2.3. Panel Diagrams and Controls

F
EATURE
 M
D
AIN ISPLAY
 O
O
PTICAL UTPUT
P
ORTS
 L
P S
ASER OWER WITCH
Optilab, LLC
600 E. Camelback Road, Phoenix, AZ 85012
Phone: (602) 343-1496, Fax: (602) 343-1489, Email: sales@oequest.com
DFB-4-B Benchtop Front Panel
1
The LCD display shows the parameters and optical settings of the
DFB benchtop unit. This is a touchscreen type display (see
section 2.4 for more information)
The optical output receptacles for the benchtop unit. Up to 4
optical ports will be present, one for each laser unit. These
particular receptacles are FC/APC type.
This switch enables / disables the laser optical output for the DFB
lasers.
This feature is not enabled on all units.
2
3
F
UNCTION
