WASHER DRYER
PWD 8514VU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PWD 8514VU and is the answer not in the manual?

Questions and answers

Related Manuals for Philco PWD 8514VU

Summary of Contents for Philco PWD 8514VU

  • Page 1 WASHER DRYER PWD 8514VU...

  • Page 2: Table Of Contents

    Thank you for choosing this product. WEEE should be handed over to the relevant We are proud to offer the ideal product for collection points managed by the municipality or you and the best complete range of home by registered companies. In many countries, for appliances for your daily routine.

  • Page 3: General Safety Rules

    inappropriate. Cleaning 1. GENERAL SAFETY user maintenance shall not be RULES made children without This appliance is intended to supervision. be used in household. different this Children of less than 3 years appliance from household should be kept away unless environment or from typical continuously supervised.
  • Page 4 The appliance must not be Oil-affected items can ignite installed behind a lockable spontaneously, especially when door, a sliding door or a door exposed to heat sources such with a hinge on the opposite as a washer dryer. The items side to that of the washer become warm,...
  • Page 5 Make sure that the electrical Do not expose the washing system is earthed, complies machine to rain, direct sunlight with all applicable law and that or other weather elements. (electricity) socket Protect from possible freezing. compatible with the plug of the When moving, do not lift the appliance.

  • Page 6: Installation

    2. INSTALLATION Remove the 2 or 4 transportation screws (A) on the back and remove the 2 or 4 flat washers, rubber bungs and plastic spacer tubes (B) as illustrated in figure 1. If the washing machine is built- unscrew transportation screws (A) and remove the 3 or 4 flat washers, rubber bungs and plastic spacer...
  • Page 7 Fitting under worktop Slide the appliance into an opening of the size indicated in the diagram. The 4 adjustable feet allow the height of the washer to be adjusted from 820 mm to a maximum of 840 mm. To adjust the height, you should remove the nuts fitted to each foot and replace these with the 5 mm...
  • Page 8 Hydraulic connections Connect the water hose to the water supply tap (fig. 3) only using the hose supplied with the appliance (do reuse old hose-sets). SOME MODELS may include one or more of the following features: HOT&COLD (fig. 4): water mains connection settings with hot and cold water for higher energy savings.
  • Page 9 Level the appliance using the feet as illustrated in figure 8: a. turn the nut clockwise to release the screw; b. rotate the foot to raise or lower it until it touches to the floor; c. lock the foot, screwing in the nut, until it tightens against to the bottom of the washing machine.

  • Page 10: Practical Hints

    3. PRACTICAL HINTS reduce the necessity of a hot wash programme. Save energy by using a low temperature wash programme. Load tips Before using drying programme When sorting laundry, make sure: (WASHER-DRYERS) - have eliminated metallic objects such as hair clips, pins, coins, from laundry; SAVE energy and time by selecting a high spin speed to reduce the water - to have buttoned pillow cases, closed...

  • Page 11: Cleaning And Maintenance

    4. CLEANING AND Remove and clean the filter; when finished, replace it turning it clockwise. MAINTENANCE The filter handle will be locked when it is not possible to turn any further and the To clean the washing machine exterior, use handle is horizontal.

  • Page 12: Quick User Guide

    5. QUICK USER GUIDE 6. CONTROLS AND PROGRAMS This washing machine automatically adjusts the level of the water to the type and quantity of washing. This system gives a reduction in energy consumption and a saving in washing times. Program selection Turn on the washing machine and select the required program.
  • Page 13 START/PAUSE button WARNING: Don’t touch the display while inserting Close the door BEFORE selecting the plug because machines button START/PAUSE. calibrates the systems during the first seconds: touching the display, the machine couldn’t work property. In Press to start the selected cycle. this case, remove the plug and repeat the operation.
  • Page 14 washing programme To delay the start use the following compatible with automatic drying procedure: selected, this function will activated. - Select the required programme. - Press the delay start button once to If you exceed the maximum dryable activate it (h00 appears on the display) load of laundry indicated in the and then press it again to set a 1 hour programme table, the laundry may not...
  • Page 15 It is advisable to also use this function for RAPID / STAIN LEVEL button the children clothes and for the washing of heavily soiled items, which requires a This button allows you to choose between lot of detergent to be used, or for the two different options, depending on the washing of toweling items whose fibres selected programme:...
  • Page 16 Close the door BEFORE selecting the An over dosing of detergent can START/PAUSE button. cause excessive foaming. appliance detects the presence of excessive foam, it may exclude the When START/PAUSE is pressed on spinning phase or extend the duration the machine with the door closed, the of the program and increase water indicator will flash momentarily and then consumption.
  • Page 17 5) KEY LOCK INDICATOR LIGHT 8) DRYING SELECTION INDICATOR LIGHTS The indicator light show that the keys are The indicators display the degrees of locked. dryness that can be selected by the relevant button: 6) STAIN LEVEL INDICATOR LIGHT Automatic drying programmes The indicator light shows the selection of the relevant option.
  • Page 18 Table of programmes (MAX.) (see control panel) PROGRAMME (MAX.) Whites 90° 60° Cotton Jeans 40° Eco 20°C 20° Mixed 60° Delicates 40° Rinse Spin Drain 30° 3) 4) 30° Rapid 40° Shirts 30° Wool 40° Handwash 30°...
  • Page 19 Please read these notes: INFORMATION TEST Maximum load capacity of dry clothes, LABORATORIES (Ref. 50229 according to the model used (see control Standards) panel). Washing (Only for models with liquid Use the programme with the maximum detergent compartment) degree of soiling selected, maximum When only a limited number of spin speed and a temperature of 60°C.
  • Page 20 Drain Description of programmes This programme drains out the water. To clean different types of fabrics and Rapid (14-30-44 Min.) various levels of dirt, the washing machine Washing cycle suggested for low loads and has specific programs to meet every need slightly dirty.

  • Page 21: Drying Cycle

    7. DRYING CYCLE The correct way to dry Drying guidance advice is general, but Open the door. practical experience of using the product will help you to achieve the best drying Fill with the laundry, not exceeding the results. maximum drying load indicated in the programme table.
  • Page 22 The washer dryer will calculate the time Switch off the machine by turning the needed for drying and the level of programme selector to the OFF position. moisture remaining laundry, according to the load and drying type Open the door and remove the laundry. selected.

  • Page 23: Automatic Washing/Drying Cycle

    8. AUTOMATIC WASHING/ Press the START/PAUSE button. DRYING CYCLE At the end of the wash phase the display will show the drying time remaining. You cannot exceed the maximum dryable load of laundry indicated in The drying programme indicator will be the programme table, otherwise the on, until the cool down phase begins and laundry will not be dried satisfactory.

  • Page 24: Troubleshooting And Warranty

    9. TROUBLESHOOTING AND WARRANTY If you believe the washing machine is not working correctly, consult the quick guide provided below which includes some practical tips on how to fix the most common problems. ERROR CODE FORMAT Models with a display: the error is shown by a number preceded by the letter “E” (example: E2 = Error 2).
  • Page 25 OTHER ANOMALIES Problem Possible causes and practical solutions The washing machine Make sure the product is plugged into a working supply socket. Make sure power is on. does not work / start Make sure the wall socket is working, testing it with another appliance such as a lamp.
  • Page 26 The use of ecological detergents without Warranty phosphates may cause the following effects: The product is guaranteed under the terms and conditions stated on the - cloudier rinse drain water: This effect is certificate included with the product. The tied to the suspended zeolites which do certificate has to be stored so as to be not have negative effects on rinse shown to the Authorized Customer...
  • Page 28 4/F, DCH Building, 20 Kai Cheung Road, Kowloon Bay, Hong Kong...
