SUNSET NEB402 Instruction Manual

Handheld mesh nebulizer
Hide thumbs Also See for NEB402:

Advertisement

Quick Links

Instruction Manual
Handheld Mesh Nebulizer
NEB402
Manufactured for
Sunset Healthcare Solutions
180 N Michigan Ave Ste 2000
Chicago, IL 60601
IFU-00059 REV 1.00
2022-05-17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEB402 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SUNSET NEB402

  • Page 1 Instruction Manual Handheld Mesh Nebulizer NEB402 Manufactured for Sunset Healthcare Solutions IFU-00059 REV 1.00 180 N Michigan Ave Ste 2000 2022-05-17 Chicago, IL 60601...
  • Page 2 Thank you very much for choosing Handheld Mesh Nebulizer. Please read this user manual carefully before using, so that you can use it safely and correctly. Please keep this user manual properly in place for future reading.
  • Page 3: Table Of Contents

    Table of Contents 1. Important Safety Notes ..............5 2. Intended Use ..................5 3. Contraindications ................5 4. Package Contents & Overview ............5 5. Product Technical Parameters ............6 6. User Instructions ................7 7. Cleaning & Disinfection ..............10 8.
  • Page 4: Important Safety Notes

    1. Important Safety Notes a. For the type, dose and regimen of the medication, please follow the instruction from your medical doctor. b. Please operate the device as intended. c. This unit is only used for nebulization. d. Please clean and disinfect the medication cup and accessories before using each time.
  • Page 5: Product Technical Parameters

    4.2 Product Contents A. Medication Cover B. Medication Cup C. Spray Nozzle D. Main Unit E. Power Switch F. Slide G. PRESS Switch H. Micro USB Cable Figure 2 Product Contents 5. Product Technical Parameters Device Name Handheld Mesh Nebulizer DC 4.8V (2×2.4V rechargeable Li-ion Power Supply batteries) or DC 5.0V 1.0A with AC adapter...
  • Page 6: User Instructions

    ℉ ℉ (-10 ℃ to Temperature: +14 to +122 +50 ℃ ) Relative Humidity: 30%~80%R.H. Storage Environment Atmospheric pressure: (86.0~106.0) kPa Time Auto-off Power on, operate 10 mins, then auto-off Table 1 Technical Parameters Durable Period: Durable periods are as follows, provided the product is used to nebulize medication 3 times a day for 10 minutes each time at temperature +77 ℉...
  • Page 7 6.2 Battery Charging The battery group can supply power up to 60 minutes continually after full charging. When the battery power is below 3.8V, the green LED light will keep flashing, until the nebulizer powers off automatically. When low power is indicated, please recharge the battery for 1.5 hours.
  • Page 8 Figure 4 Filling Procedure Step Three: Connect mask or mouthpiece as in Figure 5 below, and click ON/OFF switch to power on. Figure 5 Connect Mask or Mouthpiece Please hold the nebulizer to keep liquid medication in contact with the vibrating mesh, and the stream of inhalation, Please see Figure 6 below.
  • Page 9: Cleaning & Disinfection

    Step Four: When finishing nebulization, press ON/OFF switch to power off. Pour out the residual liquid medication from the medication cup. Please see Figure 7 below. PRESS Button Figure 7 Pouring out the Residual Liquid Medication Step Five: Clean after use: Clean and disinfect the main unit, medication cover, medication cup and mask or mouthpiece by the method on the Section 7 (Please refer to the Section 7 Cleaning &...
  • Page 10 close the medication cover. Soak the medication cup for 5 minutes. c.Turn on the device to nebulize the clean water for 1 to 2 minutes to remove residual medication from the mesh. d.Turn off the device and disassemble the medication cover and medication cup from the main unit.
  • Page 11: Storage Conditions

    8. Storage Conditions The device should be stored indoors. The environment temperature should be +14℉ to +122℉ (-10℃ to +50℃ ), non-corrosive gas, good ventilation, avoid high temperature, humidity and direct sunlight. Keep the device out of the reach of unsupervised infants and children. The device may contain small parts that can be swallowed.
  • Page 12: Note & Warning

    Please refer to a physician's advice. Viscous Unsure which medication is not allowed. medication to use Please choose kids mask to cover mouth and Pediatric use nose for better effect. Kids are forbidden to use the nebulizer alone. 10. Note & Warning 10.1 Note •...
  • Page 13: Emc Declarations

    • Do not use the unit near high frequency products or electronic products. • Do not use a microwave oven, oven, blow dryer or other house applications to dry nebulizer and accessories. 10.2 Warning • Please stop using it if you feel uncomfortable and please contact a doctor. •...
  • Page 14 (for which CISPR 11 class B is normally required). 2.WARNING:The use of accessories and cables other than those specified by Sunset, with the exception of cables sold by Sunset as replacement parts for internal components, may result in increased emission or decreased immunity of the device.
  • Page 15 Length ( m ) Cables Whether to block Note USB Cable Guidance and Manufacturer’s declaration – electromagnetic emissions This device is intended for use in the electromagnetic environment specified below. The customer or the user of the device should assure that it is used in such environment.
  • Page 16 ±2 kV for Mains power quality should power ±2 kV for Electrical fast be that of a typical supply lines power transient/burst commercial or hospital ±1 kV for supply IEC 61000-4-4 input/output lines*1) environment. lines Mains power quality should ±1 kV line to ±1 kV line to Surge IEC be that of a typical...
  • Page 17 Guidance and manufacturer’s declaration – electromagnetic immunity – for device that is not LIFE- SUPPORTING. Guidance and manufacturer’s declaration – electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The customer or the user of the device should assure that it is used in such an environment.
  • Page 18 NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies. NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. • Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
  • Page 19 Separation distance according to frequency of transmitter Rated maximum output 150 kHz to 80 MHz 80 MHz to 800 800 MHz to 2.5 power of transmitter 0.01 0.12 0.12 0.23 0.38 0.38 0.73 For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W)
  • Page 20: Signs & Symbols

    12. Signs & Symbols Label Explanation Label Explanation General mandatory action Batch code sign Serial number General prohibition sign Indicates the product does not contain toxic and Manufacturer harmful substances and element. Protected against solid foreign objects of 12.5 mm and greater;...
  • Page 21 Warning, Non-sterile electricity TYPE BF Refer to instruction manual/ APPLIED booklet PART It means prohibition (the thing was not Fragile, handle with care permitted to “ON” / “OFF” Operation indicator (push-push) Storage and delivery Storage and delivery temperature humidity limitations limits Storage and delivery...
  • Page 22: After-Sales Service

    13. After-sales Service Changes or modifications by users are not allowed. Any such behaviors will void the user’s warranty right. 1. The device is warranted to be free from defects materials and workmanship appearing within 1 year from the date of purchase, when used in accordance with the instructions provided with the device.
  • Page 23: Disclaimer Clause

    14. Disclaimer Clause Please read the user manual before use the product. We will not take any responsibility in case of damage caused by improper use of the product. Please use or purchase original parts or accessories. The manufacturer does not take responsibility for the buyer or third parties for any damage or loss intentionally or unintentionally caused by improper use.
  • Page 24: Warranty Card

    Warranty card ●The period of host free for maintan service is 1 year. Medication cup is 6 months. NEB402 ●During the warranty period, we will decide to repair or Warranty Card replace damaged parts and accessories according to the case. When exceed the warranty period, relevant charge Distributor copy must be taken according to the case.
  • Page 25: Certificate Of Inspection

    FCC STATEMENT FCC Caution Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference;...
