Gimenez Ganga Saxun Plisada Glass 111 Assembly And Installation Manual

Product installation

2
1

Warnings

Place the frame in the window opening, without removing
the protective adhesive tape.

1. Clean the window

Clean the marked areas of the window with alcohol.

2. Adjust the supports

Then, adjust the clips to be as close as possible to the corners.

3. Install the product

1
Remove the protective adhesive tape.
Press each corner firmly against the
window for 5 seconds, starting with
the lower corners of the Stor
3
1
1
1
2
Giménez Ganga, S.L.U.
Polígono Industrial El Castillo
C/ Roma, 4
03630 • Sax (Alicante) • España
saxun.com
Assembly and installation manual
Plisada Glass
Model 111
Model 140
General recommendations regarding safety, use
and restrictions
In order to ensure the safe assembly, use and maintenance of this product, a
number of precautionary measures must be taken. Please observe the following
warnings and instructions, for the safety of all concerned.
Please read this manual carefully
before starting work. These systems are exclusively inten-
ded for the use for which they were
Some components may be sharp or designed. Any other use is inappro-
have jagged edges. It is therefore priate, and therefore dangerous.
advisable to wear safety gloves..
The manufacturer will not be liable
All parts supplied have been designed for damage caused during the ins-
specifically for this product. The re- tallation due to non-compliance with
placement or addition of other parts these recommendations.
may have a negative effect on the
safety of the product and its warranty.
Under no circumstances should a
damaged product be installed, as
it may damage the equipment and
create situations that are dangerous
for people.
EN
