CM7867D
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 4
CM7867M
(Included)
(Not Included)
Rev: 16-07-25
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7867D
Summary of Contents for Furniture of America CM7867D
- Page 1 Assembly Instructions CM7867D CM7867M ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 4...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Screw M4 x 32mm Mirror Dresser Mirror Support Rail - 995 x 30 x 18mm Support Leg - 90 x 30 x 30mm Page 3 of 4...
- Page 4 Loosen the button screws of the mirror support rails (#3) to rotate them upwards. 1. With the help of another person, place the mirror (#1) onto the dresser (#2) and align to the rails (#3). 2. Insert 4 screw (#A) into #A x 8pcs each mirror support rail (#3) and secure using a...
