INSTALLATION & OPERATING
INSTRUCTIONS
MODEL 67050
PORTABLE
FOR YOUR RECORDS
MODEL NO: ___________________
DATE PURCHASED: ____________
WHERE PURCHASED: __________
INPUT POWER CORDS
OVER/UNDER VOLTAGE PROTECTION
Should voltage drop below 102V or rise above 132V for more than 8
seconds, power to watercraft is turned off.
SEE TIME DELAY INDICATOR
The green LED indicates power to Watercraft
TIME DELAY INDICATOR
When unit is plugged in, the red caution LED is
flashing indicating delay. The LCD at the same
will count up to 128 seconds. When the delay
expires, the red caution LED will stop flashing
and power will be applied to the watercraft.
Time delay will also be applied to reset once
power is restored to a safe range following
the 128 second delay. This allows head
pressure to bleed off the A/C Compressor.
SURGE FAILURE
If the red "SURGE" indicator LED is on,
it means that the built-in surge protection
has
been
equipment and is no longer functioning
properly. Other features will still function,
but the unit is recommended to be replaced.
CAUTION LIGHT POLARITY
Indicates possible miswiring or current to
ground
condition
power on 50 amp unit only.) The LCD screen
will also indicate REVERSE POLARITY.
3 MODE SURGE PROTECTION
Protects the watercraft's sensitive electronic
systems and appliances from potentially
damaging
power
power
interruptions
OUTPUT POWER CORDS
www.rvpower.southwire.com
For technical assistance, please call 1-800-780-4324 x 20311
Manufactured by Southwire Company, LLC, 4525 140th Avenue North, Suite 900, Clearwater, Florida 33762
© 2017 Southwire Company, LLC. All rights reserved.
when illuminated.
sacrificed
to
protect
your
PROTECTION
present.
(Will
prevent
surge
events
without
to
the
watercraft.
* Trademark of Southwire Company, LLC. Registered in the United States.
MODEL 67030
PORTABLE
505-00063C
