ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7868M / CM7868D
DIFFICULT
Tools Required For Assembly:
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 4
(Not Included)
Rev: 16-07-25
Advertisement
Related Manuals for Furniture of America CM7868M
Summary of Contents for Furniture of America CM7868M
- Page 1 Assembly Instructions CM7868M / CM7868D ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Phillips Screwdriver assembling a specific product (with 1 being (Not Included) easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 4...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Screw 1-1/4"L Mirror Drawer Dresser Mirror Support Rail - 700 x 30 x 18mm Support Leg - 45 x 30 x 30mm Page 3 of 4...
- Page 4 Align the top holes along the mirror back support (#3) to the holes along the back sides of the mirror (#1), then insert a screw (#A) into each hole. Secure using a screwdriver. #A x 4pcs Align the bottom holes along the mirror back support (#3) to the holes along the back of the drawer dresser (#2), then insert a screw (#A) into each hole and secure.
