Summary of Contents for Moog Mavis
- Page 1 Mavis Patching with Intention Get started with patching techniques, explore deeper synthesis concepts, and understand full patchbay functionality...
- Page 2 Other times, however, you may want to patch with some intention. Perhaps you have a sound in mind that you would like Mavis to approximate, or an idea may strike you while falling asleep: “I wonder what would happen if I patched the VCO to the Filter Cutoff...”...
- Page 3 Initialized Patch Before getting started, match your Mavis to the initialized patch settings above. You should be able to press one of the keyboard keys and hear a note. Find full patch point descriptions on pages 11-14 reference as you move through the patching exercises.
-
Page 4: First Steps
This patch, however, is already present in octaves! Since that is likely too extreme for Mavis’s internal routing. After unpatching most uses, Mavis has an attenuator, which everything, all you need to do is set the is like a volume knob for a control voltage. - Page 5 Each key corresponds By turning the filter CUTOFF knob completely to a precise voltage to recreate a chromatic counterclockwise we can then silence Mavis scale. when no key is pressed. MAKE THIS CONNECTION...
- Page 6 S+H input is held at the S+H output until a connecting the LFO to the GATE. new gate comes in. On Mavis, the S+H input is normalled to the VCO, meaning that the VCO is already connected to the S+H input without the need for a patch cable.
- Page 7 Now you will hear a procession of distinct MAKE THIS CONNECTION random notes. Remembering back to our We can use the MULT to patch the S+H first patch, you will probably note that, output to two places at once. again, the range of notes is quite wide–far too wide for some musical purposes.
- Page 8 Wave Folding distortion. Wave folding pushes the same concept Mavis is the first of the Moog synthesizers a little further. Instead of the tops and to include a wave folder. A typical bottoms simply staying at the threshold, component of the “West Coast” synthesis they are folded back–the threshold acts a...
- Page 9 “teeth.” Patch the LFO to input ONE (-5) of the mixer and the VCO to input TWO of the While there is no voltage control of Mavis’s mixer. Finally, patch the ONE+TWO mixer output to the FOLD IN input.
- Page 10 Further Exploration Now that you have some intuition for how Mavis’s patch bay can be used, feel free to start exploring it on your own. Remember: there is no wrong way to patch—it’s all music at the end of the day.
- Page 11 Inputs Listed in order left to right by row; FOLD IN (R1, C1) R (Row) and C (Column) Input to the wave folder. Plugging any signal in here will patch it through the wave folder (FOLD knob) and then directly to the filter. Experiment with both the VCO and LFO (at audio rate) patched here, and play with their respective waveshapes and the FOLD...
- Page 12 LFO RATE sampled, while the pulse wave can restrict (R3, C1) the sampled voltages to either the high or Controls the frequency of the LFO. Patch low voltage values of the VCO signal. You the KB CV here to control the LFO rate with can replace the VCO with the VCA output the keyboard or the S+H to get random for more flavors of randomness, while...
- Page 13 (10V peak to peak), at a frequency and shape determined by PITCH, VCO WAVE, PULSE WIDTH, and any modulation. You can use the VCO to do audio rate modulation of any of Mavis’s parameters, or patch it to FOLD IN to explore wave folding. Outputs | 13...
- Page 14 (Attack, Decay, Sustain, Release). Like the LFO, it is internally routed to many parts of Mavis, but you can also use it as an S+H input or patch it to the LFO RATE to increase and decrease the LFO rate over the course of the envelope.
- Page 15 www.moogmusic.com...
