- Page 1 SA-SERIES Secure Wall Amplifier with UHF Microphone Item ref: SA240 - 953.150UK SA120 - 953.149UK SA60 - 953.147UK User Manual Version 1.1 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
- Page 2 Introduction Thank you for choosing the Adastra SA-series secure wall amplifier as part of your public address system. This amplifier is designed to offer high quality, dependable service for mobile and installed systems. Please read this manual fully and follow the instructions to achieve the best results with your new purchase and to avoid damage through misuse. SAFETY SYMBOL AND MESSAGE CONVENTIONS CAUTION AVIS...
-
Page 3: Front Panel
Front panel Media player display Media player controls SD card slot USB pen drive port Input 1 + 2 Volume control Input 1 + 2 Treble control Input 1 + 2 Bass control Input 1 + 2 Mic/Line level selector Input 1 + 2 XLR/jack input Priority &... -
Page 4: Line Output
Line output Further amplifiers or even a recording device can be connected from the LINE OUT XLR connector (24). This output carries the full mix of all channels, including the media player, as fed to the speakers. Speaker outputs Each SA-series amplifier can be used with standard low impedance speakers (8Ω... -
Page 5: Operation
Operation When all connections to the amplifier are made, turn Master (20) and all Volume controls down and switch on the power (29) and a “POWER” LED will illuminate (23). Turn up the Master control part way for testing. The supplied UHF wireless microphone is powered by 2 x AA batteries (supplied), which should be installed into the handheld microphone by unscrewing the base to reveal the battery compartment. -
Page 6: Usb/Sd Player
Bluetooth The Bluetooth function allows connection of a smart phone or tablet to the media player section for playback of stored files or streamed digital audio. In order to enable this function, it will be necessary to pair the sending device to the receiver as follows. 1. -
Page 7: Specifications
Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful life. The goods must be disposed of according to your local council guidelines. Hereby, AVSL Group Ltd. declares that the radio equipment type 953.147UK, 953.149UK and 953.150UK is in compliance with...
