CoeLux
1 of 6
Experience the Sky
Instructions for configuring Casambi devices with CoeLux products
EN / IT
Istruzioni per la configurazione dei dispositivi Casambi con i prodotti CoeLux
CASAMBI CBU-A2D device with CoeLux profiles
Datasheet
WIRING DIAGRAM
Connect the Casambi CBU-A2D unit to the DALI port of the CoeLux system. Below is the wiring diagram: follow
the connection instructions of the model you have purchased. The pictures are for reference only. Please refer
to each product's manual for details on 0-10V electrical connections as well.
Collegare il dispositivo Casambi CBU-A2D alla porta DALI del sistema CoeLux. Di seguito lo schema dei collegamenti elettrici:
seguire le istruzioni del modello acquistato. Le immagini sono indicative. Per dettagli anche sulle connessioni elettriche 0-10V,
si prega di fare riferimento al manuale di ogni prodotto.
45°
0.4-100%
Classic
45°
0.4-100%
Smart Sky
Bluetooth controllable, enabled 2 channel 0-10V/DALI controller.
Controllo a 2 canali 0-10V/DALI regolabile via Bluetooth.
Input:
Voltage range:
100-277 VAC
Frequency: 5
0-60 Hz
Max. mains current:
35 mA
No-load standby power:
< 0,5 W
Radio transceiver:
Operating frequencies:
2,4...2,483 Ghz
Maximum output power:
-4 dBm
V+ (Red)
V– (Black)
Max. 5 m / 15 ft
2 x AWG 18 / 0.75 mm
2
MASTER
LED SLAVE
SSKY SLAVE
V+ (Red)
V– (Black)
Max. 5 m / 15 ft
2 x AWG 18 / 0.75 mm
2
coelux.com
Mechanical data:
Dimensions:
Weight:
Degree of protection: IP20 (indoor use only)
Protection class:
FCC ID:
IC:
UL:
DALI / 0-10V –
DALI / 0-10V +
DRIVER
N
SELV (IEC) or Class II (UL)
60 W, 1050 mA
2 x AWG 20 /
DALI (White)
0.5 mm
DALI (Pink)
*
SSKY 0-10V – (Grey)
*
SSKY 0-10V + (Yellow)
*
LED 0-10V – (Green)
*
LED 0-10V + (Brown)
POWER SUPPLY
UNIT
L
N
SELV (IEC) or Class II (UL)
60 W, 24 V DC
CoeLux® _Casambi CBU-A2D instructions_EN-IT_02
76,0 x 26,0 x 23,0 mm
3.0 x 1.0 x 0.9 inch
40 g
Built-in Class II
2ALA3-CBUA2D
22496-CBUA2D
E494741
CBU-A2D
L
N
AC/N (Blue)
AC/L (Brown)
(Green/Yellow)
INPUT: 100-277 VAC
L
2 X
CBU-A2D
2
L
N
AC/N (Blue)
AC/L (Brown)
(Green/Yellow)
INPUT: 100-277 VAC
2 X
