Leica Silverline 10x25 Specifications

LEICA SILVERLINE 10 x 25

Technical Data

Binocular LEICA SILVERLINE
10 x 25
Order No. Product 40 652
Delivery scope Woven carrying strap, eyepiece cover, deep-drawn leather case
Magnification 10 x
Front lens diameter 25 mm
Exit pupil 2.5 mm
Twilight factor 15.8
Field of view at 1,000 m 90 m
Field of view at 1,000 yds 273 ft
Eye-relief 15 mm
Objective angle of view 5.2°
Close focusing distance approx. 3.2 m/10.5 ft
Diopter compensation ± 3.5 diopters
Automatic diopter
compensation ADC™ yes
Eyepieces for eyeglass
wearers yes
Adjustable interpupillary
distance 34–74 mm
Focusing Internal focusing via central focusing knob
No. of lens elements
(each side) 6, all with HDC™ coating
Prism system Roof prism with phase correcting coating P40 and HighLux-System HLS™
Coating AquaDura™ coating on outer lens (not on close focus lens)
Watertightness Watertight to a depth of 5 m/16.5 ft
Housing Aluminum, nitrogen-filled
Dimensions (W x H x D) 111 x112 x 39 mm
4
Weight approx. 255 g / 9 oz
Page 1 of 1 / As at december 2010 / Specifications are subject to change without notice
Leica Camera AG / Oskar-Barnack-Straße 11 / D-35606 Solms / Telephone +49 (0) 6442-208-0 / Telefax +49 (0) 6442-208-333 / info@leica-camera.com / www.leica-camera.com
⁄ x 4 ⁄ x 1 ⁄ in
3 3 1
8 8 2
