is now ready to use. Ensure you have read these instructions thoroughly prior to use. 5.2 Wall mounting Hints: •... - Page 11 User’s Manual – A S Infrared heater 2500 W with remote control REBO • Fasten the brackets at the appropriate distance of each other (17.7 - 21.7 in (45-55 cm)). • Two other brackets are fastened by the help of fasteners at the appropriate distance on the wall parallel to the floor (at least 71 in (1.80 m) from the floor and at least 29.5 in (0.75 m) from the ceiling).
-
Page 12: Use
User’s Manual – A S Infrared heater 2500 W with remote control REBO 6. Use 6.1 Commissioning and operation • Turn on the power. A buzzer will beep once, the digital screen and the display will not be displayed. At this point, press the ON/OFF button to enter standby mode. •... - Page 13 User’s Manual – A S Infrared heater 2500 W with remote control REBO • Press the function button again until the middle level, the buzzer will beep once, the P2 indicator will appear on the screen and the indicator will flash three times to indicate that the unit is in medium operating mode.
- Page 14 User’s Manual – A S Infrared heater 2500 W with remote control REBO • Press the function button again. You can select a low, medium, and high level, the P.0 indicator appears on the screen, and the indicator flashes three times to indicate that the unit is in standby mode.
-
Page 15: How The Remote Control Works
User’s Manual – A S Infrared heater 2500 W with remote control REBO 1. ON/OFF/Power mode button 2. Timer button 3. Power level indicator 4. LED 6.2 How the remote control works 1. On/Off: Switches the heater on or off or switches to standby mode. 2. -
Page 16: Cleaning
User’s Manual – A S Infrared heater 2500 W with remote control REBO • The reflector and the tube should also be visually inspected for deformation or damage. In the case of conspicuous deformations or glass breakage, please contact a qualified specialist to take the necessary steps. -
Page 17: Service And Repair
User’s Manual – A S Infrared heater 2500 W with remote control REBO • Check the intactness of the electrical wiring. 7.4 Service and repair • If there is any damage or discrepancy on your device, it must only be checked and repaired by a specialist. -
Page 18: Meaning Of The "Dustbin
You can also find more information on the Battery Act on the Internet at www.batteriegesetz.de. You can also visit our website at www.arebos.de to find out about other return options we have created. Our customer service number: +49 (0) 931-45232700... -
Page 19: Eu Declaration Of Conformity
Authorised representative for the technical documentation: Korhan Canbolat Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
