DXV D35703312.100 Installation Instructions

INSTALLATION INSTRUCTIONS
Grab Bar
12" Grab Bar – Model D35703312.100
18" Grab Bar – Model D35703318.100
24" Grab Bar – Model D35703324.100
Thank you for selecting DXV. To ensure that your
installation proceeds smoothly, please read these
instructions carefully before you begin.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing,
supply stores. It is essential that the tools and materials be on hand before work is begun.
Phillips Screwdriver
Flat Blade Screwdriver
ROUGHING-IN DIMENSIONS:
• For reference
11-5/8"
(295 mm)
Ø 2-1/8"
(54 mm)
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: (800) 227-2734
www.DXV.com
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2017
Drill
3mm (1/8")
Drill Bit
3-7/16"
(88 mm)
23-5/8"
(600 mm)
Ø 2-1/4"
(57 mm)
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: 1-800-395-1498
www.DXV.ca
- 1 -
Hammer
17-1/8"
(450 mm)
Ø 2-1/4"
(57 mm)
3-5/8"
(93 mm)
