Shurco truXedo Lo Profile Owner's Manual

DIRECT ALL WARRANTY CLAIMS TO SHUR-CO. AT 1-877-878-9336
3 3 3 3 3 "
1 ___*___ TruXedo Replacement Cover 11 1703344 Blind Rivet, 1/8" x 3/16"
2 ___*___ Black Header 12 1701595 End Plug, 1" OD
3 ___*___ Header Seal, Notched 13 ___*___
4 1115372 Header End Plugs (Set of Two) 14 1702992 Spring Plunger, 5/8" x 1.94"
5 1702602 Square Nut, 3/8" 15 1703260 Tension Control Bracket
6 1115354 Header Insert Safety Clip 16 1703345 Spring Pin, 1/8" x 5/16"
7 ___*___ Safety Strap 17 ___*___
8 1114872 Header Guide 18 1703332 Hitch Pin, 1/16" x 1 5/16"
9 1703000 Cap Screw, 3/8" x 1 1/2" 19 ___*___
10 1115353 Header Safety Strap 20 ___*___
* Please specify length or make and model of vehicle.
21 ___*___ Side Rail, Driver's Side
22 1114773 Flat Spring, 5/8" x 3 7/8"
23 1115658 Latch Main Frame
Black Bow
24 1702610 Clevis Pin, 3/16" x 1 1/4"
25 1114888 Toggle
26 1700419 Nylon Lock Nut, 5/16"
27 1703265 Toggle Cap
Shur-Bond™ VELCRO ® Fasteners
28 1702611 Cotter Pin, 3/64" x 19/32"
29 1702926 Cap Screw, 5/16" x 7/8"
Aluminum Clamp Assy
30 1702801 Header Stop
Side Rail, Passenger's Side
31 1115373 Side Rail End Plugs w/Seal (Set of Two)
