Gimenez Ganga Saxun Stor Glass Avant Assembly And Installation Manual

Product Installation
2
1

Warnings

Place the frame in the window opening, without removing
the protective adhesive tape.

1. Clean the window

Clean the marked areas of the window with alcohol.

2. Adjust the supports

Then, adjust the clips to be as close as possible to the corners.

3. Install the product

1
Remove the protective adhesive tape.
Press each corner firmly against the
window for 5 seconds, starting with
the lower corners of the Stor
3
1
1
1
2
Giménez Ganga, S.L.U.
Polígono Industrial El Castillo
C/ Roma, 4
03630 • Sax (Alicante) • España
saxun.com
Assembly and installation manual
Stor Glass Avant
Chain
system
Spring
system
General recommendations regarding safety, use
and restrictions
In order to ensure the safe assembly, use and maintenance of this product, a
number of precautionary measures must be taken. Please observe the following
warnings and instructions, for the safety of all concerned. If in doubt, contact
your dealer.
Please read this manual carefully These systems are exclusively inten-
before starting work. ded for the use for which they were
designed. Any other use is inappro-
Some components may be sharp or priate, and therefore dangerous.
have jagged edges. It is therefore
advisable to wear safety gloves. The manufacturer will not be liable for
damage caused during the
All parts supplied have been designed installation due to non-compliance
specifically for this product. The re- with these recommendations.
placement or addition of other parts
may have a negative effect on the
safety of the product and its warranty.
Under no circumstances should a
damaged product be installed, as
it may damage the equipment and
create situations that are dangerous
for people.
EN
