GMV5 HR HEAT RECOVERY VRF Units Technical Sales Guide
Outdoor Units_Heat Recovery
Model
Module combination
Low pressure Gas Pipe Size
Pipe
high pressure gas pipe Size
Connection
Liquid Pipe Size
External Dimension
Dimensions
(width×
depth×
height)
Packaging Dimension
Net Weight
Weight
Gross Weight
Maximum qty of connected indoor units
High Pressure Protection
Protection
Compressor /Fan
Devices
Inverter
① . Rating conditions:
Cooling: indoor 26.7°C (80°F) D.B./19.4°C(67°F)W.B. outdoor: 35°C(95°F)D.B.
Heating: indoor 21.1°C (70°F)D.B. outdoor: 8.3°C (47°F)D.B./6.1°C(43°F)W.B
Remark ② . It refers to the operation power of compressor under ARI test conditions (Condensing temp. 130°F; Evaporating
temp.45°F; Return gas temp.65°F; Liquid temp.115°F) at 60Hz.
③ . Oil charge includes the total oil amount of outdoor units, residual oil amount of compressor and oil separate tank.
When replacing the compressor or oil separate tank, only the corresponding required oil amount shall be charged
Ton 12
- GMV-Q144WM/B1-F(U)
- GMV-Q144WM/B1-F(U)
mm 28.60
in. 1 1/8
mm 22.20
in. 7/8
mm 12.70
in. 1/2
mm 1340×765×1605
in. 52-3/4×30-1/8×63-1/5
mm 1420×840×1775
in. 55-7/8×33-1/8×69-7/8
kg 370
lbs. 816
kg 385
lbs. 849
unit 23
High pressure sensor, High pressure switch
Over-current protection, Over-heat protection
Over-current protection, Over-heat protection, High/ Low voltage protection,
14
GMV-Q168WM/B1-F(U)
GMV-Q168WM/B1-F(U)
28.60
1 1/8
22.20
7/8
5.90
5/8
1340×765×1740
52-3/4×30-1/8×68-1/2
1420×840×1910
55-7/8×33-1/8×75 1/4
395
871
411
906
29
9
