- Page 1 Harmony Duo Oval Freestanding Bathtub Installation & Care Manual USA and CANADA www.aquaticaplumbing.com E: info@aquaticaplumbing.com...
- Page 2 Harmony Duo Freestanding Oval Bathtub ... At a glance Type & Shape: Oval Monobloc (Seamless) bathtub with Deep Immersion Dimensions: 70¾× 31½ × 22¼” Weight: 50.71 lbs Water Volume: 60.5 US Gallons Faucet installation: Wall or floor mounted faucets solely Minimum spout length for wall or floor mounted faucets: 6”...
- Page 3 Harmony Duo Freestanding Oval Bathtub ... Planning and preparing your installation location: ” 7 0 ¾ 3 1 . 5 ” 2 9 . 5 ”...
- Page 4 Picture 1-2: the bathtub must be carried upside-down. It must never be carried by its panel. • Picture 3: the Harmony Duo bathtub is equipped with factory pre-installed overflow system . The waste pipe/p-trap connection must be made directly to the waste/drain outlet located at the bottom of the tub. www.aquaticaplumbing.com...
- Page 5 Harmony Duo Freestanding Oval Bathtub INSTALLATION SEQUENCE continued • Picture 4-5: the bathtub is leveled via a water level at the intended local installation area. • Picture 6: place the bathtub by raising it up 3½” with 4x4 peices of lumber so you can have access from the bottom of the bathtub.
- Page 6 Harmony Duo Freestanding Oval Bathtub Installation Procedure at a Glance • Drain (provided) • 1½” Female Adapter • 1½" ABS ABS Extension Pipe* Use Home Depot PART “1 1/2” ABS (cut to length) Female Adapter Hub x FIPT or equivalent from another supplier...
- Page 7 Harmony Duo Freestanding Oval Bathtub Deep Immersion Feature LEVEL LEVEL + 2” STANDARD The new Aquatica overflow system used in Harmony series bathtubs allows to adjust the water level trough the bath handle. The ability to increase the water Overflowing water level is achieved by adjusting the handle position during the installation.
- Page 8 www.aquaticaplumbing.com E: info@aquaticaplumbing.com...
