Summary of Contents for Insane Audio JL4001
- Page 1 Caption JL4001 Installation Manual...
-
Page 2: Safety Precautions
Safety Precautions Warnings Before you use this product, be sure to carefully read this Do not unassemble or modify the product. Doing so Installation Manual and the separate User’s Guide to could lead to an accident, fire or electrical shock. ensure product is installed and used properly. - Page 3 Quick Start Guide which will walk you through the user interface. Connect the product properly according to the Enjoy your new JL4001 and we’II see ya’ on the trail! instructions. Failing to do so could lead to fire or an accident.
-
Page 4: Parts List
Parts List JL4001 USB Wire Harness Main Wiring Harness Audio RCA Wire Harness USB Wire Harness USB Wire Harness External Microphone OBDII Adapter RockCam Camera Harness GPS Antenna IA CarPlay/Android Auto Wire Harness One Bluetooth & One WiFi Antenna... - Page 5 Opening the Dashboard As a precautionary measure it’s a good idea to mask out the dashboard and panels to prevent scratches. Unsnap the 6 clips and remove the Knee Panel under the Steering Wheel using a Panel Removal Tool.
- Page 6 Opening the Dashboard Unsnap the 10 clips, unplug the 2 harnesses, and remove the HVAC panel using a Panel Removal Tool. Use the #2 Phillips Screwdriver to extract the (2) screws from the bottom of the Radio Bezel.
- Page 7 Unsnap the 6 clips and remove the Radio Bezel using a Panel Removal Tool. NOTE: Use the two clips from OEM Radio Bezel for the JL4001 frame. Use the #2 Phillips Screwdriver to extract the (4) screws from Head Unit. Disconnect and remove the Radio.
- Page 8 Removing OEM Head Unit Disconnect the OEM Power Harness, SiriusXM Radio Antenna connector (yellow), rear OEM Factory Camera Wire Connector (red), OEM AUX Input Connector (gray) from behind the OEM Head Unit. The disconnected harness and wires from the previous step will be used later to connect to the main harness in the installation.
- Page 9 Antenna, and any other USB and/or A/V Wire Harnesses and secure them. Connect the red OEM Rear Camera Wire to the Black Camera Module Box located on the JL4001 Main Power Wire Harness and make sure it is secure. Camera Module Box...
- Page 10 Installing the JL4001 NOTE: FOR VEHICLES THAT HAVE THE ALPINE PREMIUM SOUND F2 - F1 Connection (Labeled) SYSTEM R2 - R1 Connection (Labeled) CAUTION Before proceeding with the installation, vehicles with the OEM Alpine Premium Sound System will need to make a minor change on the Main Wiring Harness.
- Page 11 JL4001 Wiring Diagram (A) Connect the main power wire harness (B) Connect Audio RCA wire harness for aftermarket amps and speakers only, not needed for OEM sound system (C) Connect USB Fast Charge harness (D) Connect IA Carplay/Android Auto wire harness...
- Page 12 Installing the JL4001 USB Wiring Harnesses Route all USB wires to the glove box. Main Power Wire Harness Place adhesive GPS antenna behind the dashboard on top of the vent on the driver’s side of the vehicle. GPS Antenna The GPS antenna has an adhesive mount and is best placed behind the dashboard on top of the vent on the driver’s side of the vehicle.
-
Page 13: External Microphone
Installing the JL4001 External Microphone The JL4001 comes with a built-in Bluetooth microphone, but we also include a high quality external microphone. This external microphone will work at just about any location, but we do have some recommendations for placement. Try to keep this microphone away from any windows, air vents, or speakers to avoid background sounds or feedback. - Page 14 Installing the JL4001 Cameras Connect additional camera(s) to the RockCam video RCA RockCam Power and GND wires pigtail. We support up to 4 cameras. The pigtail offers two wires labeled “RockCam Power” and “RockCam GND” that automatically provide +12V whenever you reverse the vehicle or open the RockCam app.
- Page 15 Installing the JL4001 Cameras Check the camera installation by opening the RockCam app. Tips If you see a “No signal” warning, ensure that the front video feed is connected to “RockCam Video In” RCA port and the power wires are properly connected.
-
Page 16: Operational Tips
Insane NavEngine can be accessed both via the icon or by pressing the navigation button on the face of your JL4001. The GPS card is located behind the cover labeled “GPS/SD Card”. The GPS card needs to be inserted while using the Insane Navigation System. This will get you where you’re going both on and off the road. -
Page 17: Troubleshooting
Troubleshooting GENERAL BLUETOOTH Head unit not powering ON, no lights, no screen. Device is not pairing. Check and reseat your Main Wiring Harness. Remove the black Make sure Bluetooth is turned ON: Apps > Settings > Wiring Harness plug from the rear of the Head Unit and confirm Bluetooth >... -
Page 18: Android Auto
Troubleshooting Resources Insane Audio offers free lifetime support. If you have any Android Auto questions and/or concerns regarding your head unit, feel free to reach out to us at support@insaneaudio.com. Android Auto will not launch/start. Ensure a certified Android cable is being used. Make sure...
